Peugeot 3008 Hybrid 4 (2017 year). Instruction

Access

Precautions in use

In wintry conditions

In the event of an accumulation of snow
on the tailgate, clear the snow before
commanding a motorised opening of the
tailgate.
The formation of ice can block the tailgate
and prevent its opening: wait until the ice
melts with the heating of the passenger
compartment.

When washing

When washing the vehicle in an automatic
car wash, don't forget to lock your vehicle
to avoid the risk of unexpected opening.

Recommendations related to the "Hands-Free Tailgate

Access" function

If several kicking movements to operate the
tailgate have no effect, wait a few seconds
before trying again.

The function automatically deactivates in heavy
rain or following a build-up of snow.
If it does not work, check that the electronic key
is not exposed to a source of electromagnetic
pollution (smartphone etc.).

The function may not work correctly with a
prosthetic leg.

The function may not work correctly if your
vehicle is fitted with a towbar.

In some circumstances, the tailgate may open
or close by itself, particularly if:
-  you hitch or unhitch a trailer,
-  you fit or remove a bicycle carrier,
-  you load or unload bicycles from a bicycle

carrier,

- you place or lift something behind the

vehicle,

-  an animal approaches the rear bumper,
-  you are washing your vehicle,
-  your vehicle is being serviced,
-  you are accessing the spare wheel

(depending on version).

To avoid such operating problems, keep the
electronic key away from the sensor zone or
deactivate the "Hands-Free Tailgate Access"
function.

Ease of use and comfort

The programmable heating operates independently from the engine.
With the engine off, it preheats the coolant circuit to ensure optimal engine operating temperature
as soon as it is started up.
The programmable heating is switched on by the long range remote control. It may be immediate or
deferred thanks to a programming function.

Programmable heating

Always switch off the programmable heating when refuelling to avoid any risk of fire or
explosion.
The programmable heating is powered by the vehicle fuel tank. Before use, ensure that
the remaining quantity of fuel is sufficient. If the fuel tank is in its reserve, we strongly
recommend you do not programme the heating.
To avoid the risks of intoxication or asphyxia, the programmable heating must not be used,
even for short periods, in a closed environment such as a garage or workshop which are not
equipped with an exhaust gas extraction system.
Do not park the vehicle on a flammable surface (dry grass, dead leaves, paper, etc.) - risk of
fire!

The volumetric alarm movement detector
may be disrupted by the programmable
heating air flows when it is operating.
To avoid any untimely triggering of the
alarm when using the programmable
heating, it is advisable that the volumetric
monitoring is deactivated.

Adapting the programmable heating
enables you to use it to preheat the
passenger compartment of your vehicle.
Contact a PEUGEOT dealer or a qualified
workshop.

Presentation

The heating programming remote control has
the following buttons and displays:

Remote control

1. Buttons for functions scroll-down menu.
2. Function symbols:

clock, temperature, operating time,
programmed time, heater operation,
heating management.

3. Digital displays:

time, temperature, operating time,
programmed time or heating level.

4. Off button.
5. On button.

Ease of use and comfort

lit up: deferred programmed start-up.
flashing: heating on.
turned off: heating off.

Operating indicator light

Press button

1 several times to display the

functions.

The first press on the left or right button
displays the time.
Then, the left button is used to scroll to the
programmed time then the heating level ("

C1"

to "

C5").

The right button is used to scroll to the
passenger compartment temperature then
the heater operating time when immediately
switched on.

Function display

The passenger compartment temperature
information is only available when the
engine is off.

Setting the time

After having displayed the time, using

button

1, press on buttons 4 and 5

simultaneously within 10 seconds.

This symbol will flash.

Set the time with button

Press simultaneously on buttons

4 and 5 to

save it.

This symbol will be displayed.

Ease of use and comfort

Immediate switching on

During these operations, if the message
"

FAIL" appears, it means that the signal

has not been received. Follow the
procedure again after having changed
position.

Adjusting the operating time

Press on button

1 to display the operating

time.

Press on button

5 until the message "OK"

appears.
When the signal has been received, the
message "

OK" is displayed along with the

operating time.

The heater starts and this symbol is
displayed.

This indicator light flashes during
heating.

To deactivate the function, press on button

4 until the message "OK" appears.

This symbol and the indicator light
will turn off.

This symbol will be displayed.

After having displayed the operating time,

press on buttons

4 and 5 simultaneously

within 10 seconds.

This symbol will flash.

Adjust the time by pressing on the buttons

1: by 10 min increment and maximum value

of 30 mins.

Ease of use and comfort

Deferred switching on

You must programme your start time for the
system to automatically calculate the optimal
time to start the heater.

This symbol will be displayed.

After having displayed the programming

time, press on buttons

4 and 5

simultaneously within 10 seconds.

The factory value setting is 30 minutes.

Set the time by pressing on button

Press simultaneously on buttons

4 and 5 to

save it.

This symbol will be displayed.

Press on button

1 to display the

programming time.

This symbol will be displayed.

This symbol will flash.

Programming the start time

Press simultaneously on buttons

4 and 5 to

save the operating time.

Ease of use and comfort

After having displayed the programming

time using button

1, press on button 5 until

the message "

OK" appears.

Activation / Deactivation

When the signal has been received,
the message "

OK" is displayed along

with this symbol.
This indicator lights up until the
heater starts.

Stopping the heating

Press button

This symbol will remain displayed.

Changing the heating level

The system has 5 heating levels:

C1 (lowest

level) to

C5 (highest level).

After having displayed the heating level

using button

1, press simultaneously on

buttons

4 and 5.

The letter "

C" will flash.

Adjust the heating level by pressing on

button

Press simultaneously on buttons

4 and 5 to

save the selected level.
The letter "

C" will be displayed.

The presets are replaced by the new
entries. The programmed times are
memorised until the next change.
When the start time is activated, it is not
possible to change the heating level. You
must first deactivate the start time.

This symbol is displayed when the
heater starts.

HTM: Heat Thermo Management

To deactivate the programming, press on

button

4 until the message "OK" appears.

This symbol will disappear.

This indicator light turns off.

During these operations, if the message

FAIL" appears, it means that the signal

has not been received. Follow the

procedure again after having changed

position.

Ease of use and comfort

Operating fault

In the event of a fault with the programmable
heating, contact a PEUGEOT dealer or a
qualified workshop.

Changing the battery

Unclip the case.

Replace the battery observing the

polarities.

Reset the remote control.

The remote control is powered by a 6V-28L
battery which is provided.
Information on the screen indicates when this
battery needs to be changed.

Resetting the remote control

If the battery is disconnected or when changing
the battery, the remote control must be reset.
F

After turning on the power, within the next

5 seconds, press button

4 for 1 second.

If the operation is successful, the message
"

OK" will be displayed on the remote

control's screen.
If there is a fault, the message "

FAIL" will

appear.

Start the operation again.

Do not throw away used batteries, take
them to an approved collection point.

Lighting and visibility

Windscreen wash

Wiper control stalk

Pull the wiper control stalk towards you.

The windscreen wash and then the wiper will
operate for a fixed period.

The windscreen wash includes a wiper
blade system with integral washer jets.
The screenwash fluid is sprayed from
along the length of the wiper blade.
This improves visibility and reduces the
consumption of screenwash fluid.
In some cases, depending on the
composition or the colour of the liquid and
the outside lighting, the liquid spray may
be hardly perceptible.

To avoid damaging the wiper blades, do
not operate the windscreen washer if the
windscreen washer reservoir is empty.
Only operate the windscreen washer if
there is no risk of the fluid freezing on the
windscreen and hindering visibility. Always
use windscreen washer fluid suitable for
low temperatures during the winter period.

Safety

Trailer stability assist

When towing, this system reduces the risk of the vehicle or trailer swaying.

Operation

The system is activated automatically when the
ignition is switched on.
The electronic stability programme (ESC) must
not have any faults.
Between 36 and 100 mph (60 and 160 km/h),
if the system detects swaying movements in
the trailer, it acts on the brakes to stabilise the
trailer and, if necessary, reduces engine power
to slow down the vehicle.

The correction is signalled by the
flashing of the indicator lamp in the
instrument panel and activation of the
brake lights.

Operating fault

Should a fault occur with the system,
this warning lamp comes on in the
instrument panel, accompanied by
the display of a message and an
audible signal.

The trailer stability assist system
offers increased safety in normal
driving conditions, provided that the
recommendations on towing a trailer are
observed. It must not encourage the driver
to take additional risks, such as towing
a trailer in adverse operating conditions
(overloading, failure to observe the trailer
nose weight, worn or under-inflated tyres,
faulty braking system, etc.) or drive at too
high a speed.
In certain cases, the swaying of the trailer
may not be detected by the ESC system,
particularly with a light trailer.
When driving on slippery or poor surfaces,
the system may not be able to prevent
sudden swaying of the trailer.

If you continue to tow a trailer, reduce your
speed and drive carefully!
Contact a PEUGEOT dealer or a qualified
workshop to have the system checked.

For information on the weights and towed
loads, refer to the "Technical data" section or
the registration certificate for your vehicle.
For advice on driving safely when

Towing a

trailer, refer to the corresponding section.

Driving

Distance alert and Active Safety Brake

This system includes three functions:
- Distance alert (alert if there is a risk of

collision),

- Intelligent emergency braking assistance,
- Active Safety Brake (automatic emergency

braking).

Distance alert: it warns the driver if their

vehicle is at risk of collision with the vehicle in
front or a pedestrian present in their traffic lane.

Intelligent emergency braking assistance:

it supplements the braking action taken by the
driver if this is inadequate.

Active Safety Brake: it intervenes following

the alert if the driver does not react quickly
enough and does not operate the vehicle's
brakes.

If the driver fails to act, it contributes

towards avoiding a collision or limiting

its severity by reducing the speed of your

vehicle.

Activation and operating conditions

The vehicle has a camera located at the top of
the windscreen, and depending on the version,
a radar located in the front bumpers.

The system is activated from about 4 mph
(7 km/h) and is deactivated below about 3 mph
(5 km/h).
It takes account of:
- registered vehicles running in the same

direction or stationary,

- pedestrians in the traffic lane (bicycles,

motorcycles, animals and objects on the
road are not necessarily detected).

This system is designed to assist the
driver and improve road safety.
It is the driver's responsibility to
continuously monitor the state of the
traffic, observing the driving regulations.
This system does not replace the need for
vigilance on the part of the driver.

Driving

Operating limits

In the following cases, deactivating the
system via the vehicle's configuration menu is
recommended:
- when towing a trailer,
- when carrying long objects on roof bars or

a roof rack,

- before using an automatic car wash, with

the engine running,

- before placing the vehicle on a rolling road

in a workshop,

- when the vehicle is being towed, with the

engine running,

- when a "space-saver" type spare wheel is

fitted (depending on version),

- following impact damage to the windscreen

close to the detection camera,

- if the front bumper has been damaged,
- if the brake lamps are not working.

Because of limits in the operation of the
system, it is possible that warnings are
not given, are given too late or seem
unjustified.
Consequently, the driver must always
remain attentive and able to react at any
time to avoid an accident.

Distance alert

Depending on the degree of risk of collision

detected by the system and the alert threshold

chosen by the driver, different levels of

alert can be triggered and displayed in the

instrument panel.

Level 1: visual alert only, signalling

that the vehicle in front is very close.
The message "

Vehicle close" is

displayed.

This level of alert is based on the inter-vehicle
time between your vehicle and the vehicle in
front.

Level 2: visual and audible alert,

warning you that a collision is
imminent.
The message "

Brake!" is displayed.

This level of alert is based on the time before
collision. It takes into account the vehicle
dynamics, the speed of your vehicle and the
one in front, the environmental conditions, the
operating conditions of the vehicle (on a curve,
pedals pressed, etc.) to trigger the alert at the
relevant moment.

Driving

Where the speed of your vehicle is too
high approaching another vehicle, the first
level of alert may not be displayed: the
level 2 alert may be displayed directly.

Important: alert level 1 is never displayed

when the "

Close" trigger threshold has

been selected.

Modifying the alert trigger

threshold

This threshold determines how you wish
to be alerted of the presence of a moving
or stationary vehicle in front of you, or a
pedestrian present in your traffic lane.
The current threshold can be modified via the
vehicle configuration menu.
You can select one of three thresholds:
- "

Distant",

- "

Normal",

- "

Close".

The last threshold selected is kept in memory
when the ignition is switched off.

Intelligent emergency

braking assistance

If the driver brakes, but not sufficiently to avoid
a collision, this system will supplement the
braking, within the limits of the laws of physics.
This assistance will only be provided if you
press the brake pedal.

Active Safety Brake

This function, also called automatic emergency
braking, aims to reduce the speed of impact or
avoid a frontal collision with your vehicle where
the driver fails to react.
Using a radar and a camera, depending on
the version, this function acts on the vehicle's
braking system.

Driving

If the camera and/or radar have
confirmed the presence of a vehicle
or a pedestrian, this warning lamp
flashes once the function is acting on
the vehicle's brakes.

Important: if operation of the

automatic emergency braking is
triggered, you must take back control
of your vehicle and

brake with the

pedal to supplement or finish the
automatic braking action.

The driver can take back control of the vehicle
at any time by sharply turning the steering
wheel and/or pressing the accelerator pedal.

The point at which braking is triggered
may be adjusted according to the reaction
from the driver, such as movement of the
steering wheel or pressing the accelerator
pedal.

Operation of the function may be felt by
slight vibration in the brake pedal.
If the vehicle comes to a complete stop,
the automatic braking is maintained for 1
to 2 seconds.

With a manual gear box, in the event of
automatic emergency braking until the
vehicle comes to a complete stop, the
engine may stall.
With an automatic gear box, in the event
of automatic emergency braking until
the vehicle comes to a complete stop,
maintain the brake pedal down to stop the
vehicle from starting off again.

Specific conditions for operation

The vehicle's speed must be between 3 mph
and 53 mph (5km/h and 85 km/h) (versions with
camera alone) or 87 mph (140 km/h) (versions
with camera and radar) when a moving vehicle
is detected.
The vehicle's speed must not exceed 50 mph
(80km/h) when a stopped vehicle is detected.
The vehicle's speed must not exceed 37 mph
(60 km/h) when a pedestrian is detected.
The ESC system must not be defective.
The CDS must not be deactivated.
All passengers seatbelts must be fastened.
Driving at steady speed on roads with few
bends is required.

After an impact, the function automatically
stops operating. Consult a PEUGEOT
dealer or a qualified workshop to have the
system checked.

Driving

Deactivation / Activation

By default, the system is automatically
activated at every engine start-up.
The system can be deactivated or activated via
the vehicle settings menu.

Deactivation of the system is
signalled by the illumination of this
indicator lamp, accompanied by the
display of a message.

Clean the windscreen regularly,
particularly the area in front of the camera.
Do not allow snow to accumulate on the
bonnet or roof of the vehicle as this could
conceal the detection camera.
Clean the front bumper, removing mud,
snow, etc.

If the front bumper is to be repainted or
retouched, contact a PEUGEOT dealer
or a qualified workshop. Certain types of
paint could interfere with the operation of
the radar.

Operating fault

Check that the sensors (camera and radar) are
not covered by dirt, mud, frost, snow, etc.
If the fault persists, contact a PEUGEOT dealer
or a qualified workshop to have the system
checked.

In the event of a fault with the system,
you are alerted by the tell-tale lighting
up, accompanied by the display of a
message and an audible signal.

The camera my be disrupted or not work
in the following situations:
- poor visibility (inadequate street

lighting, falling snow, heavy rain,
dense fog, etc.),

- dazzle (headlamps of an oncoming

vehicle, low sun, reflections on
a damp road, leaving a tunnel,
alternating shade and light, etc.),

- obstruction of the camera or radar

(mud, frost, snow, etc.).

In these situations, detection performance
may be reduced.

Technical data

Characteristics of engines and towed loads

Engines

The engine characteristics are detailed on the
vehicle's registration certificate, and in the
sales documentation.

Weights and towed loads

When the ambient temperature is high,
leaving the engine running for 1 to
2 minutes after stopping the vehicle to
allow it to cool is recommended.

The weights and towed loads relating to your
vehicle are stated in the registration certificate,
and in the sales documentation.
These values are also shown on the
manufacturer's nameplate or label.
For more information, contact a PEUGEOT
dealer or a qualified workshop.

The GTW and towed load values indicated are
valid up to a maximum altitude of 1,000 metres.
The towed load value must be reduced by 10%
for each additional 1,000 metres of altitude.
The recommended nose weight corresponds
to the weight permitted on the towbar
(dismantlable with or without a tool).

GTW: Gross train weight

High ambient temperatures may result
in a reduction in the performance of
the vehicle to protect the engine. If the
ambient temperature is above 37°C, limit
the towed load.

Towing with a towing vehicle which is only
slightly laden may negatively affect its
handling.
Towing a trailer increases the braking
distance.
With a towing vehicle, never exceed the
speed of 62 mph (100 km/h) (observe the
local legislation in force).

The maximum power corresponds to
the value type-approved on a test bed,
according to the conditions defined in
European legislation (Directive 1999/99/
EC).

For more information, contact a PEUGEOT
dealer or a qualified workshop.

Technical data

Petrol engines and towed loads

Engines

1.2 litre PureTech

130 S&S

1.2 litre PureTech

130 S&S

1.6 litre THP 150

1.6 litre THP 160

1.6 litre THP 165

S&S

Gearboxes

BVM6

(Manual 6-speed)

EAT6

(Auto. 6-speed)

EAT6

(Auto. 6-speed)

EAT6

(Auto. 6-speed)

EAT6

(Auto. 6-speed)

Codes

EB2DTS MCM

STT

EB2DTS AT6III

STT

EP6FDTM AT6III

EP6FDTMD

AT6III

EP6FDT AT6III

STT

Model codes
MR... M4...

HNYH/C1B
HNYH/C1F

HNYH/C1K

HNYW/C1B
HNYW/C1F

5GYW/C1A

5GXV/C1A

5GZW/C1B
5GZW/C1F

Cylinder capacity (cm³)

1,199

1,598

Max power: EU standard (kW)

110

120

121.4

Fuel

Unleaded

Braked trailer (within the GTW limit) (kg)
on a 10% or 12% gradient

1,400 - 1,300

1,200

600

1,550

Unbraked trailer (kg)

660

670

600

685

Recommended nose weight (kg)

Peugeot 3008 Hybrid 4 (2017 year). Instruction - part 35
