Peugeot 607 Dag (2009 year). Instruction

To set the alarm with exterior
protection only

Failure of the remote control



Unlock the doors with the key and

open the door. The alarm is trig-

gered.



Switch on the ignition in the next

ten seconds. The alarm is disarmed.

Incorrect operation

When the ignition is switched on, if

button A lights for ten seconds, there

is a fault in the siren connection.

Contact a PEUGEOT dealer to have

the system checked.

If, while you are away from the vehicle,

you wish to leave a window partially

open or a pet inside the vehicle, you

should choose exterior protection only.


Switch off the ignition.



In the next ten seconds, press but-

ton B until its indicator light is on

continuously.



Get out of the vehicle.



Set the alarm by locking or dead-

locking using the remote control
(button A and button B indicator

lights ﬂ ash once a second).

ELECTRIC WINDOWS

The electric windows are de-

activated temporarily if the

energy economy mode is ac-

tivated.

To keep your children safe, press

switch 5 to prevent operation of the

rear windows.

To reactivate the controls, press con-

trol 5

again.

You have two options:

Manual operation:


press or pull switch 1 gently. The

window stops as soon as the

switch is released.

Automatic operation:


press or pull switch 1 fully. The

window opens or closes complete-

lywhen the switch is released.

Pressing the switch again stops

the movement of the window.

Safety auto-reverse
When the window rises and meets an

obstacle, it stops and lowers again.

In the case of unwanted opening of the

window on closing (for example, in the

case of ice), if the window will not rise,

pull the switch until the window clos-

es completely. Continue to press the

switch for one second after closing.

Following reconnection of the battery,

in the event of a malfunction, you must

reinitialise the safety auto-reverse

function:
- open the window completely, then

close it, it will rise in stages of a few

centimetres with each press, repeat

the operation until the window is

completely closed,

- continue to press the switch for at

least one second after reaching

this position.

The safety auto-reverse function is not
operational during these operations.

1. Driver's electric

window switch.

2. Passenger's

electric window switch.

3. Rear right

electric window switch.

4. Rear left electric

window switch.

5. Neutralisation of the electric

controls located in the rear
(child safety).

Approximately 45 seconds fol-

lowing removal of the ignition

key, none of the windows can

be opened or closed. You must

switch the ignition on again to

open or close the windows.

Always remove the key from

the ignition when leaving the

vehicle, even for a short time.

In the event of contact when

operating the windows, you must re-

verse the movement of the window. To

do this, press the switch concerned.
When the driver operates the passenger

window switches, he must ensure that no

one is preventing correct closing of the

window.
The driver must ensure that passengers

use the electric windows correctly.

Be aware of children when operating

the windows.

DOORS

Opening the doors from outside

Opening the doors from inside

Locking/unlocking from the inside

- Using button A of the centre con-

sole:

this allows the doors, the boot and

the fuel ﬁ ller ﬂ ap to be locked or un-

locked.
Note: the button A indicator light is lit

or ﬂ ashes when the vehicle is locked.

- Using button B on the door:

on the front doors this allows the

doors, the boot and the fuel ﬁ ller

ﬂ ap to be locked or unlocked.

on the rear doors this allows the

door concerned to be locked or

unlocked.

Buttons A and B and control
C are deactivated if the vehicle

is deadlocked.

Always remove the key from

the ignition when leaving the

vehicle, even for a short time.

In the event of contact when

operating the windows, you must re-

verse the movement of the window. To

do this, press the switch concerned.
When the driver operates the passenger

window switches, he must ensure that no

one is preventing correct closing of the

window.
The driver must ensure that passengers

use the electric windows correctly.

Be aware of children when operating

the windows.

DOORS

Opening the doors from outside

Opening the doors from inside

Locking/unlocking from the inside

- Using button A of the centre con-

sole:

this allows the doors, the boot and

the fuel ﬁ ller ﬂ ap to be locked or un-

locked.
Note: the button A indicator light is lit

or ﬂ ashes when the vehicle is locked.

- Using button B on the door:

on the front doors this allows the

doors, the boot and the fuel ﬁ ller

ﬂ ap to be locked or unlocked.

on the rear doors this allows the

door concerned to be locked or

unlocked.

Buttons A and B and control
C are deactivated if the vehicle

is deadlocked.

Child safety

Automatic central locking of the
doors

'Door open' alert
With the engine running or when the

vehicle is moving, the door open warn-

ing light comes on accompanied by an

audible signal and/or a diagram indi-

cating the relevant door on the multi-

function display.

MOTORISED BOOT

The doors can lock automatically

while driving (speed above 6 mph

[10 km/h]).
You can activate or deactivate this
function by pressing button A for more

than 2 seconds.
This is indicated by a message on the

multifunction display.

This prevents either of the rear doors

being opened from inside.


Turn the switch on each rear door

a quarter of a turn using the ignition

key.

Driving with the doors locked

may make access to the pas-

senger compartment by the

emergency services more dif-

ﬁ cult in an emergency.

Vehicle locked/deadlocked
 Press button A on the remote control

key.

This action will also unlock the doors

and the fuel ﬁ ller ﬂ ap.

Child safety

Automatic central locking of the
doors

'Door open' alert
With the engine running or when the

vehicle is moving, the door open warn-

ing light comes on accompanied by an

audible signal and/or a diagram indi-

cating the relevant door on the multi-

function display.

MOTORISED BOOT

The doors can lock automatically

while driving (speed above 6 mph

[10 km/h]).
You can activate or deactivate this
function by pressing button A for more

than 2 seconds.
This is indicated by a message on the

multifunction display.

This prevents either of the rear doors

being opened from inside.


Turn the switch on each rear door

a quarter of a turn using the ignition

key.

Driving with the doors locked

may make access to the pas-

senger compartment by the

emergency services more dif-

ﬁ cult in an emergency.

Vehicle locked/deadlocked
 Press button A on the remote control

key.

This action will also unlock the doors

and the fuel ﬁ ller ﬂ ap.

Child safety

Automatic central locking of the
doors

'Door open' alert
With the engine running or when the

vehicle is moving, the door open warn-

ing light comes on accompanied by an

audible signal and/or a diagram indi-

cating the relevant door on the multi-

function display.

MOTORISED BOOT

The doors can lock automatically

while driving (speed above 6 mph

[10 km/h]).
You can activate or deactivate this
function by pressing button A for more

than 2 seconds.
This is indicated by a message on the

multifunction display.

This prevents either of the rear doors

being opened from inside.


Turn the switch on each rear door

a quarter of a turn using the ignition

key.

Driving with the doors locked

may make access to the pas-

senger compartment by the

emergency services more dif-

ﬁ cult in an emergency.

Vehicle locked/deadlocked
 Press button A on the remote control

key.

This action will also unlock the doors

and the fuel ﬁ ller ﬂ ap.

Permanent locking of the boot

This function can be ac-

tivated

deactivated

via the multifunction dis-

play

"Personalisation-

Conﬁ guration" menu.

Vehicle unlocked

Closing the boot lid

Press the push button C to start electric

closing of the boot lid.
Note: do not hinder closing of the boot
lid: any obstacle to closing causes the

boot lid to stop and rise a few centime-

tres automatically.

"Boot open" warning
With the engine running or when the ve-

hicle is moving, the door open warning

light comes on, accompanied by an au-

dible signal and/or a diagram indicating

the boot on the multifunction display, if

the boot is not properly closed.

the boot lid

While electric opening or closing of the
boot lid is in progress, you can stop its
movement at any time:


press the push-button B or C on

the boot lid.

or
 press button A

on the remote con-

trol key.

When it is stopped, the boot lid is held
in an intermediate position electrically

for approximately 10 minutes.

After this time, the system switches to

standby and releases the boot lid.
To leave the intermediate position, start
an electric opening or closing operation

or move the boot lid manually.

 When the function is active, the boot

can only be opened by pressing but-

ton A

on the remote control key.

This action will only unlock the boot.

 Press button A

on the remote con-

trol key or press the push button B

on the boot lid.

  When opening or closing the
boot,  ensure  that  no-one  is
close to the rear of the vehicle
to avoid the risk of injury.

To close the boot lid manually, use one

of the two handles inside the boot lid.

If the automatic central locking

is activated, when the vehicle

reaches a speed of 6 mph

(10 km/h), the boot is locked

and the push button B

is deactivated.

It is reactivated when stationary by the

opening of one of the doors.

Tailgate release

This enables the tailgate to be un-

locked in the event of a central locking

fault.

- Fold back the rear seats to gain

access to the lock from inside the

boot.

- Insert a small screwdriver into hole A

of the lock to unlock the tailgate.

FILLING WITH FUEL

Low fuel level

When the minimum fuel level

is reached, this warning light

comes on, accompanied by

an audible signal and a mes-

sage on the multifunction

display.

When this warning light ﬁ rst comes

on, you have approximately 5 litres

of fuel left. It is essential to ﬁ ll the tank

to avoid running out of fuel.

If you run out of fuel (Diesel), refer to the

"Practical information" section also.

Filling with fuel
Locking and unlocking of the fuel ﬁ ller

ﬂ ap, the doors and the boot is simul-

taneous.

A label, afﬁ xed to the inside of the ﬂ ap,

reminds you of the type of fuel to be

used in accordance with your engine.
More than 5 litres of fuel must be added in

order to be registered by the fuel gauge.

Opening the cap may trigger an

air intake noise. This vacuum,

which is completely normal, is

caused by the sealing of the

fuel circuit.

Tailgate release

This enables the tailgate to be un-

locked in the event of a central locking

fault.

- Fold back the rear seats to gain

access to the lock from inside the

boot.

- Insert a small screwdriver into hole A

of the lock to unlock the tailgate.

FILLING WITH FUEL

Low fuel level

When the minimum fuel level

is reached, this warning light

comes on, accompanied by

an audible signal and a mes-

sage on the multifunction

display.

When this warning light ﬁ rst comes

on, you have approximately 5 litres

of fuel left. It is essential to ﬁ ll the tank

to avoid running out of fuel.

If you run out of fuel (Diesel), refer to the

"Practical information" section also.

Filling with fuel
Locking and unlocking of the fuel ﬁ ller

ﬂ ap, the doors and the boot is simul-

taneous.

A label, afﬁ xed to the inside of the ﬂ ap,

reminds you of the type of fuel to be

used in accordance with your engine.
More than 5 litres of fuel must be added in

order to be registered by the fuel gauge.

Opening the cap may trigger an

air intake noise. This vacuum,

which is completely normal, is

caused by the sealing of the

fuel circuit.

Fuel ﬁ ller cap open

When this light comes on,
accompanied by an audible

signal and/or a message

on the multifunction display,

screw the cap on again and

close the fuel ﬁ ller ﬂ ap.

Quality of the fuel used for petrol
engines
The petrol engines are perfectly com-

patible with E10 type petrol biofuels

(containing 10 % ethanol), conforming

to European standards EN 228 and

EN 15376.

E85 type fuels (containing up to 85 %

ethanol) are reserved exclusively for

vehicles marketed for the use of this

type of fuel (BioFlex vehicles). The

quality of the ethanol must comply with

European standard EN 15376.
For Brazil only, special vehicles are
marketed to run on fuels containing up

to 100 % ethanol (type E100).

Quality of the fuel used for Diesel
engines
The Diesel engines are perfectly com-

patible with biofuels which conform to

current and future European standards

(diesel fuel which complies with stand-

ard EN 590 mixed with a biofuel which

complies with standard EN 14214)

available at the pumps (containing up

to 7 % Fatty Acid Methyl Ester).

The B30 biofuel can be used in cer-

tain Diesel engines; however, this use

is subject to strict application of the

special servicing conditions. Consult a

PEUGEOT dealer.

The use of any other type of (bio)fuel

(vegetable or animal oils, pure or di-

luted, domestic fuel...) is strictly pro-

hibited (risk of damage to the engine

and fuel circuit).

The engine and the ignition must

be switched off when ﬁ lling with

fuel:


Open the fuel ﬁ ller ﬂ ap by pressing

the front,



Unscrew the cap and hook it over

the tab located on the inside of the

ﬂ ap.

When ﬁ lling up your tank, do not con-

tinue after the 3rd cut-off of the pump;

this could cause your vehicle to mal-

function.
  The capacity of the tank is approxi-
mately 80 litres.
   

After ﬁ lling the tank, screw the cap

on fully and close the fuel ﬁ ller ﬂ ap.

The operation of the sunroof is

deactivated 45 seconds after

the ignition is switched off.
The operation of the sunroof

will be deactivated temporarily if the

energy economy mode is activated.

Always remove the key from the igni-

tion when leaving the vehicle, even for

a short time.

In the event of contact when operat-

ing the sunroof, you must reverse the

movement of the sunroof. To do this,

press the switch concerned.
When the driver operates the sunroof

switch, he must ensure that no one is

preventing correct closing of the sun-

roof.

The driver must ensure that passen-

gers use the electric sunroof correctly.

Be aware of children when operating

the sunroof.

SUNROOF *

You have two options:

Manual operation:


lightly press the switch; the roof

stops as soon as the switch is re-

leased.

Safety auto-reverse
(on sliding only)
When the sunroof is closing and

meets an obstacle, it stops then par-

tially opens again.

In the event of unwanted opening of

the sunroof on closing:
- press part B of the switch until the

sunroof is fully open,

- as soon as the sunroof stops,

press part A

of the switch until the

sunroof is fully closed.

  The  safety  auto-reverse  function  is
not operational during this operation.
  Note:

the sunroof shutter is manual.

Automatic operation:


press the switch down fully; the

roof opens or closes completely

depending on where the switch is

pressed.

to partially open the roof: press

part A

of the switch. To close it, press

part B

of the switch.

to open the roof completely:

press part B

of the switch.

to close it completely: press

part A

of the switch.

* According to country.

LIGHTS STALK

Lights off.

Side lights.

Dipped/main beam head-
lamps.

Dipped/main beam change
 Pull the stalk fully towards you.

  Lights on
With  the  ignition  and  the  automatic
lights  function  switched  off,  on  open-
ing the driver's door  a buzzer  sounds
to  warn  you  that  you  have  left  your
lights on.

Front and rear fog lamps (ring B)
 Turn ring B forwards to switch on

and backwards to switch off. The

position is conﬁ rmed by the light

on the instrument panel.

Front fog lamps (one press)

These operate with the side lights, dipped
headlamps or main beam headlamps.

Rear fog lamps (two presses)

These operate with the side lights and
the front fog lamps, or with the dipped
headlamps.

Left: downwards.
Right: upwards.

Direction indicators (ﬂ ashers)

  Note:   if  you  forget  to  return
the  direction  indicator  to  its
normal  position,  the  volume
of  the  audible  signal  will  in-

crease, if you are driving at a speed
greater than 50 mph (80 km/h).

Parking lights
The side lights are lit on the side the

trafﬁ c is on.
With the ignition off and within the next
minute, place the direction indicators

stalk on the trafﬁ c side (for example:

for  parking  on  the  right;  switching  on
of the lights on the left).
This  is  indicated  by  an  audible  sig-
nal  and  lighting  of  the  corresponding
direction  indicator  on  the  instrument
panel.

Automatic "follow-me-home"
lighting
When you leave your vehicle with  the
automatic switching on of the lights
activated ,  the  side  lights  and  dipped
headlamps remain on for the duration
selected when the ignition is switched
off.
To  deactivate  or  activate  this  func-
tion, pass via the multifunction display
"Personalisation-Configuration"
menu.

Front and rear lights (ring A)
 Turn ring A to the position required.

The  timed  duration  must
also  be  set,  via  the  multi-
function  display   "Person-
alisation-Configuration"
menu.

Automatic switching on of the
lights

Side  lights  and  dipped  beam  head-
lamps  switch  on  automatically  if  the
light is poor, or during operation of the
windscreen  wipers.  They  switch  off
as  soon  as  the  light  becomes  bright
enough  or  the  windscreen  wipers
stop.
In foggy weather or in snow, the bright-

ness sensor can detect sufﬁ cient light.

Therefore, the lights will not come on
automatically. If necessary, you must
switch on the dipped headlamps man-
ually.
This function is active when the vehicle is
supplied to the customer.

To switch the function on
or off, use the multifunction
display "Personalisation-

Conﬁ guration" menu.

Activation

Deactivation.

When this function is activat-
ed, the indicator light on the
instrument panel comes on.

When the function is deacti-
vated, the indicator light on the
instrument panel comes on.

Cancellation:


ﬂ ash the headlamps,

 get out of the vehicle and lock it.

  Manual "follow-me-home" lighting
In the absence of the automatic switching
on  of  the  lights,  the  manual  "follow-me-
home" lighting can be activated.
When you leave your vehicle, the side
lights  and  dipped  headlamps  remain
on for approximately 1 minute.

  Activation:
      switch off the engine,
  

ﬂ ash the headlamps,

 get out of the vehicle and lock it.

Deactivation:


ﬂ ash the headlamps again,

 get out of the vehicle and lock it.

  If the brightness sensor does not func-
tion  correctly ,  the  system  activates  the
function and the lights come on.
Contact  a  PEUGEOT  dealer  to  have
the system checked.

Daytime running lamps *

On vehicles which are equipped with day-
time running lamps, the dipped headlamps
come on when the vehicle is started.

This indicator lamp comes on on
the instrument panel screen.

The  instruments  and  controls
(instrument  panel,  multifunc-
tion  screen,  air  conditioning
control  panel...)  are  only  lit

on switching to the automatic lighting
mode or when the lights are switched
on manually.

* According to country.

The  brightness  of  the  display
and  of  the  instrument  panel
may  change  when  the  lights
are switched on automatically.

If  your  lights  have  been
switched on manually, turn the
ring  back  to  position   0 ,  lights
off.

The  timed  duration  must
also  be  set,  via  the  multi-
function  display   "Person-
alisation-Configuration"
menu.

Automatic switching on of the
lights

ness sensor can detect sufﬁ cient light.

Therefore, the lights will not come on
automatically. If necessary, you must
switch on the dipped headlamps man-
ually.
This function is active when the vehicle is
supplied to the customer.

To switch the function on
or off, use the multifunction
display "Personalisation-

Conﬁ guration" menu.

Activation

Deactivation.

When this function is activat-
ed, the indicator light on the
instrument panel comes on.

When the function is deacti-
vated, the indicator light on the
instrument panel comes on.

Cancellation:


ﬂ ash the headlamps,

 get out of the vehicle and lock it.

  Activation:
      switch off the engine,
  

ﬂ ash the headlamps,

 get out of the vehicle and lock it.

Deactivation:


ﬂ ash the headlamps again,

 get out of the vehicle and lock it.

  If the brightness sensor does not func-
tion  correctly ,  the  system  activates  the
function and the lights come on.
Contact  a  PEUGEOT  dealer  to  have
the system checked.

Daytime running lamps *

On vehicles which are equipped with day-
time running lamps, the dipped headlamps
come on when the vehicle is started.

This indicator lamp comes on on
the instrument panel screen.

The  instruments  and  controls
(instrument  panel,  multifunc-
tion  screen,  air  conditioning
control  panel...)  are  only  lit

on switching to the automatic lighting
mode or when the lights are switched
on manually.

* According to country.

The  brightness  of  the  display
and  of  the  instrument  panel
may  change  when  the  lights
are switched on automatically.

If  your  lights  have  been
switched on manually, turn the
ring  back  to  position   0 ,  lights
off.

AUTOMATIC HEADLAMP
ADJUSTMENT

  In cases of malfunction , the
warning  light  comes  on  on
the  instrument  panel  display,
accompanied  by  an  audible
signal and a message on the

multifunction display. The system places
your headlamps to the low position.
Do not touch the xenon bulbs. Consult
a PEUGEOT dealer.

  When  stationary  with  the  ignition
on , the system automatically corrects
the  height  of  the  beam,  whatever  the
load of the vehicle. The driver is then
assured  of  having  optimum  lighting
and  not  causing  a  nuisance  to  other
road users.

WINDSCREEN WIPER STALK

  Windscreen wipers
  2   Fast wipe (heavy rain).
  1   Normal wipe (moderate rain).
  I

Intermittent wipe

  0   Off
Automatic wipe then single sweep.
In the  Intermittent  position, the wiping
speed is in proportion to the speed of
the vehicle.
In the  AUTO  position, no further action
on your part is required.

   The  automatic  wiping  must
be  reactivated   if  the  ignition
has been switched off for more
than  one  minute,  by  pressing
the stalk down  .

Maintenance position

This position enables the wiper blades
to be removed.
In the minute following switching off of
the  ignition,  any  action  on  the  wipers
stalk  positions  the  wipers  at  the  top
of  the  windscreen  (parking  in  winter,
cleaning, replacement of the blades).
To reposition the wipers after this has
been done, switch on the ignition and
operate the stalk.

         Windscreen and headlamp wash
Pull  the  windscreen  wiper  stalk  to-
wards you. The windscreen wash then
the  windscreen  wipers  operate  for  a

ﬁ xed period.
The headlamp wash is also activated,
if the headlamps are on.

Screenwash/headlampwash low

When  the  minimum  level  of
the reservoir is reached, this
warning  light  comes  on,  ac-
companied  by  an  audible
signal and a message on the
multi-function display.

Next time you stop, ﬁ ll the screen-

wash/headlamp wash reservoir.
If the reservoir is empty, the warning
light comes on when the ignition is
switched on, or every time the stalk is

operated, until the reservoir is ﬁ lled.

Peugeot 607 Dag (2009 year). Instruction - part 5
