6E2–314 6VD1 3.2L ENGINE DRIVEABILITY AND EMISSIONS 3. Wrap the splice with mylar and with the drain (uninsulated) wire. 049 4. Tape over the whole bundle to secure. 050 Twisted Leads Removal Procedure 1. Locate the damaged wire. 2. Remove the insulation as required. 051 Installation Procedure 1. Use splice clips and rosin core solder in order to splice the two wires together. 052 |
