Peugeot 308 CC (2014 year). Instruction

239

The MP3 format, an abbreviation of MPEG 1.2 & 2.5 Audio Layer 3,

is an audio compression standard which permits the recording of

several tens of music ﬁ les on a single disc.

In order to be able to play a recorded CDR or CDRW, when

recording, the ISO 9660 level 1.2 or Joliet ﬁ le format is

recommended.

If the disc is recorded in another format, it may not be played

correctly.

It is recommended that the same recording format is always

used for an individual disc, with as low a speed as possible

(4x maximum) for optimum sound quality.

In the particular case of a multi-session CD, the Joliet format is

recommended.

The audio system will only play ﬁ les with the extension ".mp3" with

a sampling rate of 22.05 KHz or 44.1 KHz. No other type of ﬁ le

(.wma, .mp4, .m3u...) can be played.

It is advisable to restrict ﬁ le names to 20 characters without using

special characters (e.g. " ? ; ù) to avoid any playing or displaying

problems.

MP3 CD

Information and advice

AUDIO

Empty CDs are not recognised and may damage the system.

Insert an MP3 compilation in the player.

The audio equipment searches for all of the music tracks, which

may take anything between a few seconds and several tens of

seconds, before play begins.

MP3 CD

Playing an MP3 compilation

On a single disc, the CD player can read up to 255 MP3 ﬁ les

spread over 8 folder levels. However, it is advisable to keep to

a limit of two levels to reduce the access time before the CD is

played.

While the CD is being played, the folder structure is not followed.

All of the ﬁ les are displayed on a single level.

To play a disc which has already

been inserted, press the SOURCE

button several times in succession

and select CD.

Press one of the buttons to select a

folder on the CD.

Press the LIST REFRESH button to display the list of directories of

the MP3 compilation.

Press and hold one of the buttons for

fast forward or backward play.

Press one of the buttons to select a

track on the CD.

240

The display and control is via the portable device.

First adjust the volume of your portable device.

Then adjust the volume of your audio

system.

Using the auxiliary socket (AUX)

Adjusting the volume of the auxiliary source

RCA sockets

AUDIO

Do not connect a device to both the RCA sockets and the USB

port at the same time.

Connect the portable device

(MP3 player…) to the audio

sockets (white and red, RCA

type) using a suitable JACK /

RCA cable (not supplied).

Press the SOURCE button several

times in succession and select AUX.

The RCA auxiliary sockets permit the connection of a portable

device (MP3 player...).

241

PEUGEOT CONNECT USB

The system puts together playlists (temporary memory) created

over a period which depends on the capacity of the USB device.

The other sources are available during this time.

The playlists are updated each time the ignition is switched off or

each time a USB memory stick is connected.

When connecting for the ﬁ rst time, the classiﬁ cation suggested

is by folder. When you reconnect, the classiﬁ cation selected

previously is retained.

Connect the memory stick to the port, directly or

using a lead. If the audio equipment is switched

on, the USB source is detected as soon as it

is connected. Play begins automatically after a

delay which depends on the capacity of the USB

memory stick.

The ﬁ le formats supported are .mp3 (mpeg1

layer 3 only) and .wma (standard 9 only,

128 kbits/sec compression).

Certain playlist formats are supported (.m3u, ...)

On reconnection of the previous memory stick

used, play is resumed automatically with the last

track played.

You have a USB port. The

audio ﬁ les are transmitted

from a portable device - digital

player or a USB memory

stick - to your PEUGEOT

Connect Sound (RD5) and

heard via the vehicle's

speakers.

USB memory stick (1.1, 1.2 and 2.0) or Apple

player of

generation 5 or later:

- USB memory sticks should be formatted FAT or FAT 32

(NTFS not supported),

the Apple

player lead is essential,

- navigation through the ﬁ le database is also possible by

means of the steering mounted controls.

Using the PEUGEOT CONNECT USB

Connecting a USB memory stick

Other Apple

players of earlier

generations and players using

the MTP protocol * :

- play only via a JACK /

RCA lead (not supplied)

connected to the RCA

sockets,

navigation through the

ﬁ le database is from the

portable device.

* Depending on vehicle.

242

Using the PEUGEOT CONNECT USB

Press LIST brieﬂ y to display the

previously selected classiﬁ cation.

Navigate through the list using the left/

right and up/down buttons.

Conﬁ rm the selection by pressing OK.

The lists available are Artist, Genre and Playlist (as deﬁ ned in

the Apple

player).

Selection and Navigation are described in steps 1 to 4 above.

Do not connect a hard disk or USB connection device other

than audio equipment to the USB port. This could damage your

installation.

Connecting an Apple

Connecting an Apple player via the USB port

Press one of these buttons to gain

access to the previous / next track on

the classiﬁ cation list currently being

played.

Press and hold one of the buttons for

fast forward or backward play.

Press one of these buttons to

gain access to the previous / next

Genre, Folder, Artist or Playlist on

the classiﬁ cation list currently being

played.

Press and hold LIST to display the

different classiﬁ cations.

Select by Folder / Artist / Genre / Playlist,

press OK to select the classiﬁ cation

required, then press OK again to conﬁ rm.

- by Folder: all folders containing audio

ﬁ les recognised on the peripheral

device.

- by Artist: all of the artist names

deﬁ ned in the ID3 Tags, classiﬁ ed in

alphabetical order.

- by Genre: all of the genres deﬁ ned in

the ID3 Tags.

- by Playlist: in accordance with the

playlists recorded on the USB device.

PEUGEOT CONNECT USB

243

BLUETOOTH

For safety reasons and because they require prolonged attention

on the part of the driver, the operations for pairing of the Bluetooth

mobile telephone with the Bluetooth hands-free system of your

audio equipment must be carried out with the vehicle stationary

and the ignition on.

Press the MENU button.

A window is displayed with a message that a search is in progress.

Activate the telephone's Bluetooth function

and ensure that it is "visible to all" (telephone

conﬁ guration.

In the menu, select:

Bluetooth telephone function -

Audio

- Bluetooth conﬁ guration

Perform a Bluetooth search

The services offered depend on the network, the SIM card and the

compatibility of the Bluetooth equipment used.

Consult your telephone's manual and your operator to ﬁ nd out which

services are available to you.

Bluetooth telephone

Screen C

The TELEPHONE menu permits access to the following functions

in particular: Directory * , Call list, Pairing management.

The ﬁ rst 4 telephones recognised are displayed in this window.

A virtual keypad is displayed in the

screen: enter a code with at least 4 digits.

Conﬁ rm by pressing OK.

A message that the pairing has been successful appears in the

screen.

Select the telephone to be connected from the list. Only one

telephone can be connected at a time.

A message is displayed in the screen of the

telephone chosen. To accept the pairing, enter the

same code on the telephone, then conﬁ rm with OK.

The automatic connection authorised is only active after the

telephone has been conﬁ gured.

The directory and the call list can be accessed after the

synchronisation period.

(Available according to model and version)

* If your telephone is fully compatible.

If pairing fails, the number of attempts is not limited.

Go to www.peugeot.co.uk for more information (compatibility,

more help, ...).

Pairing a telephone / First connection

244

Receiving a call

An incoming call is announced by a ring and a superimposed

display in the vehicle's screen.

Select the YES tab on the display

using the buttons and conﬁ rm by

pressing OK.

Press this button to accept the call.

Making a call

From the Bluetooth telephone function Audio menu, select Manage

the telephone call then Call, Call list or Directory.

Press this button for more than two seconds for

access to your directory, then navigate with the

thumb wheel.

To dial a number, use your telephone's keypad,

with the vehicle stationary.

BLUETOOTH

The system accesses the telephone's contacts directory, depending

on compatibility, and while the Bluetooth connection with it is

maintained.

With certain telephones connected by Bluetooth you can send

a contact to the directory of the audio system.

Contacts imported in this way are saved in a permanent directory

visible to all, whatever the telephone connected.

The menu for the directory is not accessible if it is empty.

245

Initiate the pairing between the telephone and

the vehicle. This pairing can be initiated from

the vehicle's telephone function menu or via the

telephone's keypad. Refer to the steps in "Pairing

a telephone" on the previous pages. During the

pairing phase, the vehicle must be stationary with

the key in the ignition.

Select the telephone to be connected from the telephone function

menu.

The audio system connects to a newly paired telephone automatically.

Bluetooth audio streaming *

Wireless transmission of music ﬁ les on the telephone, played via

the audio equipment. The telephone must be able to manage the

appropriate Bluetooth proﬁ les (Proﬁ les A2DP / AVRCP).

* Depending on the compatibility of the telephone.

** In certain cases, playing of the Audio ﬁ les must be initiated from the

keypad.

*** If the telephone supports the function.

Activate the streaming source by

pressing the SOURCE button ** .

The tracks to be played can be

controlled as usual via the buttons on

the audio system control panel and

the steering mounted controls *** .

The contextual information can be

displayed on the screen.

During a call, press this button for more than

2 seconds.

Conﬁ rm with OK to end the call.

Ending a call

BLUETOOTH

246

SCREEN MENU MAP(S)

activate / deactivate RDS

activate / deactivate REG mode

activate / deactivate radiotext

RADIO

activate / deactivate Intro

CD / MP3 CD

activate / deactivate track repeat

(the entire current CD for CD, the entire

current folder for MP3 CD)

activate / deactivate random play

(the entire current CD for CD, the entire

current folder for MP3 CD)

activate / deactivate track repeat (of the

current folder / artist / genre / playlist)

USB

activate / deactivate random play (of the

current folder / artist / genre / playlist)

Screen C

Press the OK dial for access to short-cut menus according

to the display in the screen:

247

SCREEN MENU MAP(S)

Audio functions

Alternative frequencies (RDS)

activate / deactivate

FM waveband settings

Regional mode (REG)

activate / deactivate

Radio-text information (RDTXT)

activate / deactivate

Play modes

Album repeat (RPT)

activate / deactivate

Track random play (RDM)

activate / deactivate

Vehicle diagnostics

Alert log

Screen C

Pressing the MENU button displays:

07 SCREEN MENU MAP(S)

Bluetooth telephone

Connect/Disconnect an equipment

Consult the paired equipment

Bluetooth conﬁ guration

Telephone function

Audio Streaming function

Delete a paired equipment

Perform a Bluetooth search

Calls list

Call

Directory

Terminate the current call

Manage the telephone call

Activate secret mode

Video brightness adjustment

Display conﬁ guration

Deﬁ ne the vehicle settings *

Personalisation-Configuration

normal video

inverse video

brightness (- +) adjustment

Date and time adjustment

day/month/year adjustment

hour/minute adjustment

choice of 12 h / 24 h mode

Choice of units

l/100 km - mpg - km/l

°Celsius / °Fahrenheit

Choice of language

* The parameters vary according to vehicle.

249

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

There is a difference in

sound quality between

the different audio

sources (radio, CD...).

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source

(radio, CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to

the sources listened to. It is advisable to set

the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle

position, select the musical ambience "None" and

set the loudness correction to the "Active" position

in CD mode or to the "Inactive" position in radio

mode.

The CD is ejected

automatically or is not

played by the player.

The CD is inserted upside down, is unplayable, does not contain any

audio data or contains an audio format which the player cannot play.

The CD is protected by an anti-pirating protection system which is not

recognised by the audio equipment.

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio" section.

- The audio equipment's CD player does not

play DVDs.

- Due to their quality level, certain writeable

CDs will not be played by the audio system.

The message "USB

peripheral error" is

displayed on the screen.

The Bluetooth connection

is cut.

The battery of the peripheral may not be sufﬁ ciently charged.

Recharge the battery of the peripheral device.

The USB memory stick is not recognised.

The memory stick may be corrupt.

Reformat the memory stick.

250

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

I am unable to access my

voicemail.

Few telephones or service providers allow the use of this function.

The CD player sound is

poor.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in suitable

conditions.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting

an ambience.

The stored stations do

not function (no sound,

87.5 Mhz is displayed...).

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the

stations are stored.

The trafﬁ c announcement

(TA) is displayed. I do

not receive any trafﬁ c

information.

The radio station is not part of the regional trafﬁ c information network.

Tune to a radio station which broadcasts trafﬁ c

information.

The quality of reception

of the radio station

listened to gradually

deteriorates or the stored

stations do not function

(no sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened

to or there is no transmitter in the geographical area through which the

vehicle is travelling.

Activate the RDS function to enable the system

to check whether there is a more powerful

transmitter in the geographical area.

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

This phenomenon is normal and does not indicate

a failure of the audio equipment.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

Have the aerial checked by a PEUGEOT dealer.

251

FREQUENTLY ASKED QUESTIONS

QUESTION

ANSWER

SOLUTION

Sound cut-outs of 1 to

2 seconds in radio mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon is

too frequent and always on the same route.

With the engine off,

the audio equipment

switches off after a few

minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.

The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

Start the vehicle's engine to increase the battery

charge.

The message "the audio

system is overheated"

appears on the display.

In order to protect the installation if the surrounding temperature is too

high, the audio equipment switches to an automatic thermal protection

mode leading to a reduction of the volume or stopping of the playing of

the CD.

Switch the audio system off for a few minutes to

allow the system to cool.

252

VISUAL SEARCH

EXTERIOR

Boot ......................................71, 73

Temporary puncture

repair kit ...........................140-144

Changing a wheel ..............145-148

- tools

- removing / reﬁ tting

Changing bulbs..................153-154

- rear lamps

- 3rd brake lamp

- number plate lamps

Parking sensors .................128-129

Towbar ......................................167

Towing ...............................165-166

Remote control key................61-65

- opening / closing

- unlocking / partial opening of

the boot

- anti-theft protection

- starting

- battery

Accessories .......................168-169

Retractable roof .........................6-7

Fuel tank ................................74-75

Door mirrors ...........................58-59

Side spotlamps ...................80, 152

Doors .....................................70-72

- opening / closing

- central locking

- emergency locking

Alarm .....................................66-67

Electric windows ....................68-69

Lighting controls ....................76-80

Directional lighting ......................81

Headlamp height adjustment ....80-81

Changing bulbs..................150-152

- front lamps

- foglamps

- direction indicator repeaters

Braking assistance .....................94

Trajectory control ........................95

Tyre under-inflation

detection ..........................122-123

Snow chains .............................149

Tyre pressures ..........122, 144, 175

253

VISUAL SEARCH

INTERIOR

Boot fittings ............................91-92

- stowing rings

- luggage retaining net

- luggage retaining strap

- storage net

- storage box

Installing the windstop ...........50-52

Child seats .................104-109, 113

ISOFIX child seats ............. 110-112

Rear seats ..................................57

Front seats.............................53-57

"AIRWAVE" systems ...................56

Seat belts...............................97-99

Airbags ..............................100-103

Deactivating the passenger's front

airbag .............................101, 105

Interior fittings ........................86-90

- lockable glove box

- mat

- lockable front armrest

Roll-over bars .............................96

254

VISUAL SEARCH

INSTRUMENTS AND CONTROLS

Multifunction screens .............39-44

Hazard warning lamps ................93

Switch panel ...............................15

Emergency and assistance

call ....................................94, 177

Instrument panels ..................21-22

Warning lamps .......................23-30

Indicators ...............................31-34

Buttons ..................................35-36

- Check / service indicator /

trip distance recorder

- lighting dimmer

Lighting controls ....................76-80

Headlamp height adjustment ....80-81

Stop & Start .......................119-121

Speed limiter......................124-125

Cruise control ....................126-127

Door mirrors ...........................58-59

Electric windows ....................68-69

Dashboard fuses ...............155-157

Opening the bonnet ..................131

Steering wheel adjustment .........60

Horn ............................................93

Courtesy lamps...........................84

Seat belt / passenger's front airbag

warning lamps display ..............97

Rear view mirror .........................60

Sun visor.....................................87

Wiper controls........................82-84

Trip computer ........................37-38

PEUGEOT Connect

Navigation (RT6) .............179-232

Setting the date/time...................43

PEUGEOT Connect Sound .....233-251

Setting the date/time...................41

Ventilation ..............................45-46

Digital air conditioning ...........48-49

Demisting - defrosting

the rear screen .........................47

Parking brake ........................... 114

Manual gearbox ........................ 114

Gear shift indicator ................... 115

Automatic gearbox............. 116-118

"AIRWAVE" system controls .......56

Retractable roof control .............6-7

Control for all four windows ........69

Peugeot 308 CC (2014 year). Instruction - part 16
