Peugeot 307 CC Dag (2007.5). Instruction - part 2

INSTRUMENTS and CONTROLS

OPERATION WARNING
LIGHTS

A permanently lit warning light or

one that l ashes with the engine run-

ning,  indicates  an  operating  fault
in  the  relevant  unit.  Some  warning
lights may be linked to buzzers and
a message on the multifunction dis-
play.  Do  not  ignore  this  warning:
contact a PEUGEOT dealer as soon
as possible.
  If  the  Central  STOP  warning  light
comes  on  when  you  are  driving,
stop immediately where it is safe to
do so.

  Central STOP
warning light
This  light  comes  on

for a few seconds

each time the igni-

tion is switched on.

It is linked to the "engine oil pres-

sure" * , "low brake l uid level'' and

"electronic brake force distribution

fault'' warning lights and the ''coolant

temperature'' gauge.

Stop immediately if it l ashes with

the engine running.
Contact a PEUGEOT dealer.
It also comes on if a wheel is punc-

tured, accompanied by an audible

signal and a message on the multi-

function display locating the wheel

concerned.

Service warning light
This light comes on for a

few seconds each time

the ignition is switched on.

If it remains on or comes

on when the engine is running, ac-

companied by an audible signal and

a message on the multifunction dis-

play, it indicates one of the following:

- a battery charge fault * ,

- an automatic gearbox operation

fault,

- an engine immobiliser system

fault,

- an engine management system

fault,

- a speed control system fault

(cruise control/speed limiter),

- a rear parking assistance system

fault,

- an automatic switching on of the

lights system fault,

- an automatic headlamp adjust-

ment system fault,

- a tyre under-inl ation detection

system fault,

- a del ated wheel,

- a l at remote control battery,

- one or more door(s) open at a vehi-

cle speed above 6 mph (10 km/h),

- a low diesel additive reservoir

level (Diesel),

- a lack of engine oil,

- the start of saturation of the par-

ticle emission i lter (Diesel) due

to exceptionally prolonged urban

driving conditions: low speed,

long trafi c jams, ...

In order to regenerate the i lter, it

is advisable to drive at a speed of

40 mph (60 km/h) or more for at

least i ve minutes (until the warn-

ing light is switched off) as soon

as possible when trafi c condi-

tions permit. If the warning light

remains on, contact a PEUGEOT
dealer.

During regeneration of the par-

ticle emission i lter, relay noise

may be heard under the fascia

panel.

- the presence of water in the die-

sel i lter (Diesel) *

There is a risk of damage to the

injection system.

Contact a PEUGEOT dealer as

soon as possible.

- a low coolant level ** .

Stop immediately.

Warning:

wait for the engine to

cool before topping up the level.

The cooling system is pressu-

rised.

In order to avoid any risk of scald-

ing, unscrew the cap by two turns

to allow the pressure to drop.

When the pressure has dropped,

remove the cap and top up the

level.

Contact a PEUGEOT dealer.

* According to country.

** According to engine.

INSTRUMENTS and CONTROLS

  Air bags and rear, protective, pop-
up roll-over hoops warning light
This  comes  on  for  a  few

seconds each time the igni-

tion is switched on.

Illumination of this warning light, with

the engine running, is accompanied by

an audible signal and a message on

the multifunction display indicating:

- a fault in the front air bags or side

air bags,

or
- a fault in the pop-up roll-over hoops,

located in the rear head restraints.

Contact a PEUGEOT dealer.

  Passenger air bag
disarmed indicator light *
This  comes  on  for  a  few

seconds each time the igni-

tion is switched on.

If the passenger air bag is disarmed,

the indicator light remains on.
In all cases, if the indicator light l ash-

es, contact a PEUGEOT dealer.

Emission control system
warning light
This comes on each time

the ignition is switched on.

It should switch off a few seconds af-

ter the engine is started.
If the light comes on when the engine

is running, accompanied by an audible

signal and a message on the multifunc-

tion display, this indicates a malfunc-

tion of the emission control system.
Contact a PEUGEOT dealer as soon

as possible.

Anti-lock braking system
(ABS) warning light
This light comes on for a

few seconds each time the

ignition is switched on.

If it remains on or comes on above

8 mph (12 km/h), this indicates a

malfunction of the ABS.
However, the vehicle retains conven-

tional servo-assisted braking.

Illumination of this light is accompa-

nied by an audible signal and a mes-

sage on the multifunction display.
Contact a PEUGEOT dealer.

Electronic stability
programme (ESP/ASR)
warning light
This comes on for a few

seconds each time the

ignition is switched on.

If the light remains on or comes on

when the engine is running and the

vehicle is moving, it is accompanied

by an audible signal and a message

on the multifunction display; contact

a PEUGEOT dealer.
When the engine is running and the

vehicle is moving, it l ashes if the

system is activated.
It is lit permanently when it is disarmed.

Handbrake, low brake

l uid level and electronic

brake force distribution
fault warning light
Linked to the central STOP

warning light.

This comes on for a few seconds each

time the ignition is switched on.

Illumination of this light is accompa-

nied by an audible signal and a mes-

sage on the multifunction display

indicating:

- that the handbrake is applied or

has not been released correctly,

when the vehicle is moving,

- an excessive drop in the brake

l uid (if the light remains on even

with the handbrake released),

- a malfunction of the electronic

brake force distribution, if linked

to the ABS warning light.

Stop immediately

in the last two cases.

Contact a PEUGEOT dealer.

Seat belt unfastened/not
fastened warning light
When

the

ignition

switched on, the light comes

on if the driver has not fastened his
seat belt.
With the engine running and the

doors closed, the light goes out auto-

matically after 30 seconds.
If the seat belt is unfastened:

- below 12 mph (20 km/h), the light

comes on constantly,

- above 12 mph (20 km/h) and for

two minutes, the light l ashes ac-

companied by an audible signal

of increasing volume. Once these

two minutes have elapsed, the

light remains on until the driver
fastens his seat belt.

* According to country.

INSTRUMENTS and CONTROLS

Engine oil pressure warning *
Linked to the central STOP

warning

light.
When the engine is running, the en-

gine oil pressure warning message is

accompanied by an audible signal.
Stop immediately.
If there is a lack of oil in the lubrica-

tion circuit, top up the level.
Contact a PEUGEOT dealer as soon

as possible.

Diesel engine pre-heat
warning light
This comes on for a few

seconds each time the igni-

tion is switched on.

Wait until it is switched off before op-

erating the starter.

  Battery charge warning
light *
This  comes  on  for  a  few

seconds each time the igni-

tion is switched on.

The illumination of this warning light

when the engine is running is accom-

panied by an audible signal and a

message on the multifunction display.

Depending on the country, this warn-

ing light may be replaced by the serv-

ice warning light.

It may indicate:

- faulty operation of the charging

circuit,

Low fuel level
warning light
This comes on for a

few seconds each

time the ignition is

switched on.

When this light comes on with the en-

gine running, it is accompanied by an

audible signal and a message on the

multifunction display.

When the warning light comes on,

you have enough fuel to drive approx-

imately 30 miles (50 km). The tank ca-

pacity is approximately 60 litres.

  Engine oil pressure
warning light *
Linked to the central  STOP

warning light.

The illumination of this warning light,

when the engine is running, is accom-

panied by an audible signal and a mes-

sage on the multifunction display.

- slack battery or starter terminals,

- a cut or slack alternator belt,

- an alternator failure.
Contact a PEUGEOT dealer.

When the needle is in zone A , the

temperature is correct.
When the needle is in zone B , the

temperature is too high. The central

STOP

warning light l ashes, accom-

panied by an audible signal and a

message on the multifunction dis-

play.
You must stop immediately.
Warning:

wait for the engine to cool

before topping up the level.

The cooling system is pressurised.
In order to avoid any risk of scalding,

unscrew the cap two turns to allow

the pressure to drop.

When the pressure has dropped, re-

move the cap and top up the level.
Contact a PEUGEOT dealer.

Coolant temperature indicator

* According to country.

Stop immediately.
If there is a lack of oil in the lubrica-

tion circuit, top up the level.
Contact a PEUGEOT dealer as soon

as possible.

INSTRUMENTS and CONTROLS

Engine oil pressure warning *
Linked to the central STOP

warning

light.
When the engine is running, the en-

gine oil pressure warning message is

accompanied by an audible signal.
Stop immediately.
If there is a lack of oil in the lubrica-

tion circuit, top up the level.
Contact a PEUGEOT dealer as soon

as possible.

Diesel engine pre-heat
warning light
This comes on for a few

seconds each time the igni-

tion is switched on.

Wait until it is switched off before op-

erating the starter.

  Battery charge warning
light *
This  comes  on  for  a  few

seconds each time the igni-

tion is switched on.

The illumination of this warning light

when the engine is running is accom-

panied by an audible signal and a

message on the multifunction display.

Depending on the country, this warn-

ing light may be replaced by the serv-

ice warning light.

It may indicate:

- faulty operation of the charging

circuit,

Low fuel level
warning light
This comes on for a

few seconds each

time the ignition is

switched on.

When this light comes on with the en-

gine running, it is accompanied by an

audible signal and a message on the

multifunction display.

When the warning light comes on,

you have enough fuel to drive approx-

imately 30 miles (50 km). The tank ca-

pacity is approximately 60 litres.

  Engine oil pressure
warning light *
Linked to the central  STOP

warning light.

The illumination of this warning light,

when the engine is running, is accom-

panied by an audible signal and a mes-

sage on the multifunction display.

- slack battery or starter terminals,

- a cut or slack alternator belt,

- an alternator failure.
Contact a PEUGEOT dealer.

When the needle is in zone A , the

temperature is correct.
When the needle is in zone B , the

temperature is too high. The central

STOP

warning light l ashes, accom-

panied by an audible signal and a

message on the multifunction dis-

play.
You must stop immediately.
Warning:

wait for the engine to cool

before topping up the level.

The cooling system is pressurised.
In order to avoid any risk of scalding,

unscrew the cap two turns to allow

the pressure to drop.

When the pressure has dropped, re-

move the cap and top up the level.
Contact a PEUGEOT dealer.

Coolant temperature indicator

* According to country.

Stop immediately.
If there is a lack of oil in the lubrica-

tion circuit, top up the level.
Contact a PEUGEOT dealer as soon

as possible.

INSTRUMENTS and CONTROLS

When the engine is running, this indi-

cates the oil temperature.

The temperature is too high if the

maximum graduation is reached.
  You must stop immediately.
Contact a PEUGEOT dealer.

Park

Automatic gearbox lever
positions indicator

In the event of under-revving or over-

revving, the gear selected l ashes for

a few seconds, then the actual gear

engaged is displayed.

Reverse

Neutral

Drive

Manual mode:

1st gear engaged

2nd gear engaged

3rd gear engaged

4th gear engaged

This comes on when the au-

tomatic gearbox "SPORT"

operating programme is se-

lected.

This comes on when the au-

tomatic gearbox "SNOW"

operating programme is se-

lected.

This is displayed if a gear

is not engaged correctly

(selector between two posi-

tions).

"SNOW" indicator light

Invalid value during manual
operation

"SPORT" indicator light

Engine oil temperature
indicator

Automatic gearbox indicator
lights

INSTRUMENTS and CONTROLS

After switching on the ignition, three

functions are shown in succession:

- service indicator,

- engine oil level indicator,

- total distance recorder (total and

trip distances).

Note

: the total and trip distances are

displayed for 30 seconds when the

ignition is switched off, on opening

the driver's door, as well as on lock-

ing and unlocking the vehicle.

It also displays the information relat-

ing to the cruise control or speed lim-

iter, when either of these is activated

(see corresponding section).

Service indicator

This indicates when the next service

is due in accordance with the manu-

facturer's servicing schedule.
The point at which the next service

is due is calculated from the last indi-

cator zero reset (see corresponding

section). It is determined by two pa-

rameters:

- the distance travelled,

- the time which has elapsed since

the last service.

Note: the distance remaining before

the next service may be weighted by

the time factor, depending on the us-

er's driving habits.

Operation
For 5 seconds after the ignition is

switched on, the spanner symbolis-

ing the servicing operations comes

on; the distance recorder display in-

dicates the number of miles [kilome-

tres] (rounded off) remaining until the
next service.
Example: 4,800 miles/km remain

before the next service. For i ve sec-

onds after the ignition is switched on,

the display indicates:

INSTRUMENT PANEL DISPLAY

   The distance remaining to the
next service is less than
500 miles (1,000 km).
  Example:  400 miles (900 km) remain
before the next service.
For  5  seconds  after  the  ignition  is

switched on, the display indicates:

5 seconds after the ignition was

switched on, the distance recorder

resumes its normal operation and

the spanner remains lit .
It indicates that a service must be

carried out soon. The display indi-

cates the total and trip distance.

5 seconds after the ignition was

switched on, the distance recorder

resumes its normal operation and

the display indicates the total and trip

distance.

INSTRUMENTS and CONTROLS

After switching on the ignition, three

functions are shown in succession:

- service indicator,

- engine oil level indicator,

- total distance recorder (total and

trip distances).

Note

: the total and trip distances are

displayed for 30 seconds when the

ignition is switched off, on opening

the driver's door, as well as on lock-

ing and unlocking the vehicle.

It also displays the information relat-

ing to the cruise control or speed lim-

iter, when either of these is activated

(see corresponding section).

Service indicator

This indicates when the next service

is due in accordance with the manu-

facturer's servicing schedule.
The point at which the next service

is due is calculated from the last indi-

cator zero reset (see corresponding

section). It is determined by two pa-

rameters:

- the distance travelled,

- the time which has elapsed since

the last service.

Note: the distance remaining before

the next service may be weighted by

the time factor, depending on the us-

er's driving habits.

Operation
For 5 seconds after the ignition is

switched on, the spanner symbolis-

ing the servicing operations comes

on; the distance recorder display in-

dicates the number of miles [kilome-

tres] (rounded off) remaining until the
next service.
Example: 4,800 miles/km remain

before the next service. For i ve sec-

onds after the ignition is switched on,

the display indicates:

INSTRUMENT PANEL DISPLAY

   The distance remaining to the
next service is less than
500 miles (1,000 km).
  Example:  400 miles (900 km) remain
before the next service.
For  5  seconds  after  the  ignition  is

switched on, the display indicates:

5 seconds after the ignition was

switched on, the distance recorder

resumes its normal operation and

the spanner remains lit .
It indicates that a service must be

carried out soon. The display indi-

cates the total and trip distance.

5 seconds after the ignition was

switched on, the distance recorder

resumes its normal operation and

the display indicates the total and trip

distance.

INSTRUMENTS and CONTROLS

Your PEUGEOT dealer carries out

this operation after each service.

However, if you carry out the service

yourself, the re-set procedure is as

follows:


Switch off the ignition,



Press and hold the trip recorder

re-set button,



Switch on the ignition.

The display begins a countdown.

When the display shows "=0" , re-

lease the button; the spanner disap-

pears.
Important:

after this operation, if you

wish to disconnect the battery, lock

the vehicle and wait for at least i ve

minutes, otherwise the zero re-set

will not be registered.

The service is overdue.
The spanner l ashes for 5 seconds

after the ignition is switched on.
Example: the service is overdue by
300 miles/km, your vehicle must be

serviced as soon as possible.
For 5 seconds after the ignition is

switched on, the display indicates:

Engine oil level indicator

When the ignition is switched on, the

engine oil level is indicated for a few

seconds, after the service information.

Oil level correct

Oil level gauge fault

5 seconds after the ignition was

switched on, the distance recorder

resumes its normal operation and the

spanner remains lit. The display indi-

cates the total and trip distance.
Note:

the spanner may also come on

if more than two years have elapsed

since the last service.

Flashing of "OIL --"

indicates a malfunc-

tion of the engine
oil level gauge.

Contact a PEUGEOT dealer.
  The level read will only be correct
if  the  vehicle  is  on  level  ground
and  the  engine  has  been  off  for
more than 15 minutes.

Flashing of "OIL" ,

linked with the

service

warning

light, accompanied

by an audible sig-

nal and a message

on the multifunction display, indicates

a lack of oil which could damage the

engine.
If the lack of oil is coni rmed by a

check using the dipstick, it is essen-

tial that the level is topped up.

Lack of oil

Service indicator zero re-set

INSTRUMENTS and CONTROLS

Your PEUGEOT dealer carries out

this operation after each service.

However, if you carry out the service

yourself, the re-set procedure is as

follows:


Switch off the ignition,



Press and hold the trip recorder

re-set button,



Switch on the ignition.

The display begins a countdown.

When the display shows "=0" , re-

lease the button; the spanner disap-

pears.
Important:

after this operation, if you

wish to disconnect the battery, lock

the vehicle and wait for at least i ve

minutes, otherwise the zero re-set

will not be registered.

The service is overdue.
The spanner l ashes for 5 seconds

after the ignition is switched on.
Example: the service is overdue by
300 miles/km, your vehicle must be

serviced as soon as possible.
For 5 seconds after the ignition is

switched on, the display indicates:

Engine oil level indicator

When the ignition is switched on, the

engine oil level is indicated for a few

seconds, after the service information.

Oil level correct

Oil level gauge fault

5 seconds after the ignition was

switched on, the distance recorder

resumes its normal operation and the

spanner remains lit. The display indi-

cates the total and trip distance.
Note:

the spanner may also come on

if more than two years have elapsed

since the last service.

Flashing of "OIL --"

indicates a malfunc-

tion of the engine
oil level gauge.

Contact a PEUGEOT dealer.
  The level read will only be correct
if  the  vehicle  is  on  level  ground
and  the  engine  has  been  off  for
more than 15 minutes.

Flashing of "OIL" ,

linked with the

service

warning

light, accompanied

by an audible sig-

nal and a message

on the multifunction display, indicates

a lack of oil which could damage the

engine.
If the lack of oil is coni rmed by a

check using the dipstick, it is essen-

tial that the level is topped up.

Lack of oil

Service indicator zero re-set

INSTRUMENTS and CONTROLS

Your PEUGEOT dealer carries out

this operation after each service.

However, if you carry out the service

yourself, the re-set procedure is as

follows:


Switch off the ignition,



Press and hold the trip recorder

re-set button,



Switch on the ignition.

The display begins a countdown.

When the display shows "=0" , re-

lease the button; the spanner disap-

pears.
Important:

after this operation, if you

wish to disconnect the battery, lock

the vehicle and wait for at least i ve

minutes, otherwise the zero re-set

will not be registered.

The service is overdue.
The spanner l ashes for 5 seconds

after the ignition is switched on.
Example: the service is overdue by
300 miles/km, your vehicle must be

serviced as soon as possible.
For 5 seconds after the ignition is

switched on, the display indicates:

Engine oil level indicator

When the ignition is switched on, the

engine oil level is indicated for a few

seconds, after the service information.

Oil level correct

Oil level gauge fault

5 seconds after the ignition was

switched on, the distance recorder

resumes its normal operation and the

spanner remains lit. The display indi-

cates the total and trip distance.
Note:

the spanner may also come on

if more than two years have elapsed

since the last service.

Flashing of "OIL --"

indicates a malfunc-

tion of the engine
oil level gauge.

Contact a PEUGEOT dealer.
  The level read will only be correct
if  the  vehicle  is  on  level  ground
and  the  engine  has  been  off  for
more than 15 minutes.

Flashing of "OIL" ,

linked with the

service

warning

light, accompanied

by an audible sig-

nal and a message

on the multifunction display, indicates

a lack of oil which could damage the

engine.
If the lack of oil is coni rmed by a

check using the dipstick, it is essen-

tial that the level is topped up.

Lack of oil

Service indicator zero re-set

INSTRUMENTS and CONTROLS

With the lights on, press the button

to vary the intensity of the lighting of
the instruments and controls. When
the lighting reaches the minimum (or
maximum) setting, release the button

then press it again to increase (or re-

duce) the brightness.
As soon as the lighting is of the re-

quired brightness, release the button.

With the ignition on, press the button

until the zeros appear.
Pressing the button enables you to

alternate between the distance re-

corder and cruise control or speed

limiter displays, when either of these

is activated.

Dipstick

There are 2 marks on the

dipstick:

- never exceed level A,

- in position B, top up the

level via the oil i ller cap,

using the type of oil suited

to your engine.

A = max.
B = min.

Lighting rheostat

Trip recorder zero reset
button

INSTRUMENTS and CONTROLS

With the lights on, press the button

to vary the intensity of the lighting of
the instruments and controls. When
the lighting reaches the minimum (or
maximum) setting, release the button

then press it again to increase (or re-

duce) the brightness.
As soon as the lighting is of the re-

quired brightness, release the button.

With the ignition on, press the button

until the zeros appear.
Pressing the button enables you to

alternate between the distance re-

corder and cruise control or speed

limiter displays, when either of these

is activated.

Dipstick

There are 2 marks on the

dipstick:

- never exceed level A,

- in position B, top up the

level via the oil i ller cap,

using the type of oil suited

to your engine.

A = max.
B = min.

Lighting rheostat

Trip recorder zero reset
button

INSTRUMENTS and CONTROLS

- the current information

tab with:

the range,
the current con-

sumption,

the distance re-

maining to be trav-

elled,

Colour display

Route zero reset

Monochrome display C



Press the button, located at the

end of the wipers stalk , to dis-

play the various trip computer

tabs in succession:

Data displays



When the route required is dis-

played, press the control for more

than two seconds.

The routes "1"

and "2" are inde-

pendent but their use is identical.
Route "1"

permits, for example, daily

calculations, and route "2" monthly

calculations.

- the route "1" tab with:

the distance trav-

elled,

the average con-

sumption,

the average speed,

for the i rst route.

- the route "2" tab with:

the distance trav-

elled,

the average con-

sumption,

the average speed,

for

the

second

route.

TRIP COMPUTER

System which provides current infor-

mation concerning the route travelled

(range, consumption, …).

INSTRUMENTS and CONTROLS

Distance remaining to be
travelled
(km or miles)

This is the distance remaining to be

travelled to the i nal destination. It

is either calculated instantly by the

navigation system if guidance is acti-

vated, or entered by the user.
If the distance is not entered, dashes

are displayed in place of the digits.

Average speed
(km/h or mph)

This is the average speed calculated

since the last trip computer zero re-

set (ignition on).

Range
(km or miles)

This indicates the number of miles

(or kilometres) which can still be

travelled with the fuel remaining in

the tank in relation to the average

consumption over the last few miles

(kilometres) travelled.

Current consumption
(l/100 km or km/l or mpg)

This is the average quantity of fuel

consumed over the last few sec-

onds.

Average consumption
(l/100 km or km/l or mpg)

This is the average quantity of fuel

consumed since the last trip compu-

ter zero reset.

Distance travelled
(km or miles)

This indicates the distance travelled

since the last trip computer zero re-

set.

A few definitions…

When the range falls below 20 miles

(30 km), dashes are displayed. After

i lling with at least 5 litres of fuel, the

range is recalculated and is displayed

when it exceeds 60 miles (100 km).

This function is only displayed

from 20 mph (30 km/h).

This i gure may increase follow-

ing a change of driving style or

relief, resulting in a signii cant

change in the current consump-

tion.

If dashes are displayed continu-

ously while driving in place of

the digits, contact a PEUGEOT
dealer.

INSTRUMENTS and CONTROLS

Display C

 Press the "MENU" button to gain

access to the general menu.



Press the arrows, then the "OK"

button to select the "Trip compu-
ter" menu.

 On the "Trip computer" menu,

select one of the following appli-

cations:

Warnings log
This summarises the active warning

messages, displaying them in suc-

cession on the multifunction display.

Status of the functions
This summarises the active or inac-

tive status of the functions present on

the vehicle.

Enter the distance to the
destination
This enables you to enter an approxi-

mate value for the distance to the i -

nal destination.

"TRIP COMPUTER" MENU

System which provides general in-

formation concerning the status of

certain equipment with which your

vehicle is equipped, such as the

warnings log, the status of the func-

tions...

"DIAGNOSTICS" MENU

 On the "Diagnostics"

menu, se-

lect one of the following applica-

tions:

Colour display

 Press the "MENU" button to gain

access to the general menu.



Turn the dial and press it to select

the "Diagnostics" menu.

MULTIFUNCTION DISPLAYS

MONOCHROME DISPLAY C
(WITHOUT RD4 AUDIO EQUIPMENT)

Presentation

Three buttons and a navigator en-

able you to control the display:

- "MENU" to display the general

menu,

- to change the permanent appli-

cation (trip computer, date, ...),

- "ESC" to abandon the operation

in progress,

- Rotation of the navigator: move-

ment on the display or changing

of a setting,

- Press on the navigator: coni r-

mation of the selection.

It displays the following information:

- the time,

- the date,

- the exterior temperature (the val-

ue displayed l ashes if there is a

risk of ice),

- the accesses check (doors,

boot, ...),

- the warning messages (e.g.:

"Depollution system faulty") or

information messages (e.g.: "Au-

tomatic headlamp lighting activat-

ed"), displayed temporarily, can

be cleared by pressing the "ESC"

button,

- the trip computer (see corre-

sponding section).

Press the "MENU" button to access

the general menu:

- trip computer (see corresponding

section),

- personalisation-coni guration,
Turn the navigator to select the menu

required, then coni rm by pressing

the navigator.

Once this menu has been selected,

you can access the following

functions:
- dei ne the vehicle parameters,

- display coni guration,

- selection of the language.

Parameter configuration

General menu

"Personalisation-
Configuration" menu

Content .. 1 2 3 ..
