Instruments and controls

103

Information displays

Driver Information Centre

The Driver Information Centre is

located in the instrument cluster

below the speedometer.

Depending on vehicle configuration,

the following items appear in the

display:

● outside temperature 3 87
● clock 3 88
● odometer, trip odometer 3 91
● engine oil level monitor 3 93
● service display 3 93

● vehicle messages 3 104
● trip computer 3 105

Some of the displayed functions differ

when the vehicle is being driven or at

a standstill. Some functions are only

available when the vehicle is being

driven.

Info display

The central display in the

Infotainment system displays the time

(and/or outside temperature,

depending on version) and

Infotainment system information.
Press X to switch the Infotainment

system on. Alternatively, it

automatically switches on when the

ignition is switched on.
Depending on system, the

Infotainment system is operated via

buttons and rotary knobs on the

Infotainment system fascia, the

steering column controls, the voice

recognition system (if available) or via

the touchscreen display.

Touchscreen operation

Make the appropriate selection from

the available menus and options by

touching the display screen with the

finger.
For further information, refer to the

Infotainment system manual.

104

Instruments and controls

Vehicle messages

Messages appear in the Driver

Information Centre, in combination

with control indicator A or C.

Information messages

Information messages
BATTERY MODE: ECONOMY

ESP OFF

AUTO LIGHTS DEACTIVATED

OIL LEVEL CORRECT

Fault messages

Displayed in combination with control

indicator A. Drive with caution and

seek the assistance of a workshop.
To remove fault message, press

button on end of wiper lever. After a

few seconds the message may

disappear automatically and A

remains illuminated. The fault will

then be stored in the on board

system.

Fault messages
CHECK ESP

CHECK FUEL FILTER

CHECK GEARBOX

CHECK AUTO LIGHTS

Warning messages

These may appear with control

indicator C or in combination with

other warning messages, control

indicators or an audible warning. Stop

engine immediately and seek the

assistance of a workshop.
Warning messages
INJECTION FAULT

ENGINE OVERHEATING

GEARBOX OVERHEATING

Tyre pressure monitoring system

3

 202.

Warning chimes

When starting the engine or whilst

driving

Only one warning chime will sound at

a time.
The warning chime regarding

unfastened seat belts has priority

over any other warning chime.

● If seat belt is not fastened 3 54.
● If a certain speed is exceeded

with the parking brake applied

3

 156.

● If the parking assist detects an

object or a fault is present

3

 164.

● If the vehicle has manual

transmission automated and the

clutch temperature is too high

3

 151.

● If the vehicle speed briefly

exceeds a set limit 3 90.

● During closing of the power

sliding door 3 28.

● If the sliding door is open and the

parking brake is released 3 28.

Instruments and controls

105

● During activation and

deactivation of alarm monitoring

of vehicle inclination 3 34.

● If the AdBlue level falls below a

certain amount or a fault is

present 3 144.

● If the lane departure warning

system detects an unintended

lane change and when the

system is activated 3 168.

When the vehicle is parked and/or

the driver's door is opened

● When the key is in the ignition

switch.

● With exterior lights on 3 109.
● There is a fault with the power

door lock system 3 27.

● If the vehicle has manual

transmission automated 3 151;

the parking brake has not been

applied, neutral is not selected or

the brake pedal has not been

depressed. A corresponding

message may also appear in the

Driver Information Centre 3 103.

● If the sliding side door exterior

handle is in the open position

when unlocking the vehicle 3 28.

● If the parking brake is not applied

when the power sliding door

switch is pressed 3 28.

● If the power sliding door is locked

from the inside with the child lock

active 3 28.

● If the engine is in an Autostop but

not switched off. Stop-start

system 3 137.

Trip computer

The trip computer provides

information on driving data, which is

continually recorded and evaluated

electronically.

Depending on vehicle, the following

functions can be selected by pressing

button repeatedly on end of wiper

lever:

● fuel used
● average consumption
● instantaneous consumption
● range
● distance travelled

106

Instruments and controls

● average speed
● distance before service 3 93
● clock 3 88
● cruise control and speed limiter

stored speed 3 160

● fault and information messages
● odometer 3 91, trip odometer

3

 91

Fuel used

Displays the amount of fuel

consumed since the last reset.
The measurement can be restarted at

any time by pressing and holding the

button on the end of the wiper lever.

Average consumption

The value is displayed after driving a

distance of 400 metres.
Average consumption is displayed,

taking into consideration the distance

travelled and the fuel used since the

last reset.
The measurement can be restarted at

any time.

Instantaneous consumption

The value is displayed after reaching

a speed of 30 km/h.

Range

The value is displayed after driving a

distance of 400 metres.
The range is calculated from the

current contents of the fuel tank and

the average consumption since the

last reset.
The range will not display if control

indicator Y is illuminated in the

instrument cluster 3 101.
The measurement can be restarted at

any time.

Distance travelled

Displays the distance driven since the

last reset.
The measurement can be restarted at

any time.

Average speed

The value is displayed after driving a

distance of 400 metres.

The average speed since the last

reset is displayed.
The measurement can be restarted at

any time.
Interruptions in the journey with the

ignition off are not included in the

calculations.

Reset trip computer information

To reset the trip computer, select one

of its functions then press and hold

button on end of wiper lever.
The following trip computer

information can be reset:

● fuel used
● average consumption
● distance travelled
● average speed

The trip computer will reset

automatically when the maximum

value of any of the parameters is

exceeded.

Instruments and controls

107

Fuel economy rating (ecoScoring)

If equipped, a rating of 0 to 100 is

shown in the Infotainment system

display screen, to help evaluate fuel

efficiency, based on your driving

style.
Higher ratings indicate better fuel

economy.
Tips to improve fuel economy are also

given in the display. Journeys can be

saved in the system memory,

enabling you to compare

performances. Refer to Infotainment

manual for further information.
Vehicle messages 3 104.

Journey record

When the engine is switched off, a

record of the last journey may be

shown in the Infotainment system

display screen.
The following information is

displayed:

● average fuel consumption
● trip odometer
● fuel saved in km

Refer to Infotainment manual for

further information.

Interruption of power supply

If the power supply has been

interrupted or if the vehicle battery

voltage has dropped too low, the

values stored in the trip computer will

be lost.

Tachograph

The tachograph is operated as

described in the operating

instructions supplied. Observe

regulations regarding use.
Control indicator & illuminates in the

instrument cluster in the event of a

fault. Seek the assistance of a

workshop.

108

Instruments and controls

Note

When a tachograph is fitted, the total

distance travelled may be shown

only on the tachograph and not in the

odometer within the instrument

display.
Odometer 3 91.

Lighting

109

Lighting

Exterior lighting .......................... 109

Light switch .............................. 109

Automatic light control ............. 109

High beam ............................... 110

High beam assist ..................... 110

Headlight flash ......................... 111

Headlight range adjustment .... 111

Headlights when driving

abroad .................................... 111

Daytime running lights ............. 111

Adaptive forward lighting ......... 112

Hazard warning flashers .......... 112

Turn and lane-change signals . 112

Front fog lights ......................... 113

Rear fog lights ......................... 113

Reversing lights ....................... 113

Misted light covers ................... 113

Interior lighting ........................... 114

Interior lights ............................ 114

Load compartment lighting ...... 114

Reading lights .......................... 115

Lighting features ........................ 116

Exit lighting .............................. 116

Battery discharge protection .... 116

Exterior lighting

Light switch

Turn outer light switch:
7

: off

0

: sidelights

9

 P : headlights

AUTO : automatic light control:

headlights are switched on

and off automatically.

Turn inner light switch:
>

: front fog lights

ø

: rear fog lights

High beam control indicator P

3

 102.

Low beam control indicator 9 3 102.

Note

If the headlights have been switched

on manually, a warning chime will

sound when the engine is switched

off and when the driver's door is

opened as a reminder that the lights

are still on.

Tail lights

Tail lights are illuminated together

with low beam and sidelights.

Automatic light control

110

Lighting

When the automatic light control

function is switched on and the

engine is running, the system

switches between daytime running

lights (where fitted) and headlights,

depending on the lighting conditions.
For reasons of safety, the light switch

should always remain in the AUTO

position.
Daytime running lights 3 111.

Automatic headlight activation

During poor lighting conditions the

headlights are switched on.
Additionally, headlights are switched

on if the windscreen wipers have

been activated for several wipes.

High beam

To change between low and high

beam, pull lever until a click is felt.

High beam assist

This feature allows high beam to

function as the main driving light at

night and when vehicle speed is

faster than 45 km/h.
It switches to low beam when:

● The camera in the windscreen

detects the lights of oncoming or

preceding vehicles.

● It is foggy or snowy.
● Driving in urban areas.

If there are no restrictions detected,

the system switches back to high

beam.

Activation

Turn the outer light switch to AUTO

then pull the turn signal lever to

activate high beam assist.
The control indicator í illuminates

continuously in the instrument cluster

when the assist is activated, while the

blue control indicator 7 3 102

illuminates when high beam is on.
Control indicator í 3 102.

Lighting

111

Note

Use of the system does not relieve

the driver from full responsibility for

vehicle operation.

Deactivation

Pull the turn signal lever again.

Control indicator í extinguishes.
High beam assist is also deactivated

when the outer light switch is moved

out of the AUTO position.

Note

Depending on version, the system

can be also be deactivated via the

Infotainment system. Refer to

Infotainment manual for further

information.

General information

Performance of the system can be

affected due to the following:

● Extreme weather conditions, e.g.

heavy rain, fog or snow.

● The front camera or the

windscreen is obstructed, e.g. by

a portable navigation system.

● Oncoming or preceding vehicle

lights are not detected.

● Headlights are not adjusted

correctly.

● Various reflective surfaces may

also cause the system to fail to

detect other vehicles.

Headlight flash

To activate the headlight flash, pull

lever.

Headlight range adjustment

Manual headlight range

adjustment

With low beam switched on, adapt the

headlight range to suit the vehicle

load to prevent dazzling of oncoming

traffic.
Turn knurled wheel to required

position:
0 : front seat occupied

4 : loaded up to permissible

maximum weight

Headlights when driving

abroad

The asymmetrical headlight beam

extends visibility at the edge of the

road at the passenger side.
However, when driving in countries

where traffic drives on the opposite

side of the road, adjust the headlights

to prevent dazzling of oncoming

traffic.
Have the headlights adjusted by a

workshop.

Daytime running lights

Daytime running lights increase

visibility of the vehicle during daylight.

112

Lighting

The lights operate automatically

when the ignition is switched on.
If the vehicle is equipped with the

automatic light control function, the

system switches between daytime

running lights and headlights

automatically depending on the

lighting conditions. Automatic light

control 3 109.

Adaptive forward lighting

Cornering light

Depending on the steering angle,

vehicle speed and gear selected

when cornering, an additional light

will illuminate the corner of the road

on the respective side when the

headlights are switched on.
The cornering light is switched off

automatically after prolonged use and

at vehicle speeds above 40 km/h.

Hazard warning flashers

Operated by pressing ¨.
In the event of hard braking, the

hazard warning flashers may turn on

automatically. Switch off by pressing

¨

.

Turn and lane-change

signals

lever up

: right turn signal

lever down : left turn signal
A resistance point can be felt when

moving the lever.
Constant flashing is activated when

the lever is moved beyond the

resistance point. It is deactivated

when the steering wheel is moved in

the opposite direction or lever is

manually moved back to its neutral

position.

Lighting

113

Activate temporary flashing by

holding the lever just before the

resistance point. Turn signal lights will

flash until lever is released.
To activate three flashes, tap the

lever briefly without passing the

resistance point.

Front fog lights

Turn inner switch to position > and

release.
Front fog lights operate with engine

running and headlights switched on.

Rear fog lights

Turn inner switch to position ø and

release.
Rear fog lights operate with engine

running and headlights switched on.

Reversing lights

The reversing lights come on when

the ignition is on and reverse gear is

selected.

Misted light covers

The inside of the light covers may mist

up briefly in poor, wet and cold

weather conditions, in heavy rain or

after washing. The mist disappears

quickly by itself; to help, switch on the

headlights.

114

Lighting

Interior lighting

Interior lights

Courtesy lights illuminate when the

vehicle is unlocked with the remote

control or the front doors are opened.
When the doors are closed, the

courtesy light extinguishes after a

delay or immediately after the ignition

is switched on.

Front courtesy light

With the switch in its central position,

the light functions as a courtesy light.

Operated by pressing the switch c:

● on constantly
● on when the doors are unlocked

and opened

● off constantly

Rear courtesy lights

Combi, Bus

Low level and overhead courtesy

lights are located in the rear

passenger compartment.

Operate rocker switch on the

instrument panel:
press OFF : off

press c : on

Reading lights l 3 115.

Load compartment lighting

Load compartment lighting can be set

to illuminate when the side and rear

doors are opened, or switched on

constantly.
With the switch in its central position,

the light functions as a courtesy light.

Operated by pressing the switch c:

● on constantly
● on when the doors are unlocked

and opened

● off constantly

Lighting

115

When the doors are closed, the

courtesy light extinguishes after a

delay or immediately after the ignition

is switched on.

Reading lights

Front reading light

Operated with l.
The reading light can be directed as

required, depending on version.

Rear reading lights

Combi, Bus

Operate rocker switch on the

instrument panel:
press l

: on

press OFF : off
Courtesy lights c 3 114.

Each reading light can then be

switched on or off individually and

directed as required.

116

Lighting

Lighting features

Exit lighting

Headlights come on for approx.

30 seconds after the vehicle is parked

and the system is activated.

Activating

1. Switch off ignition.
2. Remove ignition key.
3. Pull turn signal lever towards

steering wheel.

This action can be repeated up to

four times.

The headlights are turned off

immediately by turning the light switch

to any position and returning to 7.

Battery discharge protection

To prevent discharge of the vehicle

battery when the ignition is switched

off, some interior lights may be

switched off automatically after some

time.

Climate control

117

Climate control

Climate control systems ............. 117

Heating and ventilation system 117

Air conditioning system ........... 118

Electronic climate control

system .................................... 119

Rear heating system ............... 121

Rear air conditioning system ... 123

Auxiliary heater ........................ 124

Air vents ..................................... 130

Adjustable air vents ................. 130

Fixed air vents ......................... 131

Glovebox cooler ...................... 131

Maintenance .............................. 131

Air intake ................................. 131

Pollen filter ............................... 131

Air conditioning regular

operation ................................ 131

Service .................................... 131

Climate control systems

Heating and ventilation

system

Controls for:

● temperature
● fan speed
● air distribution
● demisting and defrosting

Heated rear window Ü 3 41, Heated

seats ß 3 50.

Temperature

red : warm

blue : cold
Heating will not be fully effective until

the engine has reached normal

operating temperature.

Fan speed

Adjust the air flow by switching the fan

to the desired speed.

Air distribution

M

: to head area

L

: to head area and foot well

K

: to foot well

J

: to windscreen, front door

windows and foot well

V

: to windscreen and front door

windows

Intermediate settings are possible.

Demisting and defrosting the

windows

● Set temperature control to

warmest level.

● Set fan speed to highest level.

118

Climate control

● Set air distribution control to V.
● Switch on heated rear window Ü.
● Open side air vents as required

and direct them towards door

windows.

● For simultaneous warming of the

foot well, set air distribution

control to J.

Air conditioning system

Additional to the heating and

ventilation system, the air

conditioning system has controls for:
A/C : cooling

u

: air recirculation

Heated rear window Ü 3 41, Heated

seats ß 3 50.

Cooling (A/C)

Press A/C to switch on cooling. The

LED in the button illuminates to

indicate activation. Cooling is only

functional when the engine is running

and climate control fan is switched on.
Press A/C again to switch off cooling.
The air conditioning system cools and

dehumidifies (dries) the air when

outside temperature is a little above

the freezing point. Therefore

condensation may form and drip from

under the vehicle.
If no cooling or drying is required,

switch the cooling system off to save

fuel.

Note

If the climate control is set to

maximum cooling while the ambient

temperature is high, an Autostop

may be inhibited until the required

temperature in the passenger

compartment has been reached.

If the climate control is set to

maximum cooling while the engine is

in an Autostop, the engine may

restart automatically.

Stop-start system 3 137.

Air recirculation system

Press u to activate air recirculation

mode. The LED in the button

illuminates to indicate activation.
Press u again to deactivate air

recirculation mode.

9 Warning

The exchange of fresh air is

reduced in air recirculation mode.

In operation without cooling the air

humidity increases, so the

windows may mist up. The quality

of the passenger compartment air

deteriorates, which may cause the

vehicle occupants to feel drowsy.

Maximum cooling

Briefly open the windows so that hot

air can disperse quickly.
