Peugeot 1007 Dag (2008.5). Instruction

184

The trafﬁ c announcement

(TA) is displayed. I do

not receive any trafﬁ c
information.

Tune to a radio station which broadcasts trafﬁ c
information.

The radio station is not part of the regional trafﬁ c information network.

QUESTION

SOLUTION

RESPONSE

The quality of reception
of the radio station

listened to gradually
deteriorates or the
stored stations do

not function (no

sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened to or

there is no transmitter in the geographical area through which the vehicle

is travelling.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Activate the RDS function to enable the system
to check whether there is a more powerful

transmitter in the geographical area.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1
to 2 seconds in radio
mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon
is too frequent and always on the same route.

With the engine off,
the audio equipment
switches off after a few
minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

The stored stations do

not function (no sound,

87.5 Mhz is displayed...)

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the
stations are stored.

The message "the audio

system is overheated"
appears on the display.

Switch the audio system off for a few minutes to
allow the system to cool.

In order to protect the installation if the surrounding temperature is too

high, the audio equipment switches to an automatic thermal protection

mode leading to a reduction of the volume or stopping of the playing of the
CD.

185

QUESTION

SOLUTION

RESPONSE

The TRAFFIC INFO

box is ticked. However,

certain trafﬁ c jams

along the route are not
indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways, ...) are listed for the

trafﬁ c information.

The time taken to
calculate a route
sometimes seems

longer than usual.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

The performance of the system may slow down temporarily if a CD is

being copied onto the Jukebox at the same time as a route is being
calculated.

Wait until the CD has been copied or stop the

copying before starting the guidance function.

Does the emergency call
function work without a

SIM card?

No, European regulations impose the presence of a SIM card in order to

make an emergency call.

Insert a valid SIM card in the slot on the WIP Com.

My SIM card is not

recognised.

The WIP Com accepts 3.3 V SIM cards, the old 5 V and 1.8 V SIM cards

are not recognised.

Contact your telephone operator.

After changing a wheel,
the system loses its
location.

The WIP Com uses the wheel rotation information to improve the GPS

locating function. If a wheel is changed or deﬂ ates suddenly, the system
recalculates the location. For approximately ten minutes, this recalculation

may affect the quality of the locating function.

The altitude is not displayed.
Wait until the system has completed its
recalculation.

The table below groups together the answers to the most frequently asked questions concerning the WIP Com.

The location on the
map is incorrect or
inaccurate.

On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

4 satellites (long press on the MENU button, then

select AUDIO/TELEPHONE DIAGNOSTICS, then

GPS COVERAGE).

Depending on the geographical environment (tunnel, ...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is
dependent on the conditions of reception of the

GPS signal.

169

WIP Sound

CONTENTS

• 01 First steps

pg. 170

• 02 General menu

pg. 171

• 03 Audio

pg. 172

• 04 USB reader

pg. 175

• 05 Hands-free kit

pg. 178

• 06 Control short-cuts

pg. 179

• 07 Conﬁ guration

pg. 180

• 08 Display ﬂ ow charts

pg. 181

• Frequently asked questions pg. 183

The WIP Sound is coded in such a way that it will only
operate in your vehicle. If it is to be installed in another

vehicle, contact a PEUGEOT dealer for conﬁ guration of
the system.

For safety reasons, the driver must carry out operations

which require prolonged attention while the vehicle is
stationary.

When the engine is off, and in order to prevent

discharging of the battery, the WIP Sound may switch off
after a few minutes.

AUDIO EQUIPMENT/HANDS-FREE KIT

170

01 FIRST STEPS

On/Off and volume adjustment.

CD eject.

Selection of the display on the screen from the modes:

Audio (AUDIO), Trip Computer (TRIP) and Hands-Free Kit

(TEL) functions.

Selection of the source: radio, audio CD/MP3 CD,

CD changer, USB, Jack connection.

5. Selection of the FM1, FM2, FMast and AM wavebands.

Setting the audio options: front/rear balance, left/right

balance, loudness, sound ambiences.

Displaying of the list of local stations, of the tracks on the CD

or of the MP3 directories.

Abandon current operation.

9. TA (Trafﬁ c Announcement) function on/off.

Long press: access to the PTY

(TYpes of radio Programme) mode.

10.

Conﬁ rmation.

11.

Automatic search for a lower/higher frequency.

Selection of previous/next CD, MP3 or USB track.

12.

Selection of a lower/higher radio frequency.

Selection of the previous/next CD.

Selection of the previous/next MP3 directory.

Selection of the previous/next USB equipment

directory/genre/artist/playlist.

13.

Displaying of the general menu.

14. Buttons 1 to 6:

Selection of a stored radio station.

Selection of a CD in the CD changer.

Long press: storing of a station.

15. The DARK button changes the display on the screen

to improve driving comfort at night.

1st press: lighting of the top banner only.

2nd press: displaying of a black screen.

3rd press: return to the standard display.

172

03 AUDIO

Press the SOURCE button several
times in succession and select the
radio.

Press the BAND AST button to select

a waveband: FM1, FM2, FMast, AM.

Brieﬂ y press one of the buttons to
carry out an automatic search of the
radio stations.

Press one of the buttons to carry out a
manual search of the radio stations.

Press the LIST REFRESH button to
display the list of stations received

locally (30 stations maximum).
To update this list, press for more than
two seconds.

Select ACTIVATE FREQUENCY

FOLLOWING (RDS) then press OK.
RDS appears on the display.

Select the FM WAVEBAND
PREFERENCES function then press
OK.

Select AUDIO FUNCTIONS then
press OK.

Press the MENU button.

FM WAVEBAND PREFERENCES

ACTIVATE FREQUENCY FOLLOWING (RDS)

The external environment (hills, buildings, tunnels, basement car parks) may block reception, including
in RDS mode. This is a normal effect of the way in which radio waves are transmitted and does not

indicate any failure of the audio equipment.

RDS

The RDS, if displayed, enables you to continue listening to the

same station by means of frequency following. However, in certain

conditions, this RDS station is not followed throughout the country
as radio stations do not cover 100 % of the territory. This explains

the loss of reception of the station during a journey.

RADIO

SELECTING A STATION

173

Insert circular compact discs only.

Some anti-pirating systems, on original discs or CDs

copied using a personal recorder, may cause faults

which are no reﬂ ection on the quality of the original
player.

Without pressing the EJECT button, insert a CD in the

player, play begins automatically.

To play a disc which has already been
inserted, press the SOURCE button
several times in succession and select
CD.

Press one of the buttons to select a
track on the CD.

Press the LIST REFRESH button to
display the list of tracks on the CD.
Press and hold one of the buttons for
fast forward or backward play.

Insert an MP3 compilation in the player.
The audio equipment searches for all of the music

tracks, which may take anything between a few seconds

and several tens of seconds, before play begins.

On a single disc, the CD player can read up to 255 MP3 ﬁ les spread

over 8 directory levels. However, it is advisable to keep to a limit of
two levels to reduce the access time before the CD is played.

While the CD is being played, the directory ﬂ ow chart is not followed.

All of the ﬁ les are displayed on a single level.

To play a disc which has already been
inserted, press the SOURCE button
several times in succession and
select CD.

Press one of the buttons to select a
track on the CD.

Press the LIST REFRESH button to
display the list of directories of the
MP3 compilation.
Press and hold one of the buttons for
fast forward or backward play.

PLAYING A CD

MP3 CD

PLAYING AN MP3 COMPILATION

174

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3,

is an audio compression standard which permits the recording of

several tens of music ﬁ les on a single disc.

The playing and displaying of an MP3 compilation may depend on

the recording programme and/or the parameters used.

In order to be able to play a recorded CDR or CDRW, when recording
select standards ISO 9660 level 1.2 or Joliet.
If the disc is recorded in another format, it may not be played
correctly.

It is recommended that the same recording standard is always used
for an individual disc, with as low a speed as possible for optimum
sound quality.
In the particular case of a multi-session CD, the Joliet standard is
recommended.

The audio equipment will only play ﬁ les with the extension ".mp3".

No other type of ﬁ le (.wma, .mp4...) can be played.

It is advisable to restrict ﬁ le names to 20 characters without using

special characters (e.g.: " " ? ; ù) to avoid any playing or displaying
problems.

Insert the CDs in a multi-slot changer
one by one.

On a single slot changer, press

LOAD, select the number of the CD,
then insert the CD, or press and hold

LOAD and insert the CDs one by one.

Press the SOURCE button several
times in succession and select CD

CHANGER.

Press one of the buttons on the
numeric keypad to select the

corresponding CD.

Press one of the buttons to select a
track on the CD.
Press and hold one of the buttons for
fast forwards or backwards play.

MP3 CD

INFORMATION AND ADVICE

AUDIO/MP3 CD CHANGER *

PLAYING A CD

* according to availability on the vehicle.

175

04 USB PLUG - READER

The other sources are available during this time.

The playlists are updated each time the ignition is switched off or
each time a USB stick is connected.

When connecting for the ﬁ rst time, the tracks are classiﬁ ed by folder.

When you reconnect, the classiﬁ cation system selected previously is
retained.

Insert a USB stick or connector in the

space provided, play begins automatically
after a delay which depends on the
capacity of the USB stick.

The ﬁ le formats recognised are .mp3

(mpeg1 layer 3 only), .wma (standard 9

only), .wav and .ogg.

The system puts together playlists

(temporary memory) created over a
period which depends on the capacity of
the USB equipment.

Press and hold LIST to display the

different classiﬁ cations.

Select by Folder/Artist/Genre/Playlist,

press OK to select the classiﬁ cation

required, then press OK again to conﬁ rm.

- by Folder: all folders containing audio

ﬁ les recognised on the peripheral

device, classiﬁ ed in alphabetical order

without following the ﬂ ow chart.

- by Artist: all of the artist names

deﬁ ned in the ID3 Tags, classiﬁ ed in
alphabetical order.

- by Genre: all of the genres deﬁ ned in

the ID3 Tags.

- by Playlist: in accordance with the

playlists recorded on the USB device.

This equipment reads 1.1, 1.2 and 2.0 USB sticks, as well as iPods

of generation 5 or later via a

USB connector.

IPods

earlier than generation 5 must be connected via the JACK socket.

The list of compatible equipment is available from PEUGEOT dealers.

The playlists accepted are .m3u, .pls and .wpl.

USING THE USB SOCKET

USB CONNECTION

176

USB PLUG - READER

USING THE USB SOCKET

Press LIST to display the list of

Folders/Genres/Artists/Playlists on
the USB equipment.

The lists available are Artist, Genre and Playlist

(as deﬁ ned on the iPod

The operation is identical to that of a conventional USB peripheral
device.

Do not connect a hard disc or USB devices other than audio

equipment to the USB socket. This could damage your installation.

CONNECTING AN IPOD

VIA THE USB SOCKET

Press one of these buttons to gain
access to the previous/next track on

the classiﬁ cation list currently being
played. Press and hold one of the
buttons for fast forward or backward
play.

Press one of these buttons to gain
access to the previous/next Genre,

Folder, Artist or Playlist on the

classiﬁ cation list currently being
played.

Navigate through the list using

the left/right and up/down buttons.

Conﬁ rm the selection by pressing OK.

177

The controls are displayed and managed via the
portable equipment.

First adjust the volume of your portable equipment.

Then adjust the volume of your audio
equipment.

The auxiliary input, JACK and RCA, permits the connection

of portable equipment (MP3 player...).

Connect the portable equipment (MP3

player…) to the JACK socket or to the

audio sockets (white and red, RCA type)

using a suitable cable.

Press the SOURCE button several

times in succession and select AUX.

USING THE AUXILIARY INPUT (AUX)

JACK/RCA CABLE NOT SUPPLIED

ADJUSTING THE VOLUME
OF THE AUXILIARY SOURCE

Do not connect a single piece of equipment via the USB socket and

the JACK socket at the same time.

178

HANDS-FREE KIT *

For safety reasons and because they require prolonged attention on

the part of the driver, the operations for matching of the Bluetooth
mobile telephone with your WIP Sound hands-free kit must be

carried out with the vehicle stationary and the ignition on.

Select the accessory which corresponds to the

name of the vehicle, a superimposed conﬁ guration
display appears on the multifunction display.

Activate the telephone's Bluetooth function and
carry out a search of the Bluetooth accessories
present for the telephone.

Select the YES tab on the display using

the buttons then conﬁ rm by pressing OK.

Enter the vehicle's authentication code (=1234).

Depending on the telephone, you may be asked
to enter this code before the superimposed

conﬁ guration display appears.

YES

The services offered by the hands-free kit depend on the network, the SIM card and the compatibility

of the Bluetooth equipment used.
Consult your telephone's manual and your operator to ﬁ nd out which services are available to you. A
list of mobile telephones which offer the best range of services is available from the network. Consult
a PEUGEOT dealer.

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed display
on the multifunction display.

Select the YES tab on the display

using the buttons and conﬁ rm by

pressing OK.

Press the end of the steering wheel stalk to accept
the call.

Press the end of the steering wheel stalk for more
than two seconds to access your directory.

To dial a number, use the keypad on your
telephone.

MAKING A CALL

MATCHING A TELEPHONE

DISPLAY C

The TELEPHONE menu permits access to the following functions in

particular: Phone book, Call list, Matching management.

* according to availability on the vehicle.

179

RADIO: selection of the next stored station.

CD CHANGER: selection of the next CD.

USB: selection of the next genre/artist/directory

from the classiﬁ cation list.
Selection of the next item on a menu.

RADIO: selection of the previous stored station.

CD CHANGER: selection of the previous CD.

USB: selection of the previous genre/artist/directory

from the classiﬁ cation list.
Selection of the previous item on a menu.

RADIO: automatic search for a higher frequency.

CD/CD CHANGER/MP3/USB: selection of the next
track.

CD/CD CHANGER/USB: continuous press: fast
forwards play.
Selection of the previous item.

RADIO: automatic search for a lower frequency.

CD/CD CHANGER/MP3/USB: selection of the previous
track.

CD/CD CHANGER/USB: continuous press: fast
backwards play.
Selection of the next item.

Volume increase.

Volume decrease.

CONTROL SHORT-CUTS

Mute: by pressing
the volume increase
and decrease buttons
simultaneously.

The sound is restored by

pressing one of the two
volume buttons.

- Change of sound source.

- Conﬁ rmation of a selection.

- Pick up/Hang up the telephone.
- Press for more than 2 seconds:

access to the telephone menu.

STEERING WHEEL CONTROLS

180

07 CONFIGURATION

Press the MENU button.

Using the arrows, select

the PERSONALISATION

CONFIGURATION function.

Press to conﬁ rm the selection.

Using the arrows, select the

DISPLAY CONFIGURATION function.

Press to conﬁ rm the selection.

Using the arrows, select the

ADJUST DATE AND TIME function.

Adjust the parameters one by one

conﬁ rming by pressing the OK button.
Next select the OK tab on the display

then conﬁ rm.

DISPLAY CONFIGURATION

ADJUST DATE AND TIME

PERSONALISATION CONFIGURATION

ADJUSTING THE DATE AND TIME

DISPLAY C

181

RADIO-CD

DISPLAY ADJUST

YEAR

MONTH

DAY

HOUR

MINUTES

12 H/24 H MODE

DISPLAY FLOW CHART

MAIN FUNCTION

* The parameters vary according to vehicle

(refer to the "Multifunction displays" chapter).

CHOICE A

Choice A1

Choice A2

CHOICE B...

LANGUAGES

FRANCAIS

ITALIANO

NEDERLANDS

PORTUGUES

PORTUGUES-BRASIL

DEUTSCH

ENGLISH

ESPANOL

Press the OK dial to gain access to short-

cut menus according to the display on the
screen:

monochrome A

monochrome C

RADIO

activate/deactivate RDS

activate/deactivate REG mode

activate/deactivate radiotext

CD/MP3 CD

activate/deactivate Intro

activate/deactivate track repeat

Audio CD/Changer: the entire CD

MP3 CD/MP3 Changer: the entire current folder

activate/deactivate random play

Audio CD/Changer: the entire CD

MP3 CD: the entire current folder

MP3 Changer: all of the folders

USB

activate/deactivate track repeat

current folders/artist/genre/playlist

activate/deactivate random play

current folders/artist/genre/playlist

RDS SEARCH

REG MODE

CD REPEAT

RANDOM PLAY

VEHICLE CONFIG *

REV WIPE ACT

GUIDE LAMPS

OPTIONS

DIAGNOSTICS

consult

abandon

UNITS

TEMPERATURE: °CELSIUS/°FAHRENHEIT

FUEL CONSUMPTION: KM/L - L/100 - MPG

Peugeot 1007 Dag (2008.5). Instruction - part 12
