Nissan Versa Sedan (2015 year). Instruction - part 6

After the ignition switch is placed in the ON
position, this light illuminates for about 1 second
and turns off.

Low tire pressure warning:

If the vehicle is being driven with low tire
pressure, the warning light will illuminate.

A CHECK TIRE PRES (pressure) warning
message is also displayed in the odometer.

When the low tire pressure warning light
illuminates, you should stop and adjust the
tire pressure of all 4 tires to the recom-
mended COLD tire pressure shown on the
Tire and Loading Information label located
in the driver’s door opening. The low tire
pressure warning light does not automati-
cally turn off when the tire pressure is ad-
justed. After the tire is inflated to the rec-
ommended pressure, the vehicle must be
driven at speeds above 16 MPH (25 km/h)
to activate the TPMS and turn off the low
tire pressure warning light. Use a tire pres-
sure gauge to check the tire pressure.

The low tire pressure warning light remains illu-
minated until the tires are inflated to the recom-
mended COLD tire pressure. The CHECK TIRE
PRES warning message is displayed each time
the ignition switch is placed in the ON position as
long as the low tire pressure warning light re-
mains illuminated.

For additional information, see

⬙Check tire pres-

sure warning message

⬙ in this section and “Tire

Pressure Monitoring System (TPMS)” in the
“Starting and driving” section and in the “In case
of emergency” section.

TPMS malfunction:

If the TPMS is not functioning properly, the low
tire pressure warning light will flash for approxi-
mately 1 minute when the ignition switch is
placed in the ON position. The light will remain on
after the 1 minute. Have the system checked by a
NISSAN dealer.

For additional information, see “Tire Pressure
Monitoring System (TPMS)” in the “Starting and
driving” section and “Tire pressure” in the “Main-
tenance and do-it-yourself” section.

WARNING

● If the light does not illuminate with the

ignition switch placed in the ON posi-
tion, have the vehicle checked by a
NISSAN dealer as soon as possible.

● If the light illuminates while driving,

avoid sudden steering maneuvers or
abrupt braking, reduce vehicle speed,
pull off the road to a safe location and
stop the vehicle as soon as possible.
Driving with under-inflated tires may
permanently damage the tires and in-
crease the likelihood of tire failure. Se-
rious vehicle damage could occur and
may lead to an accident and could result
in serious personal injury. Check the
tire pressure for all four tires. Adjust the
tire

pressure

the

recommended

COLD tire pressure shown on the Tire
and Loading Information label located
in the driver’s door opening to turn the
low tire pressure warning light OFF. If
the light still comes on while driving
after adjusting the tire pressure, a tire
may be flat. If you have a flat tire, re-
place it with a spare tire as soon as
possible.

Instruments and controls

2-15

● When a spare tire is mounted or a wheel

is replaced the TPMS will not function
and the low tire pressure warning light
will flash for approximately 1 minute.
The light will remain on after 1 minute.
Contact your NISSAN dealer as soon as
possible for tire replacement and/or
system resetting.

● Replacing tires with those not originally

specified by NISSAN could affect the
proper operation of the TPMS.

CAUTION

● The TPMS is not a substitute for the

regular tire pressure check. Be sure to
check the tire pressure regularly.

● If the vehicle is being driven at speeds

of less than 16 MPH (25 km/h), the
TPMS may not operate correctly.

● Be sure to install the specified size of

tires to the 4 wheels correctly.

Low windshield-washer fluid
warning light (if so equipped)

This light comes on when the windshield-washer
fluid is at a low level. Add windshield-washer fluid
as necessary. See “Windshield-washer fluid” in
the “Maintenance and do-it-yourself” section of
this manual.

NISSAN Intelligent Key®
warning light (if so equipped)

After the ignition switch is placed in the “ON”
position, this light comes on for about 2 seconds
and then turns off. This light illuminates or blinks
as follows:

● The light blinks in yellow when the door is

closed with the Intelligent Key left outside
the vehicle and the ignition switch in the
“ACC” or “ON” position. Make sure that the
Intelligent Key is inside the vehicle.

● The light blinks in green when the Intelligent

Key battery is running out of power. Replace
the battery with a new one. See “Battery” in
the “Maintenance and do-it-yourself” sec-
tion.

● The light illuminates in yellow when it warns

of a malfunction with the electrical steering
lock system or the Intelligent Key system.

If the warning light illuminates in yellow while the
engine is stopped, it may be impossible to free
the steering lock or to start the engine. If the light
comes on while the engine is running, you can
drive the vehicle. However in these cases, con-
tact a NISSAN dealer for repair as soon as pos-
sible.

See “NISSAN Intelligent Key®” in the “Pre-
driving checks and adjustments” section.

Power steering warning light

WARNING

● If the engine is not running or is turned

off while driving, the power assist for
the steering will not work. Steering will
be harder to operate.

● When the power steering warning light

illuminates with the engine running,
there will be no power assist for the
steering. You will still have control of
the vehicle but the steering will be
harder to operate. Have the power
steering system checked by a NISSAN
dealer.

When the ignition switch is placed in the ON
position, the power steering warning light illumi-
nates. After starting the engine, the power steer-
ing warning light turns off. This indicates the
power steering system is operational.

If the power steering warning light illuminates
while the engine is running, it may indicate the
power steering system is not functioning properly
and may need servicing. Have the power steering
system checked by a NISSAN dealer.

2-16

Instruments and controls

When the power steering warning light illumi-
nates with the engine running, there will be no
power assist for the steering but you will still have
control of the vehicle. At this time, greater steer-
ing effort is required to operate the steering
wheel, especially in sharp turns and at low
speeds.

See “Power steering” in the “Starting and driving”
section.

Seat belt warning light and
chime

The light and chime remind you to fasten your
seat belts. The light illuminates whenever the
ignition switch is placed in the ON or START
position and remains illuminated until the driver’s
seat belt is fastened. At the same time, the chime
sounds for about 6 seconds unless the driver’s
seat belt is securely fastened.

The seat belt warning light may also illuminate if
the front passenger’s seat belt is not fastened
when the front passenger’s seat is occupied . For
7 seconds after the ignition switch is placed in
the ON position, the system does not activate the
warning light for the front passenger.

Refer to “Seat belts” in the “Safety—Seats, seat
belts and supplemental restraint system” section
for precautions on seat belt usage.

Shift P warning light (if so
equipped)

This light blinks red and the key reminder chime
sounds if the shift lever is in any position other
than P (Park) and the ignition switch is in the OFF
position. Return the shift lever to P (Park) with the
ignition switch in the OFF position and the light
will turn off. Place the ignition switch in the LOCK
position and the chime will turn off.

Supplemental air bag warning
light

When the ignition switch is placed in the ON or
START position, the supplemental air bag warn-
ing light illuminates for about 7 seconds and then
turns off. This means the system is operational.

If any of the following conditions occur, the front
air bag, side air bag, curtain air bag, and preten-
sioner seat belt systems need servicing and your
vehicle must be taken to a NISSAN dealer:

● The supplemental air bag warning light re-

mains on after approximately 7 seconds.

● The supplemental air bag warning light

flashes intermittently.

● The supplemental air bag warning light does

not come on at all.

Unless checked and repaired, the supplemental
restraint system (air bag system) and/or the pre-
tensioners may not function properly. For addi-
tional details see “Supplemental restraint sys-
tem” in the “Safety—Seats, seat belts and
supplemental restraint system” section of this
manual.

WARNING

If the supplemental air bag warning light
is on, it could mean that the front air bag,
side air bag, curtain air bag systems
and/or pretensioner systems will not op-
erate in an accident. To help avoid injury to
yourself or others, have your vehicle
checked by a NISSAN dealer as soon as
possible.

INDICATOR LIGHTS

Automatic Transmission
(A/T)/Continuously Variable
Transmission (CVT) position
indicator light (if so equipped)

When the ignition switch is placed in the ON
position, this indicator light shows the shift lever
position. See “Driving the vehicle” in the “Starting
and driving” section of this manual.

Instruments and controls

2-17

Cruise main switch indicator
light (if so equipped)

The light comes on when the cruise control main
switch is pushed. The light goes out when the
main switch is pushed again. When the cruise
main switch indicator light comes on, the cruise
control system is operational.

Engine start operation
indicator (if so equipped)

For vehicles equipped with push button ignition
this indicator illuminates when the ignition switch
is in the LOCK, OFF, ACC or ON position with
the shift lever in the P (Park) position.

This indicator means that the engine will start by
pushing the push-button ignition switch with the
brake pedal depressed.

Front passenger air bag status
light

The front passenger air bag status light (

)

will be lit and the passenger front air bag will be
OFF depending on how the front passenger seat
is being used.

For front passenger air bag status light operation,
see “Front passenger air bag and status light” in

the “Safety — Seats, seat belts and supplemental
restraint system” section of this manual.

High beam indicator light
(blue)

This blue light comes on when the headlight high
beams are on and goes out when the low beams
are selected.

The high beam indicator light also comes on
when the passing signal is activated.

Malfunction Indicator Light
(MIL)

If this indicator light comes on steady or blinks
while the engine is running, it may indicate a
potential emission control malfunction.

The

may also come on steady if the fuel-

filler cap is loose or missing, or if the vehicle runs
out of fuel. Check to make sure the fuel-filler cap
is installed and closed tightly, and that the vehicle
has at least 3 gal (11.4 L) of fuel in the fuel tank.

After a few driving trips, the

light should

turn off if no other potential emission control
system malfunction exists.

If this indicator light comes on steady for 20 sec-
onds and then blinks for 10 seconds when the
engine is not running, it indicates that the vehicle

is not ready for an emission control system
inspection/maintenance test. See “Readiness for
inspection/maintenance (I/M) test” in the “Tech-
nical and consumer information” section of this
manual.

Operation

The Malfunction Indicator Light will come on in
one of two ways:

● Malfunction Indicator Light on steady — An

emission control system malfunction has
been detected. Check the fuel-filler cap. If
the LOOSE FUEL CAP warning message is
displayed in the odometer, and the fuel-filler
cap is loose or missing, tighten or install the
cap and continue to drive the vehicle.
The

light should turn off after a few

driving trips. If the

light does not turn

off after a few driving trips, have the vehicle
inspected by a NISSAN dealer. You do not
need to have your vehicle towed to the
dealer.

● Malfunction Indicator Light blinking — An

engine misfire has been detected which may
damage the emission control system. To re-
duce or avoid emission control system dam-
age:

– do not drive at speeds above 45 MPH

(72 km/h).

2-18

Instruments and controls

– avoid hard acceleration or deceleration.

– avoid steep uphill grades.

– if possible, reduce the amount of cargo

being hauled.

The Malfunction Indicator Light may stop blinking
and come on steady. Have the vehicle inspected
by a NISSAN dealer. You do not need to have
your vehicle towed to the dealer.

CAUTION

Continued vehicle operation without hav-
ing the emission control system checked
and repaired as necessary could lead to
poor driveability, reduced fuel economy,
and possible damage to the emission con-
trol system.

Overdrive OFF indicator light
(A/T / CVT models) (if so
equipped)

The overdrive off indicator light illuminates when
the overdrive off mode is selected.

For additional information, see “Driving the ve-
hicle” in the “Starting and driving” section of this
manual.

Security indicator light
(if so equipped)

This light blinks when the ignition switch is in the
OFF, LOCK or ACC position. The blinking secu-
rity indicator light indicates that the security sys-
tems equipped on the vehicle are operational.

For additional information, see “Security sys-
tems” in this section.

Side light and headlight
indicator light (green)
(if so equipped)

The side light and headlight indicator light illumi-
nates when the side light or headlight position is
selected. See “Headlight and turn signal switch”
in this section for further details.

Slip indicator light

This indicator will blink when the Vehicle Dynamic
Control (VDC) system or the traction control
system is operating, thus alerting that the vehicle
is nearing its traction limits. The road surface may
be slippery.

Turn signal/hazard indicator
lights

The appropriate light flashes when the turn signal
switch is activated.

Both lights flash when the hazard switch is turned
on.

Vehicle Dynamic Control
(VDC) off indicator light

This indicator light comes on when the Vehicle
Dynamic Control off switch is pushed to OFF.
This indicates the Vehicle Dynamic Control sys-
tem is not operating.

Push the Vehicle Dynamic Control off switch
again or restart the engine and the system will
operate normally. See “Vehicle Dynamic Control
(VDC) system” in the “Starting and driving” sec-
tion of this manual.

The Vehicle Dynamic Control light also comes on
when you place the ignition switch in the ON
position. The light will turn off after about 2 sec-
onds if the system is operational. If the light stays
on or comes on along with the

indicator

light while you are driving, have the Vehicle Dy-
namic Control system checked by a NISSAN
dealer.

Instruments and controls

2-19

While the Vehicle Dynamic Control system is
operating, you might feel slight vibration or hear
the system working when starting the vehicle or
accelerating, but this is normal.

AUDIBLE REMINDERS

Brake pad wear warning

The disc brake pads have audible wear warnings.
When a disc brake pad requires replacement, it
makes a high pitched scraping sound when the
vehicle is in motion, whether or not the brake
pedal is depressed. Have the brakes checked as
soon as possible if the warning sound is heard.

Key reminder chime

A chime sounds if the driver’s door is opened
while the key is left in the ignition switch. Remove
the key and take it with you when leaving the
vehicle.

Light reminder chime

With the ignition switch placed in the OFF posi-
tion, a chime sounds when the driver’s door is
opened if the headlights or parking lights are on.

Turn the headlight control switch off before leav-
ing the vehicle.

NISSAN Intelligent Key® door buzzer
(if so equipped)

The Intelligent Key door buzzer sounds if any one
of the following improper operations is found.

● The ignition switch is not returned to the

LOCK position when locking the doors.

● The Intelligent Key is left inside the vehicle

when locking the doors.

● The Intelligent Key is taken outside the ve-

hicle when operating the vehicle.

● Any doors are not closed securely when

locking the doors.

When the buzzer sounds, be sure to check both
the vehicle and the Intelligent Key. See “NISSAN
Intelligent Key®” in the “Pre-driving checks and
adjustments” section.

Parking brake reminder chime

A chime sounds if the parking brake is set and the
vehicle is driven. The chime will stop if the parking
brake is released or the vehicle speed returns to
zero.

NISSAN VEHICLE IMMOBILIZER
SYSTEM (if so equipped)

The NISSAN Vehicle Immobilizer System will not
allow the engine to start without the use of a
registered key.

If the engine fails to start using a registered key
(for example, when interference is caused by
another registered key, an automated toll road
device or automatic payment device on the key
ring), restart the engine using the following pro-
cedures:

1. Leave the ignition switch in the ON position

for approximately 5 seconds.

2. Turn the ignition switch to the OFF or LOCK

position, and wait approximately 10 sec-
onds.

3. Repeat steps 1 and 2.

4. Restart the engine while holding the device

(which may have caused the interference)
separate from the registered key.

If the no start condition re-occurs, NISSAN rec-
ommends placing the registered key on a sepa-
rate key ring to avoid interference from other
devices.

SECURITY SYSTEMS

2-20

Instruments and controls

FCC Notice:

For USA:

This device complies with part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions; (1) This device may
not cause harmful interference, and (2) this
device must accept any interference re-
ceived, including interference that may
cause undesired operation of the device.

NOTE:

Changes or modifications not expressly ap-
proved by the party responsible for compli-
ance could void the user’s authority to op-
erate the equipment.

For Canada:

This device complies with Industry Canada
license-exempt RSS standard(s). Opera-
tion is subject to the following two condi-
tions: (1) this device may not cause harmful
interference, and (2) this device must ac-
cept any interference received, including
interference that may cause undesired op-
eration of the device.

Security indicator light

This light blinks whenever the ignition switch is
placed in the LOCK, OFF or ACC position.

This function indicates the NISSAN Vehicle Im-
mobilizer System is operational.

If the NISSAN Vehicle Immobilizer System is mal-
functioning, the light will remain on while the
ignition switch is placed in the ON position.

If the light still remains on and/or the en-
gine will not start, see a NISSAN dealer for
NISSAN Vehicle Immobilizer System ser-
vice as soon as possible. Please bring all
registered keys that you have when visiting
your NISSAN dealer for service.

LIC0474

Instruments and controls

2-21

SWITCH OPERATION

The windshield wiper and washer operates when
the ignition switch is in the ON position.

Push the lever down to operate the wiper at the
following speed:

䊊

Intermittent (INT) — intermittent operation
can be adjusted by turning the knob toward

䊊

(Slower) or

䊊

(Faster).

䊊

Low (LO) — continuous low speed operation

䊊

High (HI) — continuous high speed opera-
tion

Push the lever up

䊊

to have one sweep opera-

tion (MIST) of the wiper.

Pull the lever toward you

䊊

to operate the

washer. The wiper will also operate several times.

WARNING

In freezing temperatures the washer solu-
tion may freeze on the windshield and
obscure your vision which may lead to an
accident. Warm the windshield with the
defroster before you wash the windshield.

CAUTION

● Do not operate the washer continuously

for more than 30 seconds.

● Do not operate the washer if the reser-

voir is empty.

● Do not fill the windshield-washer fluid

reservoir with washer fluid concen-
trates at full strength. Some methyl al-
cohol based washer fluid concentrates
may permanently stain the grille if
spilled while filling the windshield-
washer fluid reservoir.

● Pre-mix windshield-washer fluid con-

centrates with water to the manufactur-
er’s recommended levels before pour-
ing the fluid into the windshield-washer
fluid

reservoir.

not

use

the

windshield-washer fluid reservoir to
mix the windshield-washer fluid con-
centrate and water.

Type A

LIC2153

Type B

LIC2131

WINDSHIELD WIPER AND WASHER
SWITCH

2-22

Instruments and controls

To defrost the rear window glass, start the engine
and push the rear window defroster switch on.
The rear window defroster indicator light on the
switch comes on. Push the switch again to turn
the defroster off.

The rear window defroster automatically turns off
after approximately 15 minutes.

CAUTION

When cleaning the inner side of the rear
window, be careful not to scratch or dam-
age the rear window defroster.

HEADLIGHT CONTROL SWITCH

Lighting

䊊

When turning the switch to the

posi-

tion, the front parking, tail, license plate and
instrument panel lights come on.

䊊

When turning the switch to the

posi-

tion, the headlights come on and all the other
lights remain on.

CAUTION

Use the headlights with the engine run-
ning to avoid discharging the vehicle
battery.

LIC2116

Type A

LIC2127

Type B

WIC1509

REAR WINDOW AND OUTSIDE
MIRROR (if so equipped)
DEFROSTER SWITCH

HEADLIGHT AND TURN SIGNAL
SWITCH

Instruments and controls

2-23

Headlight beam select

䊊

To select the high beam function, push the
lever forward. The high beam lights come on
and the

light illuminates.

䊊

Pull the lever back to select the low beam.

䊊

Pulling and releasing the lever flashes the
headlight high beams on and off.

Battery saver system

If the ignition switch is placed in the OFF position
while the headlight switch is in the
or

position, the headlights will turn off after

a period of time.

CAUTION

Even though the battery saver feature au-
tomatically turns off the headlights after a
period of time, you should turn the head-
light switch to the OFF position when the
engine is not running to avoid discharging
the vehicle battery.

DAYTIME RUNNING LIGHT SYSTEM
(Canada only)

The headlights automatically illuminate at a re-
duced intensity when the engine is started with
the parking brake released. The daytime running
lights operate with the headlight switch in the
OFF position. Turn the headlight switch to
the

position for full illumination when driv-

ing at night.

If the parking brake is applied before the engine is
started, the daytime running lights do not illumi-
nate. The daytime running lights illuminate when
the parking brake is released. The daytime run-
ning lights will remain on until the ignition switch
is placed in the OFF position.

WARNING

When the daytime running light system is
active, tail lights on your vehicle are not
on. It is necessary at dusk to turn on your
headlights. Failure to do so could cause
an accident injuring yourself and others.

LIC2128

2-24

Instruments and controls

INSTRUMENT BRIGHTNESS
CONTROL

The instrument brightness control operates when
the headlight control switch is in the
or

position.

Type A: Turn the control

䊊

to adjust the bright-

ness of instrument panel lights when driving at
night.

Type B: Press the control

䊊

to adjust the bright-

ness of instrument panel lights when driving at
night.

TURN SIGNAL SWITCH

Turn signal

䊊

Move the lever up or down to signal the
turning direction. When the turn is com-
pleted, the turn signal cancels automatically.

Lane change signal

䊊

To signal a lane change, move the lever up or
down to the point where the indicator light
begins to flash, but the lever does not latch.

The turn signal will flash three times automati-
cally.

Type A

LIC2289

Type B

LIC2137

WIC1512

Instruments and controls

2-25

FOG LIGHT SWITCH (if so equipped)

To turn the fog lights on, turn the headlight switch
to the

position, then turn the fog light

switch to the

position.

To turn the fog lights off, turn the fog light switch
to the OFF position.

The headlights must be on and the low beams
selected for the fog lights to operate. The fog
lights automatically turn off when the high beam
headlights are selected.

To sound the horn, push near the horn icon on the
steering wheel.

WARNING

Do not disassemble the horn. Doing so
could affect proper operation of the
supplemental front air bag system. Tam-
pering with the supplemental front air bag
system may result in serious personal
injury.

The vehicle should be driven with the Vehicle
Dynamic Control (VDC) system on for most driv-
ing conditions.
If the vehicle is stuck in mud or snow, the VDC
system reduces the engine output to reduce
wheel spin. The engine speed will be reduced
even if the accelerator is depressed to the floor. If
maximum engine power is needed to free a stuck
vehicle, turn the VDC system off.

To turn off the VDC system, push the VDC OFF
switch. The

indicator will come on.

Push the VDC OFF switch again or restart the
engine to turn on the system. See “Vehicle Dy-
namic Control (VDC) system” in the “Starting and
driving” section.

WIC1513

LIC2419

LIC1548

HORN

VEHICLE DYNAMIC CONTROL (VDC)
OFF SWITCH

2-26

Instruments and controls

The power outlet is for powering electrical acces-
sories such as cellular telephones. The outlet is
rated at 12 volt, 120W (10A) maximum.

CAUTION

● The outlet and plug may be hot during

or immediately after use.

● Only certain power outlets are designed

for use with a cigarette lighter unit. Do
not use any other power outlet for an
accessory lighter. See your NISSAN
dealer for additional information.

● Do not use with accessories that exceed

a 12 volt, 120W (10A) power draw. Do
not use double adapters or more than
one electrical accessory.

● Use power outlets with the engine run-

ning to avoid discharging the vehicle
battery.

● Avoid using power outlets when the air

conditioner (if so equipped), headlights
or

rear

window

defroster

(if

equipped) is on.

● Before inserting or disconnecting a

plug, be sure the electrical accessory
being used is turned OFF.

● Push the plug in as far as it will go. If

good contact is not made, the plug may
overheat or the internal temperature
fuse may open.

● When not in use, be sure to close the

cap. Do not allow water or any other
liquid to contact the outlet.

MAP POCKETS

LIC2754

LIC2157

POWER OUTLET

STORAGE

Instruments and controls

2-27

SEATBACK POCKET (if so equipped)

The seatback pocket is located on the back of the
passenger’s seat. The pocket can be used to
store maps.

STORAGE TRAYS

WARNING

Do not place sharp objects in the trays to
help prevent injury in an accident or sud-
den stop.

CUP HOLDERS

CAUTION

● Avoid abrupt starting and braking when

the cup holder is being used to prevent
spilling the drink. If the liquid is hot, it
can scald you or your passenger.

● Use only soft cups in the cup holder.

Hard objects can injure you in an
accident.

LIC1328

LIC2771

Front

LIC2159

2-28

Instruments and controls

CAUTION

● Do not use bottle holder for any other

objects that could be thrown about in
the vehicle and possibly injure people
during sudden braking or an accident.

● Do not use bottle holder for open liquid

containers.

GLOVE BOX

Open the glove box by pulling the handle.

WARNING

Keep glove box lid closed while driving to
help prevent injury in an accident or a
sudden stop.

Bottle holder

LIC2158

Rear

LIC2162

LIC2160

Instruments and controls

2-29

POWER WINDOWS (if so equipped)

WARNING

● Make sure that all passengers have

their hands, etc. inside the vehicle while
it is in motion and before closing the
windows. Use the window lock switch to
prevent unexpected use of the power
windows.

● Do not leave children unattended inside

the vehicle. They could unknowingly ac-
tivate switches or controls and become
trapped in a window. Unattended chil-
dren could become involved in serious
accidents.

The power windows operate when the ignition
switch is placed in the ON position, or for a
period of time after the ignition switch is placed in
the OFF position. If the driver’s or passenger’s
door is opened during this period of time, the
power to the windows is canceled.

Window lock button

Power door lock switch

Front passenger’s side window switch

Right rear passenger’s window switch

Left rear passenger’s window switch

Driver’s side automatic switch

Driver’s side power window switch

The driver’s side control panel is equipped with
switches to open or close the front and rear
passenger windows.

To open a window, push the switch and hold it
down. To close a window, pull the switch and
hold it up. To stop the opening or closing function
at any time, simply release the switch.

WIC0872

WINDOWS

2-30

Instruments and controls

Content .. 4 5 6 7 ..
