5C–26 POWER-ASSISTED BRAKE SYSTEM 5. If dimension (4) is out of the standard range, adjust push rod using the Push Rod Support 5–8840– 331RW014 6. Mount plate and seal assembly in vacuum booster front shell. Then install the retainer. 7. Install vacuum booster fixing nut and tighten the specified torque. Torque: 15 N·m (1.5 kg·m/11 lbft) 8. Install yoke clevis. 9. Connect vacuum hose and make sure that the arrow on the hose points in the direction of the engine. 10. Install master cylinder, refer to “ Master Cylinder Installation " in this section. |
