Peugeot 508 Dag (2010.5). Instruction

275

CONFIGURATION

Press SETUP to display the
"

Conﬁ guration " menu.

Select " Adjust luminosity

" and conﬁ rm

to adjust the screen brightness.
Press " OK

" to save the changes.

The settings for day and night are

independent.

Select " Choose colour

" and conﬁ rm to

Choose colour

select the screen colour harmony and
the map presentation mode:
-

day mode,

- night mode,

- automatic day/night mode,

according to whether the

headlamps are on.

SETTING THE DATE AND TIME

Select " Set date and time " and

conﬁ rm.

Select the setting to adjust.

Conﬁ rm by pressing OK , then adjust

the setting and conﬁ rm again to save

the modiﬁ cation.

Select "

Display conﬁ guration " and

conﬁ rm.

Press SETUP to display the
"

Conﬁ guration " menu.

Select "

Display conﬁ guration " and

conﬁ rm.

Adjust the settings one by one.
Then select " OK " on the screen and

conﬁ rm to save the settings.

DISPLAY CONFIGURATION

Select " Synchronize the minutes with GPS

" so that setting the

minutes is done automatically by satellite reception.

276

"Navigation - guidance"
MENU

Enter an address

Select destination

Directory

GPS coordinates (Archive)

Journey leg and route

Add a stage

Enter an address

Directory

Previous destinations

Order/delete journey legs

Divert route

Chosen destination

Guidance options

Deﬁ ne calculation criteria

Set speech synthesis

Delete last destinations

Map management

Map orientation

Select TMC station

Automatic TMC

Manual TMC

List of TMC stations

Display/Do not display messages

SCREEN MENU MAP

MAIN FUNCTION

option A1

option A2

OPTION A

OPTION B...

Map details

Move the map/"Vehicle monitoring"

Mapping and updating

Description of risk areas database

Stop/Restore guidance

"TRAFFIC" MENU

Geographic ﬁ lter

Retain all the messages:

Retain the messages:

Around the vehicle

On the route

Set parameters for risk areas

277

12 SCREEN MENU MAP

Dial

Directory of contacts

Call list

Phone functions

Ring options

"Phone" MENU

Conﬁ guration

Delete all contacts

Import all the entries

Synchronization options

No synchronization

"Directory of contacts"
MENU

Display contacts

Open

Import

Delete

New contact

Equalizer

"RADIO" MENU

Following waveband

Options

Activate/Deactivate TA

Activate/Deactivate RDS

Audio settings

Display telephone contacts

Display SIM card contacts

Contact mem. status

Display all phone contacts

Delete calls log

Bluetooth functions

List of the paired peripherals

Connect

Disconnect

Delete

Peripherals search

Delete all

Rename radiotelephone

None

Classical

Jazz

Rock

Techno

Vocal

278

12 SCREEN MENU MAP

Random on all media

Repetition

Audio settings (same as RADIO)

Activate/Deactivate AUX input

"MEDIA" MENU

Following media source

Eject USB support

Read mode

Normal

Random

All passengers

Le-Ri balance

Fr-Re balance

Auto. Volume

Update radio list

Bass

Treble

Loudness

Distribution

Driver

Night mode

Auto Day/Night

Adjust luminosity

Set date and time

"SETUP" MENU

Display conﬁ guration

Choose colour

Harmony:

Cartography:

Day mode

Voice synthesis

Guidance instructions volume

Select male voice/Select female voice

279

FREQUENTLY ASKED QUESTIONS

The following tables groups together the answers to the most frequently asked questions concerning your audio system.

QUESTION

ANSWER

SOLUTION

The route calculation is
not successful.

The guidance criteria may conﬂ ict with the current location (exclusion of

toll roads on a toll motorway).

Check the guidance criteria on the Navigation

Menu, "Guidance options"\"Deﬁ ne calculation

criteria".

The Accident-prone area

POIs do not appear.

The Risk area POIs have not been selected

Select the Accident-prone area POIs in the list of

POIs.

The Risk area POIs have not been downloaded.

Download the Risk area POIs from the PEUGEOT
website.

The speed camera

audible warning does not

work.

The audible warning is not active.

Activate audible warnings in the Guidance options

menu, "Navigation - guidance", "Set parameters

for risk areas".

The system does not

suggest a detour around

an incident on the route.

The guidance criteria do not take account of TMC messages.

Select the "Trafﬁ c info" function in the list of

guidance criteria.

I receive a speed camera
alert for a speed camera
which is not on my route.

Other than guidance, the system announces all speed cameras

positioned in a cone located in front of the vehicle. It may provide an alert
for speed cameras located on nearby or parallel roads.

Zoom in on the map to view the exact position of

the speed camera. Select "On the route" to no

longer receive alerts other than guidance or to

reduce the time for the announcement.

280

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

Certain trafﬁ c jams

along the route are not

indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (display of the trafﬁ c information icons on

the map).

The ﬁ lters are too restrictive.

Modify the "Geographic ﬁ lter" settings.

In certain countries, only major routes (motorways...) are listed for the

trafﬁ c information.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to

receive more than 4 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

4 satellites (long press on the SETUP button, then

select "GPS coverage").

Depending on the geographical environment (tunnel...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system

is dependent on the GPS signal reception

conditions.

I cannot connect my
Bluetooth telephone.

The telephone's Bluetooth function may be switched off or the telephone

may not be visible.

- Check that your telephone's Bluetooth

function is switched on.

- Check in the telephone settings that it is

"visible to all".

The Bluetooth telephone is not compatible with the system.

A list of compatible Bluetooth mobile telephones is

available from the dealer network.

The volume of the
telephone connected
in Bluetooth mode is
inaudible.

The volume depends both on the system and on the telephone.

Increase the volume of the audio system, to

maximum if required, and increase the volume of

the telephone if necessary.

The ambient noise level has an inﬂ uence on the quality of telephone

communication.

Reduce the ambient noise level (close the windows,

reduce the booster fan speed, slow down, ...).

281

QUESTION

ANSWER

SOLUTION

Some contacts are
duplicated in the list.

The options for synchronizing contacts are synchronizing the contacts

on the SIM card, the contacts on the telephone, or both . When both

synchronizations are selected, some contacts may be duplicated.

Select "Display SIM card contacts" or "Display

telephone contacts".

Contacts are not shown
in alphabetical order.

Some telephones offer display options. Depending on the settings

chosen, contacts can be transferred in a speciﬁ c order.

Modify the display setting in the telephone

directory.

The system does not receive

SMS text messages.

The Bluetooth mode does not permit sending SMS text messages to the

system.

The CD is ejected
automatically or is not
played by the player.

The CD is inserted upside down, is unplayable, does not contain any
audio data or contains an audio format which the player cannot play.
Le CD has been recorded in a format that is not compatible with the
player.
The CD is protected by an anti-pirating protection system which is not

recognised by the audio system.

Check that the CD is inserted in the player the

right way up.

Check the condition of the CD: the CD cannot

be played if it is too damaged.

Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

- The audio system's CD player does not play

DVDs.

Some recorded CDs will not be played by
the audio system because they are not of the
correct quality.

There is a long waiting

period following the insertion

of a CD or connection of a
USB memory stick.

When a new medium is inserted, the system reads a certain amount of

data (directory, title, artist, etc.). This may take from a few seconds to a

few minutes.

This phenomenon is normal.

The CD player sound is
poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

282

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

Some characters in the
media information are not
displayed correctly while

playing.

The audio system does not display some types of characters.

Use standard characters to name tracks and
folders.

Playing of streaming ﬁ les

does not start.

The peripheral device connected does not support automatic play.

Start the playback from the device.

The names of tracks and

the track length are not

displayed on the screen

when streaming audio.

The Bluetooth proﬁ le does not allow the transfer of this information.

The quality of reception
of the radio station

listened to gradually

deteriorates or the stored
stations do not function

(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the "RDS" function by means of the

short-cut menu to enable the system to check
whether there is a more powerful transmitter in the

geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate
a fault with the audio system.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

I cannot ﬁ nd some radio

stations in the list of
stations received.

The station is not received or its name has changed in the list.

Some radio stations send other information in place of their name (the

title of the song for example).
The system interprets this information as the name of the station.

The name of the radio

station changes.

283

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

In changing the setting

of treble and bass the

equalizer setting is

deselected.

The selection of an equalizer setting imposes the balance settings.

Modifying one without the other is not possible.

Modify the balance or equalizer settings to obtain

the desired musical ambience.

In changing the equalizer

setting, treble and bass

return to zero.

When changing the

balance settings, the

distribution setting is

deselected.

The selection of a distribution setting imposes the balance settings.

Modifying one without the other is not possible.

Modify the balance or distribution settings to

obtain the desired musical ambience.

When changing an

distribution setting,

the balance setting is

deselected.

There is a difference in
sound quality between
the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings for Volume, Bass, Treble,

Equalizer and Loudness can be adapted to the different sound sources,

which may result in audible differences when changing source (radio,

CD...).

Check that the audio settings for (Volume , Bass,

Treble, Equalizer, Loudness) are adapted to

the sources listened to. It is advisable to set the

AUDIO functions (Bass, Treble, Fr-Re balance,

Le-Ri balance) to the middle position, select the

"None", musical ambience and set the loudness

correction to the "Active" position in CD mode or

to the "Inactive" position in radio mode.

284

QUESTION

ANSWER

SOLUTION

With the engine off, the

system switches off after
a few minutes of use.

When the engine is switched off, the system's operating time depends on

the battery charge.
The switch-off is normal: the system switches to economy mode and

switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

Playback of my USB
memory stick starts only

after a very long wait

(around 2 to 3 minutes).

Some ﬁ les supplied with the memory stick may greatly slow down access

to reading the memory stick (multiplication by 10 of the catalogue time).

Delete the ﬁ les supplied with the memory stick

and limit the number of sub-folders in the ﬁ le

structure on the memory stick..

When I connect my
iPhone as telephone and
to the USB port at the
same time, I am unable

to play the music ﬁ les.

When the iPhone connects automatically as a telephone, it is possible

that it connects streaming and telephone functions simultaneously. The

streaming function takes the place of the USB function which is then not

useable.

Two possible solutions (depending on the iPhone):
-

disconnect then reconnect the USB
connection (the USB function then takes the

place of the streaming function),

- go to the "Bluetooth functions"\"List of the

paired peripherals" menu, disconnect the
iPhone then reconnect it in "Hands-free
mode" only.

FREQUENTLY ASKED QUESTIONS

285

The system is coded in such a way that it will only
operate in your vehicle. If it is to be installed in another

vehicle, contact your PEUGEOT dealer for conﬁ guration

of the system.

AUDIO SYSTEM/BLUETOOTH

01 First steps

For safety reasons, the driver must only carry out

operations which require prolonged attention while

the vehicle is stationary.
When the engine is switched off and to prevent

discharging of the battery, the audio system may switch

off after a few minutes.

CONTENTS

02 Steering mounted controls

03 Main menu

04 Audio

05 Using the telephone

06 Audio settings

07 Configuration

08 Trip computer

09 Screen menu map

Frequently asked questions

287

288

289

299

308

309

310

311

313

286

FIRST STEPS

   1.   On/Off and volume adjustment.
  2.   CD eject.
  3.   Selection of the display on the screen from

the following modes:

Full screen: Audio (or if a telephone call is in

progress)/

New window: Audio (or telephone if a call is

in progress) - Time or

Trip computer

Long press: black screen (DARK).

4. Selection of source:

Radio, CD, AUX, USB, Streaming.

Accept an incoming call.

5. Selection of FM1, FM2, DAB and AM

wavebands.

6. Buttons 1 to 6:

Selection of a preset radio station.

Long press: preset a station.

7. Display the list of stations received, the

CD/MP3 tracks or folders.

Long press: MP3/WMA ﬁ le order/update the

list of stations received.

8. TA (Trafﬁ c Announcement)

function on/off.

Long press: access to the type of information.

9. Conﬁ rmation or display of contextual menu.

10. Abandon current operation

Up one level (menu or folder).

11. Automatic search for a lower/higher radio

frequency.

Selection of previous/next CD, USB,

streaming track.

Navigation in a list.

12. Manual step by step search for a lower/

higher radio frequency.

Selection of the previous/next MP3 folder.

Selection of the previous/next USB device

folder/genre/artist/playlist.

Navigation in a list.

13. Main menu.
14. Audio settings:

equalizer, treble, bass, loudness,

distribution, left/right balance, front/rear,

automatic volume.

287

- Increase volume.

- Mute/restore sound.

- Decrease volume.

- Rotation:

Radio: access to 6 preset stations:

previous/next.

Media: previous/next track.

Press: conﬁ rmation.

- Change the audio source. Long press: mute.

- Accept an incoming call.

- Access to the Telephone menu if a call is in

progress.

- Long press: reject an incoming call or end a

call in progress.

- Long press: access to the "Telephone"

menu if no call in progress.

- Select the type of permanent

display on the screen between
window and full screen modes.

- Long press: black screen (DARK).

- Radio: display the list of stations.

Media: display the list of tracks.

Long press: update the list of

stations received.

288

" Multimedia ": Media parameters,

Radio parameters.

" Trip computer ": Warning log.

rip computer

For a detailed global view of the menus

available, refer to "Screen menu maps"

in this section.

> SCREEN C

" Bluetooth connection ":

Connections management, Search

for a device.

" Telephone ": Call, Directory

management, Telephone

management, Hang up.

MAIN MENU

Personalisation-conﬁ guration ": Deﬁ ne the

vehicle parameters, Choice of language, Display

conﬁ guration, Choice of units, Date and time

adjustment.

289

04 AUDIO

Press SOURCE several times in
succession and select radio.

Press BAND to select a waveband

among: FM1, FM2, DAB (digital radio),

AM.

Press LIST to display the list of stations
received in alphabetical order.

A press changes to the next or previous

letter (e.g. A, B, D, F, G, J, K, ...).

RADIO

Select the desired radio station and

conﬁ rm by pressing OK .

SELECTING A STATION

A long press on LIST builds or updates

the list of stations; audio reception is cut
momentarily.

The exterior environment (hills, buildings, tunnel, car park, below

ground...) may prevent reception, even in RDS station tracking

mode. This phenomenon is normal in the propagation of radio

waves and is in no way indicative of a fault with the audio system.

290

RDS, if displayed, enables you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the country as radio stations do not cover

100 % of the territory. This explains the loss of reception of the

station during a journey.

AUDIO

RDS

RECEIVING TA MESSAGES

The TA (Trafﬁ c Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a trafﬁ c

report is transmitted, the current audio source (Radio, CD,

USB, ...) is interrupted automatically to play the TA message.

Normal playback of the audio source resumes at the end of the

transmission of the message.

Press TA INFO to activate or deactivate

the reception of trafﬁ c messages.

When the radio is displayed on the
screen, press OK to display the

contextual menu.

Select " RDS " or " DAB/FM auto

tracking

" and conﬁ rm to save.

" RDS " or " DAB/FM " is displayed on the

screen.

DIGITAL RADIO - DAB/FM AUTO
TRACKING

DAB/FM auto tracking allows you to continue listening to the same

station, by temporarily switching to the equivalent analogue station

until the digital signal is stable again.

The INFO function gives priority to TA alert messages. To be

active, this function needs good reception of a radio station that

transmits this type of message. When a message is transmitted,

the current audio source (Radio, CD, USB,...) is interrupted

automatically to receive the INFO message. Normal play resumes

at the end of the message transmission.

Make a long press on TA INFO to

display the list of categories.

DIGITAL RADIO - LISTENING TO
INFO MESSAGES

Select or deselect categories to activate

or deactivate the reception of the

corresponding messages.

Peugeot 508 Dag (2010.5). Instruction - part 19
