YO U R 306 IN D ETA IL
1
2
3
Never leave a child in a
vehicle which is exposed
to the sun and has the
windows closed.
To protect young children
from the sun, fit sunblinds to the
rear windows.
Never leave the keys in the reach
of children inside the car.
Strap children into their child seats
even on short journeys.
CHILD SEATS
This was one of PEUGEOT’s main criteria when designing your vehicle, however
the safety of your children also depends on you. For maximum peace of mind,
please follow these simple precautions:
All children under the age of 10 are required to travel in approved child safety seats*,
fitted with seat belts.
After carrying out numerous tests, PEUGEOT recommend the following systems :
Up to 9 months (up to 22 lbs. or 10 kg)
«Baby Safe», a seat secured with its back to the engine and secured with a
1
three-point seat belt, on either the front or rear seat.
From 9 months to 3 or 4 years (20 to 40 lbs. or 9 to 18 kg)
2
«Römer Peggy» is fitted to the rear seat with a two-point (lap-belt) or three-point
belt.
From 3 to10 years of age (33 to 80 lbs or 15 to 36 kg)
“Klippan Optima” : is fitted in the rear with a three point belt (removable seatback).
3
from 33 to 55 lbs. [15 to 25 kg] : booster + seatback.
from 55 to 80 lbs. [25 to 36 kg] : use the booster on its own.
Observe the precautions concern-
For maximum safety, fasten the three-point seat belts or the child seat straps keeping
ing the passenger airbag.
the slack in relation to the child’s body to a minimum, even for short journeys.
To prevent the doors from opening accidentally: use the child-proof lock.
Also, do not open the rear windows more than a third.
*According to current legislation
89
YO U R 306 IN D ETA IL
Pre-tensioning and force-
To be effective, a seat belt
limiting front seat belts*
1
must be tensioned as
Safety in the event of a frontal impact
close to the body as pos-
has been improved by the introduc-
sible.
tion of pre-tensioning and force-limit-
ing front seat belts. Depending on the
seriousness of the impact, the pre-
Depending on the nature and seri-
tensioning system instantly tightens
ousness of the impact the pre-ten-
the seat belts firmly against the body
sioning system may be triggered
of the occupant.
before and independently of the
airbags.
The pre-tensioning seat belts are
armed when the ignition is on.
In all cases, the airbag warning
light comes on.
The force-limiting device reduces the
pressure of the seat belt against the
occupant’s body in the event of an
Following an impact, have the
accident.
system checked by a PEUGEOT
dealer.
Rear seat belts
4-door: the rear seats are fitted with
The system has been designed to
3 three-point inertia reel seat belts.
be fully operational for ten years.
3/5-door, estate: The rear seats are
SAFETY: SEAT BELTS
fitted with
2 three-point inertia reel
seat belts and one lap belt.
Have it replaced at the end of this
To adjust the height of the
period.
Use the buckle retaining hooks when
front seat belts
the rear seats are not occupied.
Pull the knob 1 and slide it.
To lock the seat belts
Pull the strap, then insert the end into
the buckle.
* According to specification.
78
YO U R 306 IN D ETA IL
CHANGING THE REMOTE
CONTROL BATTERIES
A
To gain access to the battery, unclip
the key casing with a coin where you
can see the ring
(CR1620/3 volt
battery).
If the remote control does not work
after the battery has been changed,
re-programme the remote control.
PROGRAMMING THE
REMOTE CONTROL
B
Manual synchronisation
- Switch off the ignition,
- Switch on the ignition,
KEYS
THE REMOTE CONTROL
- Immediately after switching on the
A single press on button A locks the
ignition press button A.
Without central locking
doors and boot or tailgate, this is dis-
The remote control is now working
The key individually Iocks and unlocks
played by the direction indicators
again.
the doors and boot or tailgate.
staying on for about 2 seconds.
Automatic synchronisation
A single press on button B unlocks the
vehicle, this is displayed by the direc-
- Switch on the ignition (position M),
With central locking
tion indicators flashing rapidly.
- Switch off the ignition and, during
Turning the key in the driver’s door
the next four minutes, lock the
lock will lock or unlock the doors and
vehicle using the remote control
boot or tailgate. If either of the front
(button A).
doors is not closed, the central locking
will not work.
The remote control is now working
again.
Note: do not repeatedly press the
button of your remote control out of
range of your vehicle. You risk causing
it not to work and the remote control
would have to be reprogrammed.
79
YO U R 306 IN D ETA IL
DOORS
LOCKING FROM INSIDE THE
Take careful note of the
VEHICLE
numbers on the keys.
Opening the doors from
The key number is coded
outside
Without central locking
on the label attached to
To lock, press button A . The button
the key. If the key is lost
locks that door.
your PEUGEOT dealer can rapidly
supply you with new keys or a
With central locking
remote control.
To lock, press button A .
As a safety precaution (with chil-
Locking the driver’s door locks the
dren on board) remove the ignition
front and rear doors and the tailgate.
key when you leave the vehicle,
On the other doors the button only
even for a short time.
locks that door.
The high frequency remote control
is a high-performance system
which has a powerful beam. There-
fore do not operate it while it is in
Opening the doors from
your pocket as there is a possibil-
inside
ity that it may unlock your vehicle.
A
80
YO U R 306 IN D ETA IL
Locking or unlocking the boot
1
or tailgate
3 or 5 door without central locking
Turn the key in the tailgate lock.
Locking or unlocking the boot
4 door or estate
or tailgate
Using the key: turn the key in the boot
3 or 5 door with central locking
or tailgate lock.
The tailgate locks and unlocks at the
Child lock
Using the remote control*: the boot or
same time as the doors.
This prevents opening of the rear
tailgate locks and unlocks at the same
doors from inside the vehicle.
time as the doors.
Tailgate release
Turn control 1 a quarter turn using the
In the event of a central locking oper-
Locking the boot only (4 door)
ignition key.
ating fault, this enables the tailgate to
Turn the key to the right in the boot
It is still possible to open the doors
be unlocked:
lock.
from outside the vehicle.
- fold the rear seats to gain access
The boot will be locked whatever the
to the control from inside the vehicle.
action of the remote control or the
- Insert the ignition key in the opening
driver’s door lock.
and slide it to unlock the tailgate.
To open, turn the key to the left in the
boot lock. The boot will then be locked
at the same time as the central locking
of the doors.
The seat back locking control enables
you to prevent unauthorised entry to
the boot, even if the doors are open.
* According to specification.
81
YO U R 306 IN D ETA IL
1
1
Tilt and slide electric sun roof*
Bonnet
Outside the vehicle
Inside the vehicle: Pull the handle.
Raise the catch 1 and support the
Open the cover.
bonnet as it rises.
To open
Press the rear part of the switch 1.
To close
Press the front part of the switch 1.
To tilt
Press the front part of the switch 1.
To close, press the rear part of the
switch 1.
Tilting manual sun roof
Tilt the handle.
* According to specification.
82
YO U R 306 IN D ETA IL
Fuel filler flap
Filling with fuel
To open*: firmly pull the handle on the
Switch off the engine.
floor to the outside of the driver’s seat.
There is a holder for the fuel filler cap.
To close: from outside, push the flap
A label on the inside of the flap shows
back and check that it is secured
which fuels are permitted and which
correctly.
are not allowed.
The capacity of the tank is approx-
imately 13 gallons (60 litres).
Use the ignition key to open and close
the fuel filler cap independently of
opening the doors.
* According to specification.
90
YO U R 306 IN D ETA IL
Dipped beam/main beam change
Front and rear fog
Pull the stalk fully towards you.
lamps on.
A
B
These operate with the
Note: when the ignition is switched
side lights and the
off, if the driver’s door or front pas-
dipped/main beam headlamps. When
senger door* is left open, a buzzer
the side lights are switched off, there
sounds if you forget that you have left
is a return to the front fog lamps only
your lights on.
position.
Front and rear fog lights
To switch on, turn the ring. The posi-
Direction indicators
tion is confirmed by the light on the
(flashers)
instrument panel.
Left : downwards.
LIGHTING CONTROL
Right : upwards.
Front lights
Selection is by turning ring A.
Front and rear (ring B)
Horn
Press the end of the
lighting stalk.
Lights off.
Lights off.
Front fog lamps on.
Side lights on.
These operate with the side lights and
the dipped/main beam headlamps.
Dipped beam/main
beam.
* According to specification.
91
YO U R 306 IN D ETA IL
Automatic windscreen wiper*
3
In good weather or in rain,
In position 1, the wipers operate auto-
both day and night, if the
matically and adjust their speed to
rear fog lamp is lit it
2
the rainfall.
causes glare and is pro-
After switching off the ignition or
hibited.
after starting, this function must be
Do not forget to switch it off as
1
re-set, so the sensor can detect the
soon as it is no longer needed.
condition of the windscreen.
Do not cover the rain detector
To do this, change the stalk position :
located on the windscreen behind
-
from 1 to 0 then back to 1 (con-
the interior mirror.
firmed by a single wipe),
When using an automatic car
0
-
change from 1 to 2, then back to 1
wash, switch off the ignition or
(confirmed by two wipes).
check that the wiper control is not
in the automatic position.
A
In winter it is advisable to wait for
4
the windscreen to completely clear
of ice before operating the auto-
WINDSCREEN WIPERS
matic wipe.
Rear screen wiper
(estate)
Front windscreen wipers
Turn ring A to the first notch,
for intermittent wiping.
3 Fast wipe.
2 Normal wipe.
Rear screen wash
1 Intermittent or automatic wipe.
(estate)
Turn ring A beyond the first
0 Park.
notch.
4 Single wipe.
Windscreen and headlight
wash*
Pull the wipers stalk towards you.
The headlamp wash works if the
dipped or main beam headlamps are
on.
* According to specification.
99
YO U R 306 IN D ETA IL
1
2
3
4
Electric windows*
Temporary locking of the rear
windows (child safety) control
1. Driver’s electric window control
This allows the rear windows to be
You have two options*:
locked in any position.
Manual operation: Push or pull switch 1, lightly. The window stops when the
NOTE: as a safety measure (children
switch is released.
on board), remove the ignition key
Automatic operation: Push or pull switch 1 firmly. Pressing once opens or
when leaving the vehicle even for a
closes the window completely. Automatic opening and closing operate only
short time.
when the engine is switched on.
2. Passenger electric window control.
Push or pull switch 2. The window stops when the switch is released.
3. Left rear electric window control.
4. Right rear electric window control.
* According to specification.
100
YO U R 306 IN D ETA IL
2
A
Manual mirrors
Electric mirrors
Operate the adjusting lever in all four
Turn the control 2 to the right or to the
directions to adjust.
left to select the corresponding mirror.
Tilting windows (3-door)
Move the control 2 in all four direc-
To open the rear side windows, tilt the
tions to adjust.
lever A and push the window out-
wards.
When parked, the mirrors can be folded back manually.
The driver’s mirror is “non-spherical*” in order to reduce the “blind
spot”. As a result, objects observed in the mirror are closer than they
appear. This must be taken into account to correctly judge the distance
of vehicles approaching from the rear.
* According to country.
104
YO U R 306 IN D ETA IL
Athermic windscreen*
The windscreen has two non-reflec-
tive zones located either side of the
base of the interior rear-view mirror.
These are for affixing toll cards or
parking passes.
Note : the athermic glass reduces
the effect of the sun’s rays, by
limiting the heating of the passenger
compartment, but its reflective
coating blocks radio signals.
Rear screen blind (4 door)*
Storage compartments (estate)
Pull the blind by the central tab then
There are two storage compartments,
position the hooks in the locations.
fitted with elastic retaining straps,
Support it as it returns.
behind the boot side trims.
To gain access to a storage compart-
ment, pull the handle towards you.
* According to specification.
102
YO U R 306 IN D ETA IL
Hazard warning lights
Rear screen demisting
The switch and the direction
Rear screen (and mirrors)*
indicators flash.
electric demisting control.
This controls the indicator
Goes out automatically after
lights simultaneously and continu-
approximately 12 minutes to avoid
ously.
excessive power consumption.
Only use in case of danger, in an
Pressing the button again will operate
1
emergency stop or for driving in
the
demisting
for
another
unusual conditions.
12 minutes.
They can operate with the ignition off.
2
Digital clock*
Setting:
1 - Adjusting of hours.
2 - Adjusting of minutes.
Outside temperature display*
This indicates the outside tempera-
ture. When the temperature is
between minus 3 °C and + 5 °C, the
°C symbol flashes indicating a risk of
ice.
* According to specification.
103
YO U R 306 IN D ETA IL
2
1
3
Lighter
Front ashtray
Front and rear courtesy lights
Press and wait a few
To empty:
moments until it pops out
- open and pull the unit.
automatically.
Off.
To replace:
- push in fully.
Rear ashtray
Gradual illumination on
To empty, open and pull towards you.
opening or closing a door.
Lights permanently on with
the key in the accessories
position or with the ignition
on.
1 - Front courtesy light.
2 - Left map-reading light.
3 - Right map-reading light.
With the key in the accessories or igni-
tion on position, press the corre-
sponding switch.
105
DRIVING YOUR 306
AUTOMATIC AUTOADAPTIVE GEARBOX
Starting
To start the engine, put the selector lever in N or P.
A
Press the brake pedal when starting the engine and to exit position P.
B
1
Positions of the selector lever
These positions are displayed on the instrument panel.
P.
Park: use with the handbrake when parked.
R.
Reverse: this must only be engaged when the vehicle is stationary and the
engine idling.
N.
Neutral: if N is engaged by mistake while the car is moving, allow the engine
to return to idling speed before engaging a new forward gear.
D.
Drive: in this position, the four gear ratios change automatically. The gear
change points vary depending on the programme selected.
3.
Automatic changes of the first three gears only.
Select this position when you notice frequent changes between third and fourth
gear (town driving or on winding roads).
2
Automatic changes of the first two gears only.
This position is particularly suitable for mountain roads, when going uphill (to
make the best use of the engine's power) and downhill (engine braking).
1.
Selection of first gear only.
For use on steep gradients, especially when towing a trailer.
Selection of first gear is by pressing switch 1 with the lever in position 2.
To exit position 1, press switch 1 again or move the selector lever.
106
DRIVING YOUR 306
Operating programmes
Snow Programme
Any disruption of the
You have a choice of three operating
In position D the Snow programme
system is signalled by the
programmes:
provides smooth driving suited to slip-
simultaneous flashing of
- Auto-adaptive (normal).
pery roads in order to improve trac-
the Sport and Snow lights
tion and stability. Starting is in 2nd
on the instrument panel. In
- Sport.
gear and changing down is at low
such a case, the gearbox will
- Snow.
engine speeds.
operate in downgraded mode. You
One press on button A or B will select
may feel a substantial knock when
Sport or Snow respectively. The selec-
reverse is selected from P or N
tion is displayed on the instrument
(without any risk of damage to the
panel. Pressing the button a second
Special operating features
gearbox).
time will return to the auto-adaptive
- During prolonged braking, the
Do not exceed
60 m.p.h.
(normal) programme.
gearbox changes down automati-
(100km/h).
cally, so as to provide efficient
Contact a PEUGEOT dealer
engine braking.
without delay.
Auto-adaptive programme
- If you take your foot off the accel-
When the engine is idling with the
(normal)
erator suddenly
(when you are
car in gear, the car will move even
taken by surprise, for example), the
Gear changes are carried out on the
without you accelerating.
gearbox will not change up, so as to
basis of various parameters, such as:
improve safety.
Do not accelerate while a gear is
- driving style,
being selected, when the vehicle is
- When the engine is cold, the
- road characteristics,
stationary.
gearbox automatically selects a
- the vehicle’s load.
special programme which enables
When stationary, have your foot on
The gearbox continuously scans the
the engine to reach its ideal tem-
the brake pedal when selecting a
different programmes in the memory
perature more quickly to decrease
gear.
and selects the one most suitable for
pollution.
Do not accelerate in gear with the
the driving conditions at any given
brakes on.
moment.
If work needs to be done with the
engine running, apply the hand-
brake and select position P.
Sport programme
Kickdown
Do not change down to brake on
The Sport programme favours perfor-
slippery roads.
For immediate maximum acceleration
mance for sporty driving and more
without touching the gear lever, press
Never select position N when the
dynamic acceleration.
the accelerator pedal down as far as
vehicle is moving.
it will go. The gearbox will change
Never engage P or R if the vehicle
down automatically or stay in the gear
is not stationary.
selected, up to maximum engine
Do not allow children inside the
speed.
vehicle unsupervised when the
engine is running.
107
DRIVING YOUR 306
THE ABS ANTI-LOCK
BRAKING SYSTEM*
In conjunction with tyres of an
approved make and in good condition,
the ABS system with electronic brake
force distribution improves the stabil-
ity and handling of your vehicle, par-
ticularly on an uneven or slippery
surface.
The anti-lock braking system comes
into operation automatically when
there is a risk of wheel lock.
In the event of emergency braking,
press very firmly without reducing
the pressure. In some conditions
the normal operation of the ABS
Manual gearbox
Handbrake
may be felt as vibrations of the
The positions are indicated on the
Application
brake pedal.
gear lever knob.
When you have parked the vehicle,
pull up the handbrake to apply it.
Reverse gear can only be engaged
To ease application and release of the
from neutral when the vehicle is
handbrake, press the brake pedal and
stationary, with the engine idling.
pull up the handbrake with the engine
Power steering
running.
This is a comfort device which offers
the best compromise for parking, and
Release
Special features of the six speed
for driving at high speeds.
gearbox*
Press the button before releasing the
handbrake.
Raise the lock ring
under the knob
before engaging
reverse.
* According to specification.
