Peugeot 308 CC (2014 year). Instruction

207

USING THE TELEPHONE

Calling a recently entered number

Press

TEL , select " Call list " and

conﬁ rm,

Select the desired number and conﬁ rm.

To erase the calls log, press

PHONE twice, select " Phone

functions " and conﬁ rm then select " Delete calls log " and conﬁ rm.

Ending a call

Press

PHONE then select " OK " to end

the call.

Or make a long press on

TEL at the

steering mounted controls.

Or make two short presses on

TEL at

the steering mounted controls.

Or press the

MODE button, as many

times as necessary, until the telephone

screen is displayed.

Press

PHONE to display the calls log.

Press "

OK " to display the contextual

menu then select "

Hang up " and

conﬁ rm.

It is always possible to start a call directly from the telephone; park

the vehicle as a safety measure.

208

USING THE TELEPHONE

Receiving a call

An incoming call is announced by a ring and a superimposed display

on the screen.

Yes

" "

" to accept the call is selected by

default.

Press "

OK " to accept the call.

Select "

No " and conﬁ rm to reject the

call.

A short press on

TEL accepts an

incoming call.

A long press on

TEL rejects an incoming

call.

209

Options during a call *

During a call, press the

MODE button

several times to select display of the

telephone screen, then press "

OK " to

open the contextual menu.

Select "

Private mode " and conﬁ rm to

take the call on the handset.

Or select "

Hands-free mode " and

conﬁ rm to take the call via the vehicle's

speakers.

Select "

Put call on hold " and conﬁ rm to

put the current call on hold.

Or select "

Resume the call " and

conﬁ rm to resume the call on hold.

Select "

DTMF ring tones " to use the

numerical keypad, so as to navigate

through the menu of an interactive vocal

server.

Select "

Hang up " to end the call.

* Depending on the compatibility of the phone and your service plan.

it is possible to hold a 3-way conference

call by making 2 calls in succession*.

Select "

Conference mode call " in the

contextual menu accessible using this

button.

Or make a short press on this button.

USING THE TELEPHONE

Press

PHONE twice.

Select "

List of the paired peripherals "

and conﬁ rm.

It is possible to:

Connect " or " Disconnect " the

selected telephone,

- delete the pairing of the selected

telephone.

It is also possible to select all pairings.

Managing paired telephones

Changing the ringtone

Press

PHONE twice.

Select "

Phone functions " and conﬁ rm.

Select "

Ring options " and conﬁ rm.

You can adjust the volume and the type

of ringtone.

Select "

Bluetooth functions ".

Select "

OK " and conﬁ rm to save the

changes.

USING THE TELEPHONE

" " " " " " " " " " " " " " " " " " "

FM / AM band

FM / AM band " " " " " " " " " " " " " " " " " " "

Press  or  or use the rotary control to select

the previous or next station in the list.

Go from the list to the menu (left/right).

Press

RADIO .

RADIO

Access to the "RADIO" menu

212

By alphabetical list

Press

RADIO , select the station of your

choice and conﬁ rm.

By automatic frequency search

Press  or  for the automatic search

for a lower or higher radio frequency.

Or turn the thumb wheel at the steering

mounted controls.

By manual frequency search

Press  or  to adjust the radio

frequency step by step.

Selecting a station

The external environment (hill, building, tunnel, underground car park…) may interfere with the reception, including in RDS station tracking mode.

This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.

The quality of reception is represented by the number of

active waves in this symbol.

Press

RADIO or OK to display the

contextual menu.

Changing waveband

Select "

Change waveband ".

Select "

AM / FM " and conﬁ rm.

RADIO

213

Press the button on the numerical keypad to recall a

preset station.

Or press then turn the thumb wheel at the steering

mounted controls.

Presetting a station

After selecting a station, press one of the buttons

on the numerical keypad for 2 seconds to preset

the current station.

An audible signal conﬁ rms that the station has been

preset.

Press

RADIO .

Activate / Deactivate RDS

RDS, if activated, allows you to continue listening to the same

station by automatic retuning to alternative frequencies. However,

in certain conditions, coverage of an RDS station may not be

assured throughout the entire country as radio stations do not

cover 100 % of the territory. This explains the loss of reception

of the station during a journey.

Select "

Guidance options " then

conﬁ rm.

Activate or deactivate "

RDS " then

conﬁ rm.

RADIO

214

" " " " " " " " " " " " " " " " " " "

MEDIA

MEDIA " " " " " " " " " " " " " " " " " " "

Go from the list to the menu (left/right).

Press

MUSIC .

MUSIC MEDIA PLAYERS

Access to the "MUSIC MEDIA PLAYER" menu

215

CD, MP3 CD / USB player

The audio equipment will only play audio ﬁ les with ".wma, .aac, .ﬂ ac,

.ogg and .mp3" ﬁ le extensions and with a bit rate of between 32 Kbps

and 320 Kbps.

It also supports VBR (Variable Bit Rate) mode.

No other type of ﬁ le (.mp4, .m3u…) can be played.

WMA ﬁ les must be of the standard wma 9 type.

The sampling rates supported are greater than 32 KHz.

It is advisable to restrict ﬁ le names to 20 characters, without using of

special characters (e.g.: " " ? ; ù) to avoid any playing and displaying

problems.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.

If the disc is recorded in another format (udf, …), it may not be played

correctly.

It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.

In the particular case of a multi-session CD, the Joliet standard is

recommended.

Information and advice

The system supports USB mass storage or iPod devices via the USB

port (suitable cable not supplied).

If a partitioned USB memory key is connected to the system, only the

ﬁ rst partition is recognised.

Control of the peripheral device is with the audio system controls.

The number of tracks is limited to 2000 maximum, 999 tracks per

folder.

If the current consumption at the USB port exceeds 500 mA, the

system goes into protection mode and deactivates the port.

Other peripherals, not recognised on connection, must be connected

to the auxiliary socket using a Jack cable (not supplied).

In order to be read, a USB memory stick must be formatted

FAT 16 or 32.

The system does not support the operation of an Apple

player and a

USB memory stick connected at the same time.

It is recommended that ofﬁ cial Apple

USB cables are used to ensure

correct operation.

MUSIC MEDIA PLAYERS

216

Insert the CD in the player, insert the USB

memory stick in the USB player or connect

the USB peripheral to the USB port using a

suitable cable (not supplied) .

The system builds playlists (in temporary

memory), an operation which can take from

a few seconds to several minutes at the ﬁ rst

connection.

Reduce the number of non-music ﬁ les and

the number of folders to reduce the waiting

time.

The playlists are updated every time the

ignition is switched off or connection of a

USB memory stick. However, the system

memorises these lists and if they are not

modiﬁ ed, the loading time will be shorter.

Play starts automatically after a period which

depends on the capacity of the USB memory

stick.

Selection of source

The

SOURCE button on the steering mounted controls allows a

direct change to the next media source.

CD / CD MP3 "

USB, iPod "

AUX "

STREAMING "

RADIO "

Press

MUSIC to display the " MEDIA "

menu.

Select "

Following media source " and

conﬁ rm.

Repeat the operation as many times as necessary to obtain the

desired media source (except for radio which is accessible either

with

SOURCE or RADIO ).

Sources

MUSIC MEDIA PLAYERS

217

Selecting a track

Previous track.

Next track.

Previous folder.

Next folder.

Fast forward.

Fast backward.

Pause: long press on

SRC .

MUSIC: List of USB or CD tracks or

folders

Up or down in the list.

Conﬁ rm, next menu level.

Up one menu level.

Long press

MUSIC MEDIA PLAYERS

218

Audio streaming

Streaming allows audio ﬁ les on your telephone to be played via the

vehicle's speakers.

Connect the telephone: see "

USING THE TELEPHONE ".

Select "

Audio " or " All " proﬁ le.

If play does not start automatically, it may be necessary to start the

audio playback from the telephone.

Control is from the peripheral device or by using the audio system

buttons.

Once connected in streaming mode, the telephone is considered to be

a media source.

It is recommended that you activate "

Repeat " on the Bluetooth

peripheral.

MUSIC MEDIA PLAYERS

Connecting APPLE

Connecting APPLE players

Connect the Apple

player to the USB port using a suitable cable (not

supplied).

Play starts automatically.

Control is via the audio system.

The classiﬁ cations available are those of the portable device

connected (artists / albums / genres / playlists / audiobooks /

podcasts).

The default classiﬁ cation used is by artist. To modify the classiﬁ cation

used, return to the ﬁ rst level of the menu then select the desired

classiﬁ cation (playlists for example) and conﬁ rm to go down through

the menu to the desired track.

The "Shufﬂ e tracks" mode on an iPod

corresponds to the "Random"

mode on the audio system.

The "Shufﬂ e albums" mode on an iPod

corresponds to the "Random

all" on the audio system.

"Shufﬂ e tracks" is restored by default on each connection.

The version of software in the audio system may not be compatible

with the generation of your Apple

player.

219

MUSIC MEDIA PLAYERS

USING THE AUXILIARY INPUT (AUX)

JACK/RCA AUDIO CABLE NOT SUPPLIED

Connect the portable device (MP3,

WMA player…) to the RCA audio

sockets (white and red) using a JACK-

RCA audio cable.

Press

MUSIC to display the " MUSIC "

menu.

Select "

Activate / Deactivate AUX

input " and conﬁ rm.

First adjust the volume of your portable

device (to a high level). Then adjust the

volume of your audio system.

Display and management of the controls are via the portable device.

220

AUDIO SETTINGS

They are accessible by the

MUSIC

button in the control panel or by a long

press on

RADIO according to the source

in use.

Equalizer " (choice of 6 musical ambiences)

Equalizer

Bass "

Treble "

Loudness " (Activate/Deactivate)

Distribution " (" Driver ", "

Driver

Driver All passengers ")

Le-Ri balance " (Left/Right)

Fr-Re balance " (Front/Rear)

Auto. Volume " depending on road speed (Activate/Deactivate)

The audio settings (

Equalizer ,

Equalizer

Equalizer Bass , Treble and Loudness ) are

different and independent for each sound source.

The settings for distribution and balance are common to all sources.

The distribution (or spatialisation using the Arkamys

system) of sound

is an audio process that allows the audio quality to be adapted to the

number of listeners in the vehicle.

On-board audio: Arkamys

Sound Staging.

With Sound Staging, the driver and passengers are immersed in an

"audio scene" recreating the natural atmosphere of an auditorium:

truly a part of the scene and its surroundings.

This new sensation is made possible by software in the audio system

which processes the digital signals from the media players (radio,

CD, MP3…) without changing the audio settings. This processing

takes account of the characteristics of the passenger compartment to

produce optimum results.

The Arkamys

software installed in your audio system processes

the digital signal from the media players (radio, CD, MP3, …) and

recreates a natural musical scene, with harmonious placement of

instruments and voices in the space in front of passengers, level with

the windscreen.

221

CONFIGURATION

Press

SETUP to display the

Conﬁ guration " menu.

Select "

Choose colour " and conﬁ rm to

Choose colour

select the screen colour harmony and

the map presentation mode:

day mode,

night mode,

automatic day/night mode,

according to whether the

headlamps are on.

Select "

Adjust luminosity " and conﬁ rm

to adjust the screen brightness.

Press "

OK " to save the changes.

The settings for day and night are

independent.

Select "

Display conﬁ guration " and

conﬁ rm.

Display configuration

222

SCREEN MENU MAP(S)

"Navigation - guidance"

MENU

Enter an address

Select destination

Directory

GPS coordinates

Journey leg and route

Add a stage

Enter an address

Peugeot 308 CC (2014 year). Instruction - part 14
