Peugeot 807 (2013 year). Instruction - part 14

9.69

USING THE PEUGEOT CONNECT USB

Press LIST briefl y to display the

previously selected classifi cation.
Navigate through the list using the left/

right and up/down buttons.
Confi rm the selection by pressing OK.

The lists available are Artist, Genre and Playlist (as defi ned in the

Apple

player).

Selection and Navigation are described in steps 1 to 4 above.

Do not connect a hard disk or USB connection device other

than audio equipment to the USB port. This could damage your

installation.

CONNECTING AN APPLE

PLAYER VIA THE USB PORT

Press one of these buttons to gain

access to the previous / next track on

the classifi cation list currently being

played.
Press and hold one of the buttons for

fast forward or backward play.

Press one of these buttons to

gain access to the previous / next

Genre, Folder, Artist or Playlist on

the classifi cation list currently being

played.

Press and hold LIST to display the

different classifi cations.
Select by Folder / Artist / Genre / Playlist,

press OK to select the classifi cation

required, then press OK again to confi rm.

by Folder: all folders containing audio

fi les recognised on the peripheral

device.

by Artist: all of the artist names

defi ned in the ID3 Tags, classifi ed in

alphabetical order.

by Genre: all of the genres defi ned in

the ID3 Tags.

by Playlist: in accordance with the

playlists recorded on the USB device.

USB PLAYER

9.70

The display and control is via the portable device.

First adjust the volume of your portable device.

Then adjust the volume of your audio

system.

USING THE AUXILIARY INPUT (AUX)

ADJUSTING THE VOLUME OF THE

AUXILIARY SOURCE

JACK socket or USB port (according to vehicle)

USB PLAYER

Do not connect a device to both the JACK socket and the USB

port at the same time.

Connect the portable device

(MP3 player…) to the JACK socket or to

the USB port, using a suitable cable (not

supplied).

Press the SOURCE button several

times in succession and select AUX.

The auxiliary input, JACK or USB, allows the connection of a

portable device (MP3 player…).

9.71

06 BLUETOOTH

For safety reasons and because they require prolonged attention

on the part of the driver, the operations for pairing of the Bluetooth

mobile telephone with the Bluetooth hands-free system of your

audio equipment must be carried out with the vehicle stationary

and the ignition on.

Press the MENU button.

A window is displayed with a message that a search is in progress.

Activate the telephone's Bluetooth function

and ensure that it is "visible to all" (telephone

confi guration.

In the menu, select:
- Bluetooth

telephone

function -

Audio

- Bluetooth

confi guration

Perform a Bluetooth search

The services offered depend on the network, the SIM card and the

compatibility of the Bluetooth equipment used.
Consult your telephone's manual and your operator to fi nd out which

services are available to you.

BLUETOOTH TELEPHONE

SCREEN C

The TELEPHONE menu permits access to the following functions

in particular: Directory * , Call list, Pairing management.

The fi rst 4 telephones recognised are displayed in this window.

A virtual keypad is displayed in the

screen: enter a code with at least 4 digits.
Confi rm by pressing OK.

A message that the pairing has been successful appears in the

screen.

Select the telephone to be connected from the list. Only one

telephone can be connected at a time.

A message is displayed in the screen of the

telephone chosen. To accept the pairing, enter the

same code on the telephone, then confi rm with OK.

The automatic connection authorised is only active after the

telephone has been confi gured.
The directory and the call list can be accessed after the

synchronisation period.

(Available according to model and version)

* If your telephone is fully compatible.

If pairing fails, the number of attempts is not limited.

Go to www.peugeot.co.uk for more information (compatibility, more

help, …).

PAIRING A TELEPHONE / FIRST CONNECTION

9.72

RECEIVING A CALL

An incoming call is announced by a ring and a superimposed

display in the vehicle's screen.

Select the YES tab on the display

using the buttons and confi rm by

pressing OK.

Press this button to accept the call.

MAKING A CALL

From the Bluetooth telephone function Audio menu, select Manage

the telephone call then Call, Call list or Directory.

Press this button for more than two seconds for

access to your directory, then navigate with the

thumb wheel.
Or
To dial a number, use your telephone's keypad,

with the vehicle stationary.

During a call, press this button for more than

2 seconds.
Confi rm with OK to end the call.

BLUETOOTH

ENDING A CALL

9.73

Initiate the pairing between the telephone and

the vehicle. This pairing can be initiated from

the vehicle's telephone function menu or via the

telephone's keypad. See steps 1 to 9 on the

previous pages. During the pairing phase, the

vehicle must be stationary with the key in the

ignition.

Select the telephone to be connected from the telephone function

menu.
The audio system connects to a newly paired telephone

automatically.

BLUETOOTH AUDIO STREAMING *

Wireless transmission of the telephone's music fi les via the audio

equipment. The telephone must be able to manage the appropriate

Bluetooth profi les (Profi les A2DP / AVRCP).

* Depending on the compatibility of the telephone.
** In certain cases, playing of the Audio fi les must be initiated from the

keypad.

*** If the telephone supports the function.

Activate the streaming source by

pressing the SOURCE button ** .

The tracks to be played can be

controlled as usual via the buttons on

the audio system control panel and

the steering mounted controls *** .

The contextual information can be

displayed on the screen.

BLUETOOTH

9.74

07 CONFIGURATION

Press the MENU button.

Using the arrows, select

PERSONALISATION

CONFIGURATION.

Press to confi rm the selection.

Using the arrows, select DISPLAY

CONFIGURATION.

Press to confi rm the selection.

Using the arrows, select ADJUST

DATE AND TIME.

Adjust the settings one by one

confi rming by pressing the OK

button. Next select the OK tab on the

screen then confi rm.

SETTING THE DATE AND TIME

SCREEN C

9.75

TRIP COMPUTER

Each press of the button, located at the end of the

wiper stalk, displays the different trip computer

information in succession, depending on the screen.

the "vehicle" tab with:

● the range, the current fuel consumption and the distance

remaining to the destination,

the "1" tab (trip 1) with:

● the average speed, the average consumption and the distance

travelled calculated over trip "1" ,

the "2" tab (trip 2) with the same information for a second trip.

A FEW DEFINITIONS

Range: displays the distance which can travelled with the remaining fuel

detected in the tank, basd on the average consumption over the last few

miles (kilometres).
This displayed value may vary signifi cantly following a change in the

vehicle speed or the relief of the route.
When the range falls below 20 miles (30 km), dashes are displayed.

After fi lling with at least 10 litres of fuel, the range is recalculated and is

displayed when it exceeds 60 miles (100 km).
If, whilst driving, dashes are displayed continuously in place of the digits,

contact a PEUGEOT dealer.

Current fuel consumption: only calculated and displayed above

20 mph (30 km/h).

Average fuel consumption: this is the average fuel consumption since

the last trip computer zero reset.

Distance travelled: calculated since the last trip computer zero reset.

Distance remaining to the destination: calculated with reference to

the fi nal destination, entered by the user. If guidance is activated, the

navigation system calculates it as a current value.

Average speed: this is the average speed calculated since the last trip

computer zero reset (ignition on).

Zero reset
When the required trip is displayed, press the control for more than

two seconds.

VEHICLE DIAGNOSTICS

9.76

09 SCREEN MENU MAP

RADIO-CD

MAIN FUNCTION

* The parameters vary according to vehicle.

OPTION A

OPTION B…

MONOCHROME A

OPTION A1

OPTION A2

REG MODE

CD REPEAT

RANDOM PLAY

VEHICLE CONFIG *

REV WIPE ACT

OPTIONS

GUIDE LAMPS

DIAGNOSTICS

RDS SEARCH

CONSULT

ABANDON

9.77

TEMPERATURE: °CELSIUS / °FAHRENHEIT

FUEL CONSUMPTION: KM/L -

L/100 - MPG

SCREEN MENU MAP

DISPLAY ADJUST

MONTH

DATE

HOUR

MINUTES

YEAR

12 H/24 H MODE

LANGUAGE

ITALIANO

NEDERLANDS

PORTUGUES

PORTUGUES-BRASIL

FRANCAIS

DEUTSCH

ENGLISH

ESPANOL

9.78

09 SCREEN MENU MAP

Press the OK dial for access to short-cut menus according to the display

on the screen:

MONOCHROME C

activate / deactivate RDS

activate / deactivate REG mode

activate / deactivate radiotext

RADIO

activate / deactivate Intro

CD / MP3 CD

activate / deactivate track repeat (the

entire current CD for CD, the entire

current folder for MP3 CD)

activate / deactivate random play (the

entire current CD for CD, the entire

current folder for MP3 CD)

activate / deactivate track repeat (of the

current folder / artist / genre / playlist)

USB

activate / deactivate random play (of the

current folder / artist / genre / playlist)

9.79

09 SCREEN MENU MAP

MONOCHROME C

AUDIO FUNCTIONS

alternative frequencies (RDS)

activate / deactivate

FM BAND PREFERENCES

regional mode (REG)

activate / deactivate

radio-text information (RDTXT)

activate / deactivate

PLAY MODES

album repeat (RPT)

activate / deactivate

track random play (RDM)

activate / deactivate

TRIP COMPUTER

Distance: x miles

ENTER DISTANCE TO DESTINATION

Diagnostic s

ALERT LOG

Functions activated or deactivated

STATUS OF THE FUNCTIONS *

Pressing the MENU button displays:

* The parameters vary according to vehicle.

9.80

09 SCREEN MENU MAP

BLUETOOTH TELEPHONE

Connect/Disconnect a device

Consult the paired device

BLUETOOTH CONFIGURATION

Telephone function

Audio Streaming function

Delete a paired device

Perform a Bluetooth search

Calls list

CALL

Directory

Terminate the current call

MANAGE THE TELEPHONE CALL

Activate private mode

video brightness adjustment

DISPLAY CONFIGURATION

DEFINE THE VEHICLE PARAMETERS *

PERSONALISATION-CONFIGURATION

normal video

inverse video

brightness (- +) adjustment

date and time adjustment

day/month/year adjustment

hour/minute adjustment

choice of 12 h / 24 h mode

choice of units

l/100 km - mpg - km/l

°Celsius / °Fahrenheit

CHOICE OF LANGUAGE

* The parameters vary according to vehicle.

9.81

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between the

different audio sources

(radio, CD…).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources, which

may result in audible differences when changing source (radio, CD…).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to the

sources listened to. It is advisable to set the AUDIO

functions (Bass, Treble, Front-Rear Balance, Left-

Right Balance) to the middle position, select the

musical ambience "None" and set the loudness

correction to the "Active" position in CD mode or to

the "Inactive" position in radio mode.

The CD is ejected

automatically or is not

played by the player.

The CD is inserted upside down, is unplayable, does not contain any audio

data or contains an audio format which the player cannot play.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

Check that the CD is inserted in the player the

right way up.

Check the condition of the CD: the CD cannot

be played if it is too damaged.

Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

The audio equipment's CD player does not

play DVDs.

Due to their quality level, certain writeable CDs

will not be played by the audio system.

The message "USB

peripheral error" is

displayed on the screen.
The Bluetooth connection

is cut.

The battery of the peripheral may not be suffi ciently charged.

Recharge the battery of the peripheral device.

The USB memory stick is not recognised.
The memory stick may be corrupt.

Reformat the memory stick.

The CD player sound is

poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

9.82

QUESTION

ANSWER

SOLUTION

The stored stations do

not function (no sound,

87.5 Mhz is displayed…).

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The traffi c announcement

(TA) is displayed. I do

not receive any traffi c

information.

The radio station is not part of the regional traffi c information network.

Tune to a radio station which broadcasts traffi c

information.

The quality of reception of

the radio station listened

to gradually deteriorates

or the stored stations do

not function (no sound,

87.5 Mhz is displayed…).

The vehicle is too far from the transmitter used by the station listened to or

there is no transmitter in the geographical area through which the vehicle is

travelling.

Activate the RDS function to enable the system to

check whether there is a more powerful transmitter

in the geographical area.

The environment (hills, buildings, tunnels, basement car parks…) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off, the

audio equipment switches

off after a few minutes

of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.
The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

The message "the audio

system is overheated"

appears on the display.

In order to protect the installation if the surrounding temperature is too high,

the audio equipment switches to an automatic thermal protection mode

leading to a reduction of the volume or stopping of the playing of the CD.

Switch the audio system off for a few minutes to

allow the system to cool.

139

ISUAL

SEARCH

Exterior

Spare wheel, jack, changing,

fi tting

117-120

Rear lamps, direction indicators,

3rd brake lamp

43-45, 123

Changing rear bulbs

122-123

Accessories 107
Sun roof

Roof bars

105

Fuel fi ller cap

109

Fuel tank

31, 109

Fuel cut-off/priming

110

Boot, tailgate

Parking sensors

Towing, lifting

131

Towbar 103-104

Brakes 86,

88-89

ABS, EBFD

ASR, ESP

Tyre under-infl ation detection

Opening/closing doors

23-24

Locks 18
Opening/closing the bonnet

111

Electric child lock

Wiper blade

46, 130

Door mirror

Front lamps/foglamps,

direction indicators

43-45

Headlamp beam

height adjustment

Headlamp wash

46, 114

Changing front bulbs

121-122

Very cold climate screen

106

Key, starting, battery

18-21, 42

Central locking

18, 23

Alarm 22

EXTERIOR

Infl ating, pressure

Tyres, pressure

140

Interior

Rear fi ttings

78-79

- stowing

rings,

- storage

tray,

  -   load space cover,
  -  hooks,
  -   luggage retaining net,
  -  grab

handle,

- coat

hook,

- bottle/can

holder,

- accessories

socket.

Boot, tailgate

Rear windows

Side blinds

Front seats

59-63, 75

- head

restraint,

- electric

controls,

- manual

controls.

Courtesy lamp, interior lighting 80

Seat belts

91-92

Airbags 93-96

Battery 116
Battery fuses

126-127

Economy mode

116

Front fi ttings

76-77

- storage

tray,

- glove

box,

- cooled

compartment,

- bottle/cup

holder,

- accessories

socket,

- mat,
- storage

compartment.

Isofi x mountings

98-99

Electric child lock

Rear seats, bench seat

64-70

- head

restraint,

- writing

table.

Child seats

97-102

Confi guration, modularity

71-73

INTERIOR

Content .. 12 13 14 15 ..
