Peugeot 607 Dag (2009 year). Instruction

Memorising driving and mirror
positions

Memorising using the controls on
the driver's door
To memorise:
 Place the key in the ignition on po-

sition,

 Adjust your seat and mirrors,
 Press button M , then button 1

"ﬁ rst

driving position" or button     2  "sec-
ond  driving  position"  within  four
seconds.

An audible signal conﬁ rms that a position

has been memorised.
Memorising a new position cancels
the previous one.

Recalling a memorised driving
position

Ignition on, vehicle stationary


Brieﬂ y press button 1 or 2 to recall

the corresponding memorised po-
sition. The end of the setting is in-
dicated by a bleep.

After  recalling  a  memorised  position
a  few  times  in  succession,  the  func-
tion  will  be  cancelled  until  the  engine
is started.

G - Heated seats adjustment

With the engine running, use the cor-
responding  adjustment  dial  to  select
the required degree of heating:
  0 : Off.
  1 : Low.
  2 : Medium.
  3 :

High.

The electrical adjustments of the seat
and exterior mirrors are memorised.
Two driving positions can be memo-
rised using buttons M/1 and M/2 .

Vehicle moving
 Keep button 1 or 2 pressed down

until  the  bleep  indicates  that  set-
ting  of  the  corresponding  memo-
rised position is complete.

Memorising driving and mirror
positions

Memorising using the controls on
the driver's door
To memorise:
 Place the key in the ignition on po-

sition,

 Adjust your seat and mirrors,
 Press button M , then button 1

"ﬁ rst

driving position" or button     2  "sec-
ond  driving  position"  within  four
seconds.

An audible signal conﬁ rms that a position

has been memorised.
Memorising a new position cancels
the previous one.

Recalling a memorised driving
position

Ignition on, vehicle stationary


Brieﬂ y press button 1 or 2 to recall

the corresponding memorised po-
sition. The end of the setting is in-
dicated by a bleep.

After  recalling  a  memorised  position
a  few  times  in  succession,  the  func-
tion  will  be  cancelled  until  the  engine
is started.

G - Heated seats adjustment

With the engine running, use the cor-
responding  adjustment  dial  to  select
the required degree of heating:
  0 : Off.
  1 : Low.
  2 : Medium.
  3 :

High.

The electrical adjustments of the seat
and exterior mirrors are memorised.
Two driving positions can be memo-
rised using buttons M/1 and M/2 .

Vehicle moving
 Keep button 1 or 2 pressed down

until  the  bleep  indicates  that  set-
ting  of  the  corresponding  memo-
rised position is complete.

REAR SEATS

Folding down the seat back

Rear heated seats controls

The seat back in the rear is folded
down in two 1/3-2/3 parts.
Before folding down the seat back:
 check that the seat belt strap on

the side of the seat back (1/3 or
2/3) is positioned correctly,

 release the lap belt strap by press-

ing the black button of the lock
(2/3).

 Press the switch. The temperature

is regulated automatically.

     Press it again to stop operation.
  Note:   the  command  to  activate  heat-
ing of the seat(s) remains in the mem-
ory for one minute after the ignition is
switched off.

The unlocking controls are located in
the boot.
To unlock from the boot:
 pull the control A corresponding to

the part of the seat back that you
wish to fold down.

To unlock from inside the vehicle:
 lower the armrest and open the ski

ﬂ ap,

 pull the button B located on the un-

locking  housing  corresponding  to
the  part  of  the  seat  back  that  you
wish to fold down.

Rear seat

When returning the seat back
to  its  original  position,  en-
sure  that  the  seat  belt  is  not
trapped.

When putting the seat back to
its original position, for your
safety make sure that it is cor-
rectly locked.

"Forwards-facing"

INSTALLING A CHILD SEAT
USING A THREE POINT SEAT
BELT

GENERAL POINTS RELATING
TO CHILD SEATS

* The rules for transporting children are

speciﬁ c to each country. Refer to the

current legislation in your country.

Intermediate longitudinal

position

When  a  "rearwards-facing"
child  seat  is  installed  on  the
front  passenger  seat ,  it  is
essential  that  the  passenger

airbag is deactivated. Otherwise, the

child would risk being seriously in-

jured or killed if the airbag were to

inﬂ ate.

When  a  "forwards-facing"  child  seat
is  installed  on  the   front  passenger
seat ,  adjust  the  vehicle's  seat  to  the
intermediate longitudinal position with
the  seat  back  upright  and  leave  the
passenger airbag activated.

For maximum safety, please
follow these precautions:

in  accordance  with  European  reg-
ulations,   all  children  under  the
age  of  12  or  less  than  one  and
a  half  metres  tall  must  travel  in
approved  child  seats  suited  to
their weight

, on seats ﬁ tted with a

seat belt or ISOFIX mountings * ,

statistically, the safest seats in

your vehicle for the transpor-

tation of children are the rear
seats,

a  child  weighing  less  than  9  kg
must  travel  in  the  "rearwards-
facing" position both in the front
and in the rear.

  PEUGEOT recommends  that children
should travel in the  rear seats  of your
vehicle:
   -

"rearwards-facing" up to the age of 2,

"forwards-facing" over the age of 2.

Although one of PEUGEOT's main cri-
teria when designing your vehicle, the
safety of your children also depends
on you.

"Rearwards-facing"

CHILD SEATS RECOMMENDED BY PEUGEOT

PEUGEOT offers a complete range of recommended child seats which are secured
using a three point seat belt :

Passenger air bag OFF

Group 0: from birth to 10 kg

Group 0+: from birth to 13 kg

"ROMER Baby-Safe Plus"

Installed in the rear-facing position.

Groups 1, 2 and 3: from 9 to 36 kg

"KIDDY Life"

The use of the restraining cushion is

compulsory for transporting young

children (from 9 to 18 kg).

Groups 2 and 3: from 15 to 36 kg

"RECARO Start''.

"KLIPPAN Optima"

From the age

of 6 years

(approximately

22 kg), the booster

is used on its own.

LOCATION OF CHILD SEATS SECURED USING THE SEAT BELT

In accordance with European regulations, this table indicates the options for the installation of child seats, secured using the
seat belt and universally approved, in relation to the weight of the child and the seat in the vehicle.

Seat(s)

Weight of the child /indicative age

Less than 13 kg

(group 0 ( a ) to 0+)

Up to 1 year approx

From 9 to 18 kg

(group 1)

From 1 to 3 years

approx

From 15 to 25 kg

(group 2)

From 3 to 6 years

approx

From 22 to 36 kg

(group 3)

From 6 to 10 years

approx

Front passenger (b)
Height adjustable seat

U (R)

Rear side

Rear centre

RÖMER Duo *

L2, L3, L4

U : seat suitable for the installation of a child seat secured using the seat belt and universally approved, "rearwards facing"

and/or "forwards facing".

  U (R) : idem  U , the vehicle seat must be adjusted to its highest position.
  X : seat which is not suitable for the installation of a child seat of the weight group indicated.
  L- : only the child seats indicated may be installed on the seat concerned (according to country).
(a) Group 0: from birth to 10 kg. Infant car seats and "car cots" cannot be installed on the front passenger seat.
(b) Consult the current legislation in your country before installing your child on this seat.

* Only secured using the seat belt.

ADVICE ON CHILD
SEATS

  Installing a booster seat
The  chest  part  of  the  seat  belt  must
be  positioned  on  the  child's  shoulder
without touching the neck.
Ensure  that  the  lap  part  of  the  seat
belt  passes  correctly  over  the  child's
thighs.
PEUGEOT  recommends  the  use  of

a booster seat which has a back, ﬁ t-

ted with a seat belt guide at shoulder
level.

As a safety precaution, do not leave:
-

one or more children alone and un-
supervised in a vehicle,

a child or an animal in a vehicle
which is exposed to the sun, with
the windows closed,

the keys within reach of children
inside the vehicle.

To  prevent  accidental  opening  of  the
doors, use the "Child lock".
Take  care  not  to  open  the  rear  win-
dows by more than one third.
To  protect  young  children  from  the

rays of the sun, ﬁ t side blinds on the

rear windows.

The incorrect installation of a child seat
in  a  vehicle  compromises  the  child's
protection in the event of an accident.
Remember to fasten the seat belts or
the child seat harnesses  keeping the
slack  in relation to the child's body  to
a minimum , even for short journeys.
For  optimum  installation  of  the  "for-
ward  facing"  child  seat,  ensure  that
the back of the child seat is in contact
with the back of the vehicle's seat and
that the head restraint does not cause
any discomfort.
If the head restraint has to be removed,
ensure that it is stored or attached se-
curely  to  prevent  it  from  being  thrown
around the vehicle in the event of sharp
braking.

"ISOFIX" MOUNTINGS

This seat is ﬁ tted with ISOFIX mountings.

These are two rings located between
the seat back and the seat cushion.
The ISOFIX child seats

are ﬁ tted with

two locks which are secured easily on
these rings.
This ISOFIX mounting system guaran-

tees reliable, safe and fast ﬁ tting of the

child seat in your vehicle.

If  a  child  is  not  installed  in  a
vehicle  correctly,  the  child's
protection  in  the  event  of  a
collision will be compromised.

Children under the age of 10 must not
travel  in  the  "forward  facing"  position
on  the  front  passenger  seat,  unless
the rear seats are already occupied by
other  children,  cannot  be  used  or  are
absent.
Disarm  the  passenger  air  bag  when
a  "rear  facing"  child  seat  is  installed
on the front seat. Otherwise, the child
would  risk  being  seriously  injured  or

killed if the air bag were to inﬂ ate.

ADVICE ON CHILD
SEATS

a booster seat which has a back, ﬁ t-

ted with a seat belt guide at shoulder
level.

As a safety precaution, do not leave:
-

one or more children alone and un-
supervised in a vehicle,

a child or an animal in a vehicle
which is exposed to the sun, with
the windows closed,

the keys within reach of children
inside the vehicle.

To  prevent  accidental  opening  of  the
doors, use the "Child lock".
Take  care  not  to  open  the  rear  win-
dows by more than one third.
To  protect  young  children  from  the

rays of the sun, ﬁ t side blinds on the

rear windows.

"ISOFIX" MOUNTINGS

This seat is ﬁ tted with ISOFIX mountings.

These are two rings located between
the seat back and the seat cushion.
The ISOFIX child seats

are ﬁ tted with

two locks which are secured easily on
these rings.
This ISOFIX mounting system guaran-

tees reliable, safe and fast ﬁ tting of the

child seat in your vehicle.

If  a  child  is  not  installed  in  a
vehicle  correctly,  the  child's
protection  in  the  event  of  a
collision will be compromised.

killed if the air bag were to inﬂ ate.

ISOFIX CHILD SEATS RECOMMENDED BY PEUGEOT AND APPROVED FOR YOUR VEHICLE

These child seats can also be used on seats which are not ﬁ tted with ISOFIX mountings. In this case, it is essential

that they are secured to the vehicle's seat by means of the three-point seat belt.

Follow the instructions for ﬁ tting the child seat indicated in the seat manufacturer 's i nstallation guide .

ISOFIX KIDDY

ISOFIX RÖMER Duo Plus

Group 0+: from birth to 13 kg

Group 1: from 9 to 18 kg

Installed in the rear facing position.

Installed in the forwards facing position.

Installed in the forwards facing position only.

The body of the child seat must be in
contact with the back of the vehicle's
front seat.

It is essential that the vehicle's front
seat is adjusted to the intermediate
longitudinal position.

Secured without the top strap.
Three  child  seat  body  angles:  sitting,
reclining and lying positions.
Adjust  the  vehicle's  front  seat  so  that
the  child's  feet  do  not  touch  the  seat
back.

REMOTE CONTROL KEY

Unfolding/Folding the key

To unfold or fold the key, press button
A

ﬁ rst.

Unlocking

Normal locking

 Press button B for complete locking

of the vehicle.

 Press button B for more than

2 seconds for automatic closing
of the windows and sunroof in

addition to locking.

Each action is conﬁ rmed by ﬁ xed light-

ing of the direction indicators for ap-

proximately two seconds.

The exterior mirrors fold at the same time.

Complete
 Press button C

for complete un-

locking of the vehicle.

This is conﬁ rmed by rapid ﬂ ashing of

the direction indicators for approxi-

mately two seconds.

The complete or selective

unlocking can be conﬁ g-

ured by means of a param-

eter, via the multifunction
display "Personalisation-

Conﬁ guration" menu.

The remote control in the key permits

remote locking, deadlocking and un-

locking of the doors, boot and fuel ﬁ ller

ﬂ ap, as well as folding and unfolding of

the exterior mirrors.

The key permits mechanical and in-

dependent operation of the glove box

lock, of the passenger air bag dis-

arming control and of the mechanical

child lock as well as switching on of

the ignition.
From the driver's door, the key permits

electrical control of the locking or un-

locking of the doors, boot and fuel ﬁ ller

ﬂ ap.
If one of the doors or the boot is open,

the central locking does not function.

When the vehicle is locked,

if unlocking is activated inad-

vertently, without a door being

opened within 30 seconds, the

vehicle will lock automatically.

Selective
 Press button C to unlock the driver's

door and the fuel ﬁ ller ﬂ ap only.

 Press the button again to unlock

the other doors and the boot.

Each action is conﬁ rmed by rapid

ﬂ ashing of the direction indicators for

approximately two seconds.

The exterior mirrors unfold at the same time.

A heavy object (key ring...),

attached to the key and

weighing down on its shaft in

the switch, may cause a mal-

function.

Unlocking, opening and
stopping of the boot

Deadlocking

This renders the external and internal

door controls inoperative.
It also deactivates the internal central

locking button.
 Pressing button B

permits com-

plete locking of the vehicle or
pressing button B for more than
2 seconds

permits automatic clos-

ing of the windows and sunroof in

addition to locking.



Within ﬁ ve seconds, a second

press permits deadlocking of the

vehicle.

This function can be con-

ﬁ gured by means of a para-

meter, via the multifunction
display "Personalisation-

Conﬁ guration" menu.

Each action is conﬁ rmed by

ﬁ xed lighting of the direction

indicators for approximately

two seconds.

Key in ignition

A buzzer sounds on opening the driv-

er's door, if the key has been left in the

ignition.

   Locating your vehicle
To  locate  your  vehicle,  if  you  have
locked it, in a car park:
      press button  B , the courtesy lights

come on and the direction indica-

tors ﬂ ash for a few seconds.

If the permanent locking of the
boot is activated, unlocking is
only possible via button D on

the remote control.

 Press button D to unlock and open

the boot.

This action also unlocks the doors.
 Press button D again to stop the

movement of the boot in an inter-

mediate position.

Changing the remote control
battery

Reprogramming the remote
control

Following disconnection of the vehicle's

battery, replacement of the remote con-

trol battery or in the event of a remote
control malfunction, the remote control

must be reinitialised.


Switch off the ignition.



Switch the ignition on again.



Press the remote control locking but-

ton immediately for a few seconds.



Switch off the ignition and remove

the remote control key from the ig-

nition lock.

The remote control is now working

again.

ELECTRONIC ENGINE
IMMOBILISER

This locks the engine control system

a few moments after the ignition has

been switched off and therefore pre-

vents starting of the vehicle by anyone

who does not have the key.
The ignition key has an electronic chip

which has a special code. When the

ignition is switched on, the code is rec-

ognised and starting is possible.

Battery ref.: CR1620/3 volts.

The information "battery ﬂ at" is given by

displaying of the service warning light,

accompanied by an audible signal and a

message on the multi-function display.
To replace the battery, unclip the casing

using a coin at the notch.

If the remote control does not work after

the battery has been changed, repro-

gramme the remote control.

Do not discard the batteries,

they contain metals which are

harmful to the environment.

Take them to an approved col-

lection point.

Lost keys
Visit a PEUGEOT dealer with the vehicle's

V5 registration certiﬁ cate and your per-

sonal identiﬁ cation documents.

A PEUGEOT dealer will be able to re-

trieve the key code and the transponder
code required to order a replacement

key.

If the system does not function cor-
rectly,

the service warning light comes

on, accompanied by an audible signal
and a message on the multifunction

display.

In this case, your vehicle will not start.

Contact a PEUGEOT dealer as soon

as possible.

  Make  a  careful  note  of  the
number  on  each  key.  The
key number is coded on the
label attached to the key.

  If  the  keys  are  lost,  a  PEUGEOT
dealer  can  rapidly  supply  you  with
new keys.

  The  high  frequency  remote  control
is  a  sensitive  system;  do  not  oper-
ate  it  while  it  is  in  your  pocket  as
there is a possibility that it may un-
lock your vehicle, without you being
aware of it.

  The  remote  control  does  not  oper-
ate  when  the  key  is  in  the  ignition,
even when the ignition is switched
off, except for reprogramming.

  Do  not  operate  the  deadlocking
function  if  there  is  anyone  inside
the vehicle.

Driving with the doors locked may
make access to the passenger com-
partment by the emergency services

more difﬁ cult in an emergency.
  As a safety precaution (with children
on  board),  remove  the  ignition  key
when you leave the vehicle, even for
a short time.

  Do not repeatedly press the button
of your remote control out of range
and  out  of  sight  of  your  vehicle.
You run the risk of stopping it from
working  and  the  remote  control
would have to be reprogrammed.

  When  purchasing  a  second-hand  ve-
hicle, have the key codes memorised
by  a  PEUGEOT  dealer  to  ensure  that
the  keys  in  your  possession  are  the
only ones which can start the vehicle.

Do not make any modiﬁ cations to

the electronic engine immobiliser
system.

Changing the remote control
battery

Reprogramming the remote
control

Following disconnection of the vehicle's

battery, replacement of the remote con-

trol battery or in the event of a remote
control malfunction, the remote control

must be reinitialised.


Switch off the ignition.



Switch the ignition on again.



Press the remote control locking but-

ton immediately for a few seconds.



Switch off the ignition and remove

the remote control key from the ig-

nition lock.

The remote control is now working

again.

ELECTRONIC ENGINE
IMMOBILISER

This locks the engine control system

a few moments after the ignition has

been switched off and therefore pre-

vents starting of the vehicle by anyone

who does not have the key.
The ignition key has an electronic chip

which has a special code. When the

ignition is switched on, the code is rec-

ognised and starting is possible.

Battery ref.: CR1620/3 volts.

The information "battery ﬂ at" is given by

displaying of the service warning light,

accompanied by an audible signal and a

message on the multi-function display.
To replace the battery, unclip the casing

using a coin at the notch.

If the remote control does not work after

the battery has been changed, repro-

gramme the remote control.

Do not discard the batteries,

they contain metals which are

harmful to the environment.

Take them to an approved col-

lection point.

Lost keys
Visit a PEUGEOT dealer with the vehicle's

V5 registration certiﬁ cate and your per-

sonal identiﬁ cation documents.

A PEUGEOT dealer will be able to re-

trieve the key code and the transponder
code required to order a replacement

key.

If the system does not function cor-
rectly,

the service warning light comes

on, accompanied by an audible signal
and a message on the multifunction

display.

In this case, your vehicle will not start.

Contact a PEUGEOT dealer as soon

as possible.

  Make  a  careful  note  of  the
number  on  each  key.  The
key number is coded on the
label attached to the key.

  If  the  keys  are  lost,  a  PEUGEOT
dealer  can  rapidly  supply  you  with
new keys.

  The  remote  control  does  not  oper-
ate  when  the  key  is  in  the  ignition,
even when the ignition is switched
off, except for reprogramming.

  Do  not  operate  the  deadlocking
function  if  there  is  anyone  inside
the vehicle.

Driving with the doors locked may
make access to the passenger com-
partment by the emergency services

more difﬁ cult in an emergency.
  As a safety precaution (with children
on  board),  remove  the  ignition  key
when you leave the vehicle, even for
a short time.

  When  purchasing  a  second-hand  ve-
hicle, have the key codes memorised
by  a  PEUGEOT  dealer  to  ensure  that
the  keys  in  your  possession  are  the
only ones which can start the vehicle.

Do not make any modiﬁ cations to

the electronic engine immobiliser
system.

ALARM

Setting the alarm



Switch off the ignition and get out

of the vehicle.



Set the alarm by locking or dead-

locking using the remote control
(button A

indicator light ﬂ ashes

once per second).

When the alarm is triggered, the siren
sounds and the direction indicators

ﬂ ash for thirty seconds.

The alarm remains set following each

triggering incident.

Unlock the vehicle with the remote

control key (button B indicator light

goes out).
Note: if the alarm has been triggered

while you were away from your car, the

rapid ﬂ ashing of the indicator light will

stop when you switch on the ignition.

Automatic activation *

The alarm is activated automatically

two minutes after the last closing of a

door or the boot.
In order to avoid accidental triggering

of the alarm when a door or the boot

is opened, it is essential to press the

remote control opening button ﬁ rst.

* According to country.

This provides two types of protection:

- exterior protection , it sounds if

a door, the boot or the bonnet is

opened.

- interior protection , it sounds if

the sensors detect a variation in

the air movement inside the ve-

hicle (breaking of a window or a

movement inside the vehicle).

  Warning:   if  the  alarm  has
been  triggered  ten  times  in
succession,  on  the  eleventh

time it becomes inactive.

Note: if button A

ﬂ ashes rapidly, the

alarm has been triggered while you

were away from your vehicle.

If you wish to lock your vehicle without

setting the alarm, use the door lock.

Peugeot 607 Dag (2009 year). Instruction - part 4
