Peugeot 306 Dag (2002 year). Instruction - part 6

108

DRIVING YOUR 306

AIRBAGS

The airbag system has been designed

to maximise the safety of the occu-

pants in the event of serious collisions.

It works in conjunction with the seat

belts.

The electronic detectors register and

analyse any abrupt deceleration of the

vehicle; if the triggering threshold is

reached the airbags inflate instantly

and come between the occupants and

the vehicle.

Immediately after the impact, the

airbags deflate rapidly, so that they do

not hinder the visibility of the occu-

pants and their exit if necessary from

the vehicle.

FRONT AIRBAGS*

DISARMING THE

The airbags are not deployed in the

PASSENGER AIRBAG*

case of collisions which are not

serious, for which the seat belt is suf-

To ensure the safety of your child,

These are folded in the centre of the

ficient to ensure maximum protection.

it is essential to disarm the pas-

steering wheel for the driver and in the

The seriousness of a collision

senger airbag when you install a

fascia for the front passenger. They

depends on the nature of the obstacle

rearwards-facing child seat on the

are deployed simultaneously (except

and the speed of the vehicle at the

front passenger seat.

in cases where the airbag is dis-

moment of the collision.

armed), for frontal impacts where

Remove the ignition key, insert it into

Airbags only operate when the igni-

there is a risk of injury to the head or

the passenger airbag switch 1 and

tion is switched on.

chest.

turn it to the “OFF” position.

Note: the gas escaping from the

airbags can be a minor irritant.

One of these two warning

lights* on the instrument panel

is lit throughout the disarming

procedure.

* According to specification.

109

DRIVING YOUR 306

In the “OFF” position, the passenger

Passenger airbag precautions

Operating check

airbag will not be triggered in the

It is indicated by one of the lights on

event of an impact.

instrument panel.

As soon as you remove the rear-

Vehicle fitted with a passenger airbag

If the passenger airbag is armed (pas-

wards-facing child seat from the front

disarming switch:

senger airbag switch in the “ON” posi-

passenger seat, turn the airbag switch

tion), the light will come on for

to the “ON” position, to arm the airbag

- disarm the airbag

6 seconds when the ignition is

and thus ensure the safety of your

if you install a rear-

switched on.

passenger in an impact.

wards-facing child

If the passenger airbag is disarmed

seat on the front

(passenger airbag switch in the “OFF”

passenger seat,

position), the light will stay on.

- arm the airbag

when you trans-

port an adult on

the front passen-

Only the airbag warning light

ger seat.

remains on,

or,

Vehicle not fitted with a passenger

airbag disarming switch:

the airbag warning light

comes on for six seconds

after the ignition is switched

on and the airbag disarming

- do not install a rear-

ilight remains on permanently.

wards-facing child seat

on the front passenger

seat.

In any case, if the light flashes,

contact a PEUGEOT dealer.

Never place your feet or any object on

the fascia.

* According to specification.

110

DRIVING YOUR 306

SIDE AIRBAGS*

These are incorporated into the front

seat back frame on the door side.

They are deployed independently of

Operating check

each other depending on which side

the collision occurs, in collisions which

This is indicated by one of the lights

could cause injury to the chest, the

on the instrument panel.

abdomen or the head.

It comes on for 6 seconds, each time

the ignition is switched on.

If one of the switches:

- does not light up when the ignition

is switched on, or,

- does not go out after 6 seconds or,

- flashes for 5 minutes then stays on,

contact a PEUGEOT dealer.

* According to specification.

** During model year and depending

on model.

111

DRIVING YOUR 306

WARNING

For the front and side airbags to be fully effective, observe the following safety rules:

• Wear a correctly adjusted seat belt.

• Sit in a normal upright position.

• Do not leave an accessory, or any other object between the occupants of the front seats and the airbags. It could

hamper the operation of the airbags or injure the occupants.

• All work on the airbag system is strictly forbidden unless it is carried out by qualified personnel of the PEUGEOT

network.

• After an accident or if the vehicle has been stolen or broken into, have the airbag systems checked.

• The airbag systems have been designed to be fully operational for 10 years after the vehicle has been registered.

Have them checked by a PEUGEOT dealer at this time.

• Front air bags*

• Do not drive holding the steering wheel by its spokes or resting your hands on the centre part of the wheel.

• Smoke as little as possible; deployment of the airbags can cause burns or the risk of injury from a cigarette or pipe.

• Never remove or pierce the steering wheel or hit it violently.

• Side air bags*

• Fit only approved covers to the front seats.

• Do not fix or glue anything to the front seat backs. This could cause injury to the chest or arms when the side airbag

inflates.

• Do not sit with the upper part of the body any nearer to the door than necessary.

* According to specification.

110

DRIVING YOUR 306

SIDE AIRBAGS*

These are incorporated into the front

seat back frame on the door side.

They are deployed independently of

Operating check

each other depending on which side

the collision occurs, in collisions which

This is indicated by one of the lights

could cause injury to the chest, the

on the instrument panel.

abdomen or the head.

It comes on for 6 seconds, each time

the ignition is switched on.

If one of the switches:

- does not light up when the ignition

is switched on, or,

- does not go out after 6 seconds or,

- flashes for 5 minutes then stays on,

contact a PEUGEOT dealer.

* According to specification.

** During model year and depending

on model.

111

DRIVING YOUR 306

WARNING

For the front and side airbags to be fully effective, observe the following safety rules:

• Wear a correctly adjusted seat belt.

• Sit in a normal upright position.

• Do not leave an accessory, or any other object between the occupants of the front seats and the airbags. It could

hamper the operation of the airbags or injure the occupants.

• All work on the airbag system is strictly forbidden unless it is carried out by qualified personnel of the PEUGEOT

network.

• After an accident or if the vehicle has been stolen or broken into, have the airbag systems checked.

• The airbag systems have been designed to be fully operational for 10 years after the vehicle has been registered.

Have them checked by a PEUGEOT dealer at this time.

• Front air bags*

• Do not drive holding the steering wheel by its spokes or resting your hands on the centre part of the wheel.

• Smoke as little as possible; deployment of the airbags can cause burns or the risk of injury from a cigarette or pipe.

• Never remove or pierce the steering wheel or hit it violently.

• Side air bags*

• Fit only approved covers to the front seats.

• Do not fix or glue anything to the front seat backs. This could cause injury to the chest or arms when the side airbag

inflates.

• Do not sit with the upper part of the body any nearer to the door than necessary.

* According to specification.

MAINTENANCE OF YOUR 306

1.4 litre and 1.6 litre petrol engine

1 Power steering fluid reservoir*.

4 Brake fluid reservoir.

7 Oil filter.

2 Engine oil filler cap.

5 Battery.

8 Coolant reservoir.

3Air filter.

6 Engine oil dipstick.

9 Screenwash reservoir.

* According to specification.

MAINTENANCE OF YOUR 306

1.8 litre and 2 litre 16V petrol engine

Power steering fluid reservoir*.

Brake fluid reservoir.

Oil filter.

Engine oil filler cap.

Battery.

Coolant reservoir.

Engine oil dipstick.

Air filter.

Screenwash reservoir.

* According to specification.

MAINTENANCE OF YOUR 306

1.9 litre diesel engine

Power steering fluid reservoir*.

Brake fluid reservoir.

Oil filter.

Engine oil dipstick.

Battery.

Coolant reservoir.

Engine oil filler cap.

Air filter.

Screenwash reservoir.

* According to specification.

MAINTENANCE OF YOUR 306

2 litre HDI turbo diesel engine

Power steering fluid reservoir*.

Brake fluid reservoir.

Oil filter.

Engine oil dipstick.

Battery.

Coolant reservoir.

Engine oil filler cap.

Air filter.

Screenwash reservoir.

* According to specification.

MAINTENANCE OF YOUR 306

CHECKING THE LEVELS

Oil change: according to the manu-

Brake fluid reservoir

facturer’s servicing schedule.

Checking the brake and clutch fluid

- Dipstick. Never fill past the

Engine

level :

maximum mark A.

- The level should always be above

- Oil level gauge on the instrument

Checking the oil level

the DANGER mark on the reservoir.

panel.

Check the level regularly and top

- If the level drops substantially,

up between changes

(maximum

contact a PEUGEOT dealer imme-

consumption is

0.5

litres

per

diately.

600 miles (1,000 km).

The oil level should be checked with

Viscosity selection

Fluid change

the vehicle level, engine cold.

In all cases, the oil selected must

- must be carried out according to the

There are two marks on the dipstick:

meet the manufacturer's require-

manufacturer’s schedule.

ments.

- use fluids approved by the manu-

A = maximum.

facturer, which fulfil DOT4 stan-

dards.

B = minimum.

Oil filter

Change the filter regularly in accor-

dance with the maintenance schedule.

Coolant reservoir

Use the fluid approved by the manu-

facturer.

When the engine is warm, the tempe-

rature of the coolant is controlled by

the engine fan: because this fan can

Used oil

operate with the ignition key removed,

Prevent used oil from coming into pro-

and because the cooling system is

longed contact with the skin.

pressurised, wait for at least one hour

after the engine has stopped before

Do not dispose of used oil into drains

carrying out any work.

or into the ground.

If necessary, in a breakdown, slacken

To maintain the reliability of engines

the cap to the first notch to release the

and emission control systems, the use

pressure to prevent any risk of scal-

of additives in the engine oil is prohi-

ding. When the pressure has dropped

bited.

remove the cap and top up the level.

Item C : Dipstick guide.

MAINTENANCE OF YOUR 306

Power steering reservoir

Manual gearbox

Open the reservoir, with the engine

This does not need an oil change.

cold, at outside temperature, the level

Check the level according to the

should always be above the MINI

manufacturer’s service schedule.

mark, close to the MAXI mark.

Autoadaptive automatic gearbox

Windscreen and headlamp wash

This does not need an oil change:

reservoir*

have the level checked by a

For best quality cleaning and for your

PEUGEOT dealer according to the

safety, we recommend that you use

manufacturer’s service schedule.

products approved by PEUGEOT

(capacity

4,4 litres or

6 litres with

headlight wash).

Only use products appro-

Battery

ved by Automobiles

PEUGEOT.

Fuel supply cut-off*

At the start of winter, have your battery

checked by a PEUGEOT dealer.

To ensure best perfor-

In a serious collision, a system pre-

mance from components as impor-

vents fuel from reaching the engine.

tant as the power steering and

To re-establish the fuel supply, press

the braking system, PEUGEOT

the switch on the angle of the front

selects

and

offers

quite

left-hand suspension assembly, under

Air filter

specific products.

the bonnet.

Regular replacement of the filter

element is essential. If you drive in

very dusty conditions, change it twice

as often.

Brake pads

Brake pad wear depends on the style

of driving, in particular for vehicles

which are used in town or for short

journeys or which are driven in a

sporty manner, it may be necessary

to check the thickness of the pads

even between services.

* According to specification.

MAINTENANCE OF YOUR 306

Power steering reservoir

Manual gearbox

Open the reservoir, with the engine

This does not need an oil change.

cold, at outside temperature, the level

Check the level according to the

should always be above the MINI

manufacturer’s service schedule.

mark, close to the MAXI mark.

Autoadaptive automatic gearbox

Windscreen and headlamp wash

This does not need an oil change:

reservoir*

have the level checked by a

For best quality cleaning and for your

PEUGEOT dealer according to the

safety, we recommend that you use

manufacturer’s service schedule.

products approved by PEUGEOT

(capacity

4,4 litres or

6 litres with

headlight wash).

Only use products appro-

Battery

ved by Automobiles

PEUGEOT.

Fuel supply cut-off*

At the start of winter, have your battery

checked by a PEUGEOT dealer.

To ensure best perfor-

In a serious collision, a system pre-

mance from components as impor-

vents fuel from reaching the engine.

tant as the power steering and

To re-establish the fuel supply, press

the braking system, PEUGEOT

the switch on the angle of the front

selects

and

offers

quite

left-hand suspension assembly, under

Air filter

specific products.

the bonnet.

Regular replacement of the filter

element is essential. If you drive in

very dusty conditions, change it twice

as often.

Brake pads

Brake pad wear depends on the style

of driving, in particular for vehicles

which are used in town or for short

journeys or which are driven in a

sporty manner, it may be necessary

to check the thickness of the pads

even between services.

* According to specification.

MAINTENANCE OF YOUR 306

CHANGING A WHEEL

Access to the spare wheel

The wheel is on the outside of the vehicle, under the boot, supported by a metal

Jack location

carrier.

Petrol and Diesel

Take out the wheelbrace 1.

3 or 5 door: the jack is in the boot 2.

Using the wheelbrace 1, unscrew the spare wheel carrier securing bolt located

Rear crossbar (right side). Press the

under the carpet in the boot.

tab and open the storage box to

remove it.

Raise the carrier to release the hook rearwards, then lower the carrier.

4 door: the jack is in the left-hand side

Release the spare wheel.

of the boot.

Estate: the jack is in the right-hand

storage compartment of the boot.

MAINTENANCE OF YOUR 306

4-door: Use the jack storage box to

chock the wheel diagonally opposite

For your safety, always

the wheel to be changed.

change the wheel:

Loosen the wheel bolts.

Place the jack in the location designed

- on level, stabIe and non-slippe-

for it, as close as possible to the wheel

ry ground,

to be changed.

- with the handbrake applied,

Ensure that the whole of the base of

- with first gear or reverse enga-

the jack is in contact with the ground.

ged (position P for the automa-

Extend the jack, fully loosen the wheel

tic gearbox).

bolts and remove the wheel.

Never go underneath a vehicle

which is supported only by a jack.

(Use a ramp).

To fit the wheel

After positioning the wheel, pre-

After changing the wheel:

tighten the bolts using the wheel-

have the tightening of the bolts

brace.

and the tyre pressure checked

Lower the jack and remove it.

by a PEUGEOT dealer as soon

as possible,

Fully tighten the wheel bolts using the

wheelbrace.

have the punctured wheel

repaired and refit it to the

Fit the wheel trim starting with the

vehicle as soon as possible.

section by the valve and press into

place using the palm of the hand.

Refitting the wheel in the

Removing the wheel

carrier

Park the vehicle on level, stable and

Raise the wheel, then the carrier, and

non-slippery ground.

resecure it on the hook.

Apply the handbrake, engage first

Do not forget to fully tighten the spare

gear or reverse (position P for the

wheel carrier securing bolt.

automatic gearbox).

Remove the wheel trim by using the

wheelbrace and pulling next to the

valve.

Warning: your wheel trims are fitted

with dummy nuts. Do not use them to

remove your wheel trims.

MAINTENANCE OF YOUR 306

Special features of the alloy

Fitting the spare wheel

Anti-theft bolts**

wheels*

If your vehicle is fitted with a steel

If your wheels are fitted with an anti-

spare wheel, it is normal to notice

theft bolt (one per wheel), the chro-

Bolt covers

that the bolt washers do not come

me trim and then the plastic cover

Alloy wheel bolts are covered by

into contact with the rim. The spare

must be removed using tool 3, befo-

chrome trims.

wheel is secured by the cone shape

re unscrewing the bolt using one of

Use tool 3 to remove the trims befo-

of each bolt. Tighten the bolts fully.

the two anti-theft sockets

(which

re slackening the bolts.

were given to you on delivery of your

vehicle with the duplicate keys and

Fitting snow tyres

the confidential card) and the wheel

brace 1.

If you fit snow tyres mounted on steel

wheels, it is essential to use special

bolts available from your PEUGEOT

Comment: make a careful note of

dealer.

the code number engraved on the

head of the anti-theft socket. This

will enable you to obtain a duplicate

of the anti-theft sockets from a

Peugeot dealer.

* According to specification.

** According to model and destina-

tion.

MAINTENANCE OF YOUR 306

ATTENTION

VOIR NOTICE

WARNING

READ

INSTRUCTIONS

H7 UV

Warning

There is a risk of damage to the

dipped/main beam Headlamps.

Only use bulbs supplied by the

following manufacturers:

- GE/TUNGSRAM

CHANGING A BULB

- PHILIPS

Side lights W5W

Dipped/main beam headlights

- OSRAM

Turn the plastic protector and

These bulbs meet the UV-free speci-

remove it.

Double Headlamps: two H7

55W

bulbs.

fications necessary for the correct

Turn the pin a quarter turn and

operation and reliability of the Head-

remove it.

Changing the bulbs

lamps.

Change the bulb.

Turn the plastic protector and

The Headlamps are fitted with poly-

remove it.

carbon glass with a protective coating.

Disconnect the connectors.

We strongly advise against cleaning

Press the spring to unclip the bulb and

them using a dry or abrasive cloth or

then change it.

using products which contain deter-

When fitting, ensure that the direction

gents or solvents.

notches are positioned correctly and

that the plastic protector is secured

correctly.

Only handle the bulb using a dry cloth.

Content .. 4 5 6 7 ..
