127

3

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

A setting around 21 enables you to
obtain an optimum level of comfort.
Depending on your requirements, a
setting between 18 and 24 is usual.
In addition, it is recommended that you
avoid a left/right setting difference of
more than 3.

Dual-zone automatic air conditioning

offers the best compromise between
a comfortable temperature and quiet
operation.

Provides soft and quiet operation by
limiting air flow.

Provides strong and effective air flow.

F  Press the "AUTO" button

repeatedly.

Automatic comfort mode

Temperature

F  Push the button down to

reduce the value or up to
increase it.

When the engine is cold, the air flow will
only reach its optimum level gradually
to prevent too great a distribution of
cold air.
In cold weather, it favours the
distribution of warm air to the
windscreen, the side windows and the
footwells only.

The active mode appears in the display screen,
as described below:

If desired, you can choose settings different
to those offered by the system, by adjusting a
setting manually. The other functions are still
managed automatically.
The "AUTO" symbol disappears if you modify
a setting.

Manual mode

The driver and front passenger can each set
the temperature to suit their requirements.
The value indicated in the screen corresponds
to a level of comfort and not to a temperature in
degrees Celsius or Fahrenheit.

128

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Visibility programme

F  Press the "visibility" button for

faster demisting or defrosting
of the windscreen and side
windows.

F  Press the "visibility" button

again to stop the programme.

The system automatically manages the
air conditioning, air flow and air intake and
distributes the flow of air to the windscreen and
side windows to the best effect.

For maximum cooling or heating of
the passenger compartment, you can
exceed the minimum value of 14 or the
maximum value of 28.

F  Push the button down

until "LO" is displayed
or up until "HI" is
displayed.

on entering the vehicle, if the interior
temperature is much colder or warmer
than the comfort value, there is no need
to alter the value displayed in order to
obtain the required level of comfort.
The system corrects the temperature
difference automatically and as quickly
as possible.

"Mono" function

The comfort setting for the passenger side
can be indexed to the driver's comfort setting
(mono-zone).

The function is deactivated automatically if a
passenger uses the temperature control.

or

F  Press the "AUTO" button to

return to the automatic comfort
programme.

F  Press this button to activate /

deactivate the "Mono" function.

The indicator lamp in the button is on
when the function is activated.

129

3

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

F  Press this button to increase air

flow.

Air distribution

F  Press this button repeatedly to

direct the air flow in turn to:

-

the windscreen, the side windows and the
footwells,

-

the footwells.

-

the central vents, the side vents and the
footwells,

-

the windscreen, the side windows, the
centre vents and the footwells,

-

the centre and side vents,

-

the windscreen and side windows
(demisting or defrosting).

Air flow

F  Press this button to decrease air

flow.

The air flow symbol (a fan) appears. It is filled
in or emptied progressively according to the
setting.

Air conditioning

It enables you to:
-

lower the temperature, in summer,

-

increase the effectiveness of the demisting
in winter, above 3°C.

Switching on

With the engine running, the air conditioning is
designed to operate effectively in all seasons,
with the windows closed.

The air conditioning does not operate
when the air flow adjustment is set
to off.

To obtain cool air more quickly, you
can use interior air recirculation for
a few moments. Then return to the
intake of exterior air.

F  Press this button; its indicator

lamp comes on.

F  Press this button again; its

indicator lamp goes off.

Switching off

Switching off may result in some
discomfort (humidity, misting).

130

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Switching the system off

F  Press this button until the fan

symbol disappears.

This action switches off all of the functions of
the system.
The temperature is no longer controlled.
A slight flow of air, resulting from the movement
of the vehicle, remains perceptible however.

Avoid driving for too long with the
system switched off (risk of misting and
of deterioration of the air quality).

Air intake / Air recirculation

The intake of exterior air avoids misting of the
windscreen and side windows.
The recirculation of interior air insulates the
passenger compartment from exterior odours
and smoke.

Return to exterior air intake as soon as
possible to avoid deterioration of the air
quality and the formation of mist.

This allows hot or cold air to be
delivered quickly when required.

F  Press this button to recirculate

the interior air; the symbol
appears.

F  Press this button again to allow

exterior air into the passenger
compartment; the symbol
disappears.

F  Press this button to switch the

system on again.

131

3

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Front demist - defrost

These markings on the control panel indicate the control positions for rapid demisting or
defrosting of the windscreen and side windows.

Manual air conditioning

With Stop & Start, when demisting has
been activated, the SToP mode is not
available.

Dual-zone digital air
conditioning

F  Put the air flow, temperature and

distribution controls to the dedicated
marked position.

The system automatically manages the air
conditioning, air flow and air intake, and
provides optimum distribution towards the
windscreen and side windows.

The system reverts to the previous settings.

F  Press this button to demist or

defrost the windscreen and side
windows as quickly as possible.

F  To stop, press this button again

or on "AUTO".

F  For air conditioning, press

this button; its indicator lamp
comes on.

Heated windscreen and washer jets
For more information on the Wiper
control stalk and in particular the
heated windscreen and washer jets,
refer to the corresponding section.

132

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Door mirrors demist - defrost

Switching on

Switching off

F  Press this button to demist/

defrost the door mirrors; its
indicator lamp comes on.

The demisting/defrosting switches off automatically
to prevent an excessive consumption of current.

Door mirror demisting and defrosting
only operates with the engine running.

Switch off the heating of the rear screen
and door mirrors as soon as you judge it
possible, as reducing the consumption
of electrical current reduces fuel
consumption.

F  It is possible to stop the

demisting/defrosting operation
before it is switched off
automatically by pressing this
button again; its indicator lamp
goes off.

133

3

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Rear screen demist - defrost

Switching on

Switching off

F  Press this button to demist/

defrost the rear screen and the
door mirrors (if your vehicle is
so equipped); its indicator lamp
comes on.

The demisting/defrosting switches off automatically
to prevent an excessive consumption of current.

Rear screen demisting and defrosting
only operates with the engine running.

Switch off the heating of the rear screen
and door mirrors as soon as you judge it
possible, as reducing the consumption
of electrical current reduces fuel
consumption.

F  It is possible to stop the

demisting/defrosting operation
before it is switched off
automatically by pressing this
button again; its indicator lamp
goes off.

134

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

In order for these systems to be fully effective, follow the operation and maintenance
guidelines below:
F  To obtain an even air distribution, take care not to obstruct the exterior air intake grilles

located at the base of the windscreen, the nozzles, the vents and the air outlets, as well
as the air extractor located at the rear.

F  Do not cover the sunshine sensor, located at the top of the windscreen; this is used for

regulation of the air conditioning system.

F  operate the air conditioning system for at least 5 to 10 minutes, once or twice a month

to keep it in perfect working order.

F  ensure that the passenger compartment filter is in good condition and have the filter

elements replaced regularly.



We recommend the use of a combined passenger compartment filter. Thanks to its
special active additive, it contributes to the purification of the air breathed by the
occupants and the cleanliness of the passenger compartment (reduction of allergic
symptoms, bad odours and greasy deposits).

F  To ensure correct operation of the air conditioning system, you are also advised to have

it checked regularly as recommended in the warranty and maintenance record.

F  If the system does not produce cold air, switch it off and contact a PeugeoT dealer or

a qualified workshop.

Recommendations for heating, ventilation and air conditioning

If after an extended stop in sunshine,
the interior temperature is very high, first
ventilate the passenger compartment for
a few moments.
Put the air flow control at a setting high
enough to quickly change the air in the
passenger compartment.
The air conditioning system does not
contain chlorine and does not present
any danger to the ozone layer.

The condensation created by the air
conditioning results in a discharge
of water under the vehicle which is
perfectly normal.

When towing the maximum load on a steep gradient in high temperatures, switching off the
air conditioning increases the available engine power and so improves the towing ability.

Stop & Start

The heating and air conditioning
systems only work when the engine is
running.
To maintain a comfortable temperature
in the passenger compartment, you can
temporarily deactivate the Stop & Start
system.
For more information on Stop & Start,
refer to the corresponding section.

Air vents

To close a vent, move the control
towards the outside of the vehicle. Slight
resistance may be felt.

135

3

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

I require...

Heating or Manual air conditioning

Air distribution

Air flow

Recirculation of interior air /

Intake of exterior air

Temperature

Manual AC

HOT

COLD

DEMISTING

DEFROSTING

Suggested interior settings

Dual-zone air conditioning: use the automatic mode in preference by pressing the "AUTO" button.

136

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Rear Heating - Air conditioning

Activation/Deactivation

F  Press this button to enable the

rear controls, its indicator lamp
comes on.

F  Press this button again to inhibit

the rear controls, its indicator
lamp goes off.

Air flow

If your vehicle is fitted with a rear air
conditioning unit, located in the roof, this
system allows the distribution of air conditioned
and heated air via ducting and individual
outlets.

F  Turn the knob to increase or

decrease the air flow.

Temperature

-

Turn the knob from blue (cold)
to red (hot) to modulate the
temperature to your liking.

This button is accessible from the front, from
the air conditioning control panel.

This control simultaneously adjusts the
temperature and the location of the air
delivery:
-

at blue: the air is delivered mainly at
roof level,

-

at red: the air is delivered mainly
by the vent located in row 3 on the
right.

137

3

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Heating

This is an additional and separate system
which heats the engine hot water circuit to
heat the passenger compartment and improve
defrosting.

This indicator lamp is on when if the
system is programmed to come on
for heating.
This indicator lamp flashes while the
heating is operating.

Programmable Heating / Ventilation

Ventilation

This system allows ventilation of the passenger
compartment to improve the temperature
experienced on entering the vehicle in summer.

Programming

Audio system

F  Press on the MENU button to go

to the main menu.

F  Select "Pre-heat. / Pre-ventil.".

F  Select "Heating" to heat the engine and

passenger compartment or "Ventilation"
to ventilate the passenger compartment.

F Select:

-  the 1

st

clock to programme/store your

start time,

-  the 2

nd

 clock to programme/store a

second start time.

using these two clocks and according
to season you can, for example, select
one or the other start time.
A message in the screen confirms your
choice.

F  Select "Activation" and if necessary for

programming, select "Parameters".

138

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

F  Press and hold this button to stop

the heating immediately.

F  Press and hold this button to

start the heating immediately.

The indicator lamp in the remote control comes
on in red for about 2 seconds to confirm that
the signal has been received by the vehicle.

The indicator lamp in the remote control comes
on in green for about 2 seconds to confirm that
the signal has been received by the vehicle.

Switching off

Switching on

Long range remote
control

The range of the remote control is about
0.6 miles (1 km), in open country.

The indicator lamp in the remote control
flashes for about 2 seconds if the
vehicle has not received the signal.
You should then move to a different
location and repeat the command.

Changing the battery

If the indicator lamp in the remote control becomes
orange, the state of charge of the battery is low.
If the indicator lamp is not on, the battery is
discharged.

F  use a coin to unscrew the cap and replace

the bulb.

During heating

This indicator lamp flashes while the
heating is in operation.
This indicator lamp goes off at the
end of the heating cycle or when the
heating is stopped using the remote
control.

The maximum heating period is about
45 minutes depending on the ambient
conditions.

Do not throw the remote control
batteries away, they contain metals
which are harmful to the environment.
Take them to an approved collection
point.

139

3

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Always switch off the programmable
heating while refuelling to avoid any risk
of fire or explosion.
To avoid the risk of intoxication and
asphyxiation, the programmable
heating must not be used, even for
short periods, in an enclosed area such
as a garage or workshop not equipped
with exhaust gas extraction.
Do not park the vehicle on an
inflammable surface (dry grass, dead
leaves, paper…), there is a risk of fire.
glazed surfaces such as the rear
screen or windscreen can become very
hot in places.
Take care not to place objects in
contact with these surfaces, nor touch
them with your hands or any other part
of your body.

The heating is activated provided that:
-

the battery is sufficiently charged,

-

the fuel level is adequate,

-

the engine has been started since
the previous heating cycle.

The programmable heating system is
supplied by the vehicle's fuel tank.
Before use, ensure that there is enough
fuel in the tank.
If the tank is on reserve, it is
recommended that the system is not
used.

The ventilation is activated provided
that the battery is sufficiently charged.

140

Ease of use and comfort

Traveller-VP_en_Chap03_ergonomie-et-confort_ed01-2016

Individual reading lamp

Rear

Courtesy lamps

Automatic operation

The front courtesy lamp comes on when the
key is removed from the ignition switch.
All of the courtesy lamps come on when
the vehicle is unlocked, when one of the
corresponding doors is opened and for location
of the vehicle using the remote control.
They go off gradually after the ignition is
switched on and when the vehicle is locked.

Front

Permanently off.

Row 2 and row 3: comes on when
one of the rear doors or the boot
is opened (sliding side door and
depending on equipment, the left
hand side-hinged door or the tailgate).

Front: comes on when one of
the front or rear doors is opened
(sliding side door and depending on
equipment, the left hand side-hinged
door or the tailgate).

Permanently on, ignition on.

Take care not to leave anything in
contact with the courtesy lamp.

If fitted to the vehicle, these are
operated by means of a manual
switch.
With the ignition on, operate the
corresponding switch.

141

4

Lighting and visibility

Traveller-VP_en_Chap04_eclairage-et-visibilite_ed01-2016

F  Move switch A to the right or to the left to

select the corresponding mirror.

F  Move knob B in all four directions to adjust.
F  Return switch A to the centre position.

Electric unfolding

The electric unfolding of the mirrors is possible
with the remote control or the key on unlocking
the vehicle, unless folding was selected using
switch A. In this case, pull the switch rearwards
from the centre position again.

Mirrors

Electric adjustments

Electric folding

If your vehicle is fitted with this function, the
mirrors can be folded electrically from the inside,
with the vehicle parked and the ignition on:

F  Place switch A in the

centre position.

F  Pull switch A rearwards.

From the outside, lock the vehicle using the
remote control or the key.

The folding / unfolding on locking /
unlocking can be deactivated. Contact
a PeugeoT dealer or a qualified
workshop.
It is possible to unfold the mirrors
manually if necessary.

Door mirrors

142

Lighting and visibility

Traveller-VP_en_Chap04_eclairage-et-visibilite_ed01-2016

Heated mirrors

or

As a safety measure, the mirrors should
be adjusted to reduce the blind spots.
The objects observed are, in reality,
closer than they appear.
Take this into account in order to
correctly judge the distance of vehicles
approaching from behind.

For more information on Rear
screen demist - defrost, refer to the
corresponding section.

F  Press the heated rear window

button.

F  Press the heated mirror button.

If your vehicle has heated door mirrors:
