6E2–306 6VD1 3.2L ENGINE DRIVEABILITY AND EMISSIONS D Intake air temperature (IAT) sensor. Refer to Intake Air Temperature Sensor. 035RW023 5. Disconnect the vacuum hose below the air horn. 10. Remove the throttle body from the common chamber. 11. Remove the gasket from the upper intake manifold. 035RW024 12. Remove the IAC. Refer to Idle Air Control (IAC) Solenoid. 13. Remove the TP sensor. Refer to Throttle Position (TP) Sensor. Inspection Procedure NOTE: Do not use solvent of any type when you clean the D If the throttle body gasket needs to be replaced, D Do not leave any scratches in the aluminum casting. Installation Procedure 1. Install the TP sensor. Refer to Throttle Position (TP) Sensor. 2. Install the IAC. Refer to Idle Air Control (IAC) Solenoid. 3. Install the gasket on the common chamber. bolts. D The vacuum lines must be properly routed under Tighten D Tighten the throttle body mounting bolts to 24 035RW024 6. Install the coolant lines. 10. Connect all the electrical connectors: D Throttle position (TP) sensor. D Idle air control (IAC) solenoid. |
