Peugeot 607 Dag (2009 year). Instruction

144

You can connect video equipment (camcorder, digital camera, DVD player...) to the three audio/video
sockets, located in the glove box.

Turn the dial and select the VIDEO

function.

After connecting the video equipment,

press the MENU button.

Turn the dial and select the

ACTIVATE VIDEO MODE function to

activate/deactivate the video.

Press the dial to conﬁ rm the selection.

Pressing the "SOURCE" button several times in succession permits

the selection of an audio source other than that of the video.

Pressing the "DARK" button disconnects display of the video.

Turn the dial and select the VIDEO

PARAMETERS function to set the

display format, the brightness, the

contrast and the colours.

Press the dial to conﬁ rm the selection.

VIDEO MENU

Videos can only be displayed when stationary.

ACTIVATE VIDEO MODE

PARAMETRES VIDEO

145

06 INTERNAL TELEPHONE

ENTERING THE PIN CODE

Open the slot by pressing the button

using the tip of a pen.

Install the SIM card
in the holder and
then insert it in the

slot.

To remove the SIM card, repeat step 1.

Your SIM card must be installed and removed with the PC Com

audio and telematics system switched off and the ignition off.

Enter the PIN code on the keypad.

Conﬁ rm the PIN code by pressing

button #.

When entering your PIN code, tick the STORE PIN tab for access

to the telephone without having to enter this code when it is used

subsequently.

INSTALLING YOUR SIM CARD

(NOT SUPPLIED)

PIN CODE

146

The services offered by the telephone depend on the network, the SIM card and the compatibility of
the Bluetooth equipment used. Refer to your telephone’s manual and your operator to check which
services you have access to. A list of mobile telephones which offer the best range of services is
available from dealers.

BLUETOOTH TELEPHONE

CONNECTING A BLUETOOTH
TELEPHONE

For reasons of safety, the driver should only carry out operations

which require prolonged attention when the vehicle is stationary

(pairing the Bluetooth mobile telephone to the hands-free kit).

Activate the telephone’s Bluetooth function.
The last telephone connected is reconnected

automatically.

Select BLUETOOTH ACTIVATION

MODE, then ACTIVATED AND

VISIBLE. Press the dial to conﬁ rm

each operation.

Press the MENU button, select

TELEMATICS, then BLUETOOTH

FUNCTIONS. Press the dial to

conﬁ rm each operation.

On your telephone, select the name

of the PEUGEOT audio/telephone.

Enter the authentication code (0000

by default).

To ﬁ nd and change the name of the PEUGEOT audio/telephone,

repeat step 2 then select CHANGE AUDIO/TELEPHONE NAME.

TELEMATICS

BLUETOOTH FUNCTIONS

BLUETOOTH ACTIVATION MODE

ACTIVATED AND VISIBLE

147

The call list consists of calls made from the vehicle’s audiotelephone

only.

Once the telephone has been connected, the system can

synchronise the address book and the call list. Repeat step 2 then

select PHONE BOOK SYNCHRONISATION MODE. Select the

synchronisation of your choice and press the dial to conﬁ rm.

The synchronisation may take a few minutes.

To change the telephone connected, repeat step 2 then select LIST

OF MATCHED TELEPHONES and press OK to conﬁ rm. The list of

previously connected telephones (10 maximum) appears. Select the

telephone of your choice, conﬁ rm, then select CONNECT and press

the dial to conﬁ rm.

To change the authentication code, repeat step 2 then select

AUTHENTICATION CODE and save the code of your choice.

BLUETOOTH TELEPHONE

CONNECTING A BLUETOOTH
TELEPHONE

148

06 TELEPHONE

CALLING A CONTACT

Select CALL LIST or PHONE BOOK and press OK. Select the

number required and conﬁ rm to make the call.

Press the PICK UP button to display

the telephone short-cut menu.

Press the dial to conﬁ rm the

selection.

Press the PICK UP button to call the

number dialled.

Press the HANG UP button to end

the call.

ACCEPTING OR REFUSING A CALL

Press the PICK UP button to accept

a call.

Press the HANG UP button to refuse

a call.

Press the end of the steering wheel stalk for more

than 2 seconds to access the telephone menu:

calls log, directory, voice mailbox.

To select the telephone used, press MENU, then select TELEMATICS, then BLUETOOTH
FUNCTIONS, then BLUETOOTH ACTIVATION MODE. Then select:
   -   DEACTIVATED: to use the internal telephone,
  -   ACTIVATED AND VISIBLE: to use the bluetooth telephone, visible to all telephones,
  -    ACTIVATED AND NOT VISIBLE: to use the bluetooth telephone, not visible to other telephones,
  it is not possible to match a new telephone.

Turn the dial and select the DIAL

function.

Dial the telephone number of your

contact using the alphanumeric

keypad.

DIAL

149

EMERGENCY CALL

In an emergency, press the SOS button

until a CONFIRMATION/CANCELLATION

screen is displayed.

A call is made to the emergency services * .
In certain countries, this call is made

directly by the PEUGEOT Emergency team

which receives locating information from
the vehicle and can send a detailed alert to

the appropriate emergency services. In the
other countries, the call is directed to the

emergency services (112).

PEUGEOT ASSISTANCE

CUSTOMER CALL

If the SIM card used was not supplied by PEUGEOT, we suggest

that you check its compatibility by making a call to the PEUGEOT

Emergency team.

CONSULTING THE SERVICES

Press this button to gain access to the

PEUGEOT services * .

Select "Customer call" to request

any information about the PEUGEOT

marque.

Select "PEUGEOT Assistance" to

make a breakdown assistance call.

* These services and options are subject to conditions and availability.

* This service is subject to conditions and availability.

Consult a PEUGEOT dealer.

If necessary, the internal telephone is activated automat

tomatically to

make an emergency call.

In order for an emergency call to be made, a valid SIM card must be

inserted.

150

Each press of the button, located at the end of the wiper stalk ,
displays the different trip computer information in succession,

depending on the screen.

With the "vehicle" tab:

the range, the current fuel consumption and the distance remaining

to the destination.

Zero reset

When the required route is displayed, press the button for

more than two seconds.

TRIP COMPUTER

VEHICLE DIAGNOSTICS

WARNINGS LOG

STATUS OF FUNCTIONS

TYRE UNDER-INFLATION DETECTOR ZERO RESET

On-board computer

860

l/100

Instantaneous info.

Range

151

A few deﬁ nitions
Range: displays the distance which can be travelled with the remaining fuel

detected in the tank, based on the average consumption over the last few

miles (kilometres).

This displayed value may vary signiﬁ cantly following a change in the vehicle

speed or the relief of the route.

When the range falls below 20 miles (30 km), dashes are displayed. After

ﬁ lling with at least 5 litres of fuel, the range is recalculated and is displayed

as soon as it exceeds 60 miles (100 km).

If, whilst driving, dashes are displayed continuously in place of digits, contact

a PEUGEOT dealer.
Current fuel consumption: only calculated and displayed above 20 mph

(30 km/h).
Average fuel consumption: this is the average fuel consumption since the

last trip recorder zero reset.
Distance travelled: calculated since the last trip computer zero reset.
Distance remaining to the destination: calculated with reference to the

ﬁ nal destination entered by the user. If guidance is activated, the navigation

system calculates it as a current value.
Average speed: this is the average speed calculated since the last trip

computer zero reset (ignition on).

TRIP COMPUTER

With tab "1" (route 1):

the average speed, the average consumption and the

distance travelled calculated over trip "1" .

Tab "2" (trip 2) with the same functions for a second route.

On-board computer

Route

Distance

km/h

l/100

740

6.5

152

CONTROL SHORT-CUTS

STEERING WHEEL CONTROLS

RADIO: selection of the previous stored station.

MP3/JUKEBOX: selection of the previous

directory.

Selection of the previous item on a menu.

RADIO: selection of the next stored station.

MP3/JUKEBOX: selection of the next directory.

Selection of the next item on a menu.

RADIO: automatic search for a higher frequency.

CD/MP3/JUKEBOX: selection of the next track.

CD: continuous press: fast forwards play.

RADIO: automatic search for a lower frequency.

CD/MP3/JUKEBOX: selection of the previous

track.

CD: continuous press: fast backwards play.

- Change of sound source.

- Conﬁ rmation of a selection.

- Pick up/Hang up the

telephone.

- Press for more than

2 seconds: access to the

telephone menu.

Volume increase.

Volume decrease.

Mute: by pressing
the volume increase

and decrease buttons

simultaneously.

The sound is restored by

pressing one of the two

volume buttons.

153

Press the end of the lights stalk to start the voice

recognition.

Say the words one by one and wait for the audible

conﬁ rmation signal between each word.

The list which follows is exhaustive.

To display the list of available voice commands, press

the end of the lights stalk to start the voice recognition,

then say HELP or WHAT CAN I SAY.

For the same operation, press and

hold the MENU button and select the

function VOICE COMMANDS LIST.

VOICE COMMANDS LIST

DISPLAYING THE LIST AND USING THEM

VOICE COMMANDS

LEVEL 1

LEVEL 2

LEVEL 3

radio

memory
autostore
previous/next
list

1 to 6/*

cd player

Jukebox (if activated)

USB

previous/next track

track number/track

scan
random play

directory (CD-MP3 inserted)

list

1 to 250/*

previous/next
repeat
help/what can I say/cancel

changer

previous/next track

track number/track

scan
repeat
random play
previous/next disc

disc number

list

1 to 20/*

1 to 5/6/*

call/guide to

"Pre-recorded description"

telephone

last number

voice box

voice mail
directory

"Pre-recorded description"

message

display
read
directory

"Pre-recorded description"

navigation

stop/resume

zoom in/out

view

destination
vehicle

trafﬁ c info

display
read

display

audio
telephone
trip computer

Navigation

air conditioning

previous/next
stop
delete
yes/no

for all level 1 and 2

* help/what can I say/cancel

for all level 1, 2 or *

154

Turn the dial and select the ADJUST

THE DATE AND TIME function.

CONFIGURATION

ADJUSTING THE DATE AND TIME

Press the MENU button.

Turn the dial and select the

CONFIGURATION function.

Press the dial to conﬁ rm the selection.

Turn the dial and select the DISPLAY

CONFIGURATION function.

Adjust the settings one by one

conﬁ rming by pressing the dial. Next

select the OK tab on the screen then

conﬁ rm.

Press the dial to conﬁ rm the selection.

DISPLAY CONFIGURATION

ADJUST THE DATE AND TIME

Press the dial to conﬁ rm the selection.

The CONFIGURATION function gives access to the colour, brightness and units settings and to voice
commands.

155

3
3

MAIN FUNCTION

NAVIGATION - GUIDANCE

previous destinations

SCREEN MENU MAP

set speech synthesis

activate/deactivate road names

delete last destinations

MAP

CHOICE A

choice A1

choice A2

CHOICE B...

SELECT DESTINATION

enter an address

country:

town:

road:

N°/_ :

curr. loc

directory

previous destinations

order/delete journey legs

divert route

chosen destination

GUIDANCE OPTIONS

deﬁ ne calculation criteria

fastest

shortest

distance/time

with tolls

with ferry

trafﬁ c info

STOP/RESUME GUIDANCE

MAP ORIENTATION

vehicle direction

north direction

3D view

MAP DETAILS

administration and safety

town halls, town centre

universities, colleges

hospitals

hotels, restaurants and shops

hotels

restaurants

vineyards

business centres

156

supermarkets, shopping

culture, tourism and shows

culture and museums

casinos and nightlife

cinemas and theatres

tourism

shows and exhibitions

sports and open air centres

sports centres

golf courses

skating rinks, bowling alleys

winter sports resorts

parks, gardens

theme parks

transport and automobile

airports, ports

stations, bus stations

vehicle rental

lay-bys, car parks

service stations, garages

read messages

new message display

TRAFFIC INFORMATION

SELECT TMC STATION

automatic TMC

manual TMC

list of TMC stations

MOVE THE MAP/FOLLOW VEHICLE

DISPLAY MAP

full screen map

map in window

MAP DATABASE DESCRIPTION

READ MESSAGES

FILTER TRAFFIC INFORMATION

geographic ﬁ lter

store all messages

store messages

around the vehicle

on the route

road information

trafﬁ c information

road closure

size limit

road condition

weather and visibility

urban/city information

parking

public transport

demonstrations

AUDIO FUNCTIONS

RADIO FAVOURITES

enter a frequency

activate/deactivate RDS mode

activate/deactivate regional mode

display/hide radio text

CD, USB, JUKEBOX FAVOURITES

activate/deactivate Introscan (SCN)

activate/deactivate Random mode (RDM)

activate/deactivate Repeat (RPT)

activate/deactivate display of CD info

copy CD to Jukebox

copy complete CD

multiple selection

CONFIGURE MESSAGE ANNOUNCEMENT

157

current album

current track

eject CD

receive by infrared

exchange with SIM card

send all records to SIM

send one record to SIM

receive all SIM ﬁ les

receive a SIM ﬁ le

exchange with Bluetooth

TELEMATICS

call list

dial

directory

mailbox

services

customer contact centre

PEUGEOT assistance

PEUGEOT service

messages received

USB

copy USB to Jukebox

complete disc

multiple selection

current album

current track

eject USB

CALL

DIRECTORY

managing directory ﬁ les

consult or modify a ﬁ le

add a ﬁ le

delete a ﬁ le

delete all ﬁ les

conﬁ gure directory

select a directory

name directory

select starting directory

ﬁ le transfer

exchange by infrared

send all records

send one record

TEXT MESSAGES (SMS)

read received text messages

send a text message

write a text message

delete list of text messages

TELEPHONE FUNCTIONS

network

network search mode

automatic mode

manual mode

networks available

length of calls

reset

manage PIN code

activate/deactivate

save PIN code

JUKEBOX

jukebox management

jukebox conﬁ guration

hi-ﬁ (320 kbps)

high (192 kbps)

normal (128 kbps)

playlist management

delete jukebox data

Jukebox status

158

Display short cuts version 8.2

modify PIN code

call options

conﬁ gure calls

display my number

automatic reply after x ring(s)

ring options

for voice calls

for text messages (SMS)

text message ring

calls diversion to mailbox n°

delete calls log

CONFIGURATION

DISPLAY CONFIGURATION

choose colour

adjust luminosity

set date and time

select units

SOUND

* The parameters vary according to vehicle.

voice commands setting

speech synthesis setting

guidance instructions volume

other message volume

select female/male voice

activate/deactivate auxiliary source

VIDEO

VEHICLE DIAGNOSTICS

SELECT LANGUAGE

DEFINE VEHICLE PARAMETERS *

ACTIVATE VIDEO MODE

VIDEO PARAMETERS

display formats

adjust luminosity

set colours

set contrasts

ALERT LOG

STATUS OF FUNCTIONS *

RESET TYRE PRESS. DETEC. SYS. *

phone book synchronisation mode

no synchronisation

view telephone phone book

view SIM card phone book

view all phone books

BLUETOOTH FUNCTIONS

activation mode

deactivated

activated and visible

activated and not visible

list of matched peripheral equipment

change the name of the audio/telephone

authentication code

Peugeot 607 Dag (2009 year). Instruction - part 11
