Nissan Rogue (2019 year). Instruction

Low Fuel

This warning illuminates when the fuel level
in the fuel tank is getting low. Refuel as
soon as it is convenient, preferably before
the fuel gauge reaches 0 (Empty). There
will be a small reserve of fuel in the tank
when the fuel gauge needle reaches 0
(Empty).

Low Washer Fluid (if so equipped)

This

warning

illuminates

when

the

windshield-washer fluid is at a low level.
Add windshield-washer fluid as necessary.
For

additional

information,

refer

“Windshield-washer fluid” in the “Do-it-
yourself ” section of this manual.

Door/liftgate Open

This warning illuminates when a door or
the liftgate has been opened.

Key System Error: See Owner’s Manual
(if so equipped)

After the ignition switch is pushed to the
ON position, this light comes on for about
2 seconds and then turns off.

The Key System Error message warns of a
malfunction with the Intelligent Key sys-

tem. If the light comes on while the engine
is stopped, it may be impossible to start
the engine.

If the light comes on while the engine is
running, you can drive the vehicle. However
in these cases, contact a NISSAN dealer for
repair as soon as possible.

Loose Fuel Cap

This warning appears when the fuel-filler
cap is not tightened correctly after the ve-
hicle has been refueled. For additional in-
formation, refer to “Fuel-filler cap” in the
“Pre-driving checks and adjustments” sec-
tion of this manual.

Tire Pressure Low - Add Air

This warning appears when the low tire
pressure warning light in the meter illumi-
nates and low tire pressure is detected. The
warning appears each time the ignition
switch is placed in the ON position as long
as the low tire pressure warning light re-
mains illuminated. If this warning appears,
stop the vehicle and adjust the tire pres-
sures of all four tires to the recommended
COLD tire pressure shown on the Tire and
Loading Information label. For additional
information, refer to “Low tire pressure
warning light” in this section and “Tire Pres-

sure Monitoring System (TPMS)” in the
“Starting

and

driving”

section

this

manual.

Flat Tire – Visit dealer (if so equipped)

This warning appears when the low tire
pressure warning light in the meter illumi-
nates and one or more flat tires are de-
tected while driving. A chime also sounds
for approximately 10 seconds.

Low Oil Pressure Stop Vehicle

This warning appears in the message area
of the vehicle information display if low oil
pressure is detected. This gauge is not de-
signed to indicate low oil level. The low oil
pressure warning is not designed to indi-
cate a low oil level. Use the dipstick to
check the oil level. For additional informa-
tion, refer to “Engine oil” in the “Do-it-
yourself ” section of this manual.

AWD Error: See Owner’s Manual (if so
equipped)

This warning appears when the all-wheel
drive system is not functioning properly
while the engine is running.

2-36

Instruments and controls

AWD High Temp. Stop vehicle (if so
equipped)

This warning may appear while trying to
free a stuck vehicle due to increased oil
temperature.

The

driving

mode

may

change to 2-Wheel Drive (2WD). If this warn-
ing is displayed, stop the vehicle with the
engine idling, as soon as it is safe to do so.
Then if the warning turns off, you can con-
tinue driving.

Tire Size Incorrect: See Owner’s Manual
(if so equipped)

This warning may appear if there is a large
difference between the diameters of the
front and rear wheels. Pull off the road in a
safe area, with the engine idling. Check that
all the tire sizes are the same, that the tire
pressure is correct and that the tires are
not excessively worn.

Battery Voltage Low Charge Battery

This warning appears when the battery is
low and needs to be charged.

Shipping Mode On Push Storage Fuse

This warning may appear if the extended
storage switch is not pushed in. When this
warning appears, push in the extended
storage switch to turn off the warning. For

additional information, refer to “Extended
storage switch” in this section.

Power will turn off to save the battery

This warning appears in the message area
of the vehicle information display after a
period of time if the shift lever has not
moved from the P (Park) position.

Power turned off to save the battery

This warning appears after the ignition
switch is automatically turned off to save
the battery.

Reminder: Turn OFF Headlights

This warning appears when the headlights
are left in the ON position when exiting the
vehicle. Place the headlight switch to OFF
or AUTO position. For additional informa-
tion, refer to “Headlight and turn signal
switch” in this section.

Headlight System Error: See Owner’s
Manual (if so equipped)

This warning illuminates when there is an
error with the system. For additional infor-
mation, refer to “Headlight and turn signal
switch” in this section.

Timer Alert – Time for a driver break?

This indicator appears when the set time is
reached. The time can be set up to six
hours. For additional information on set-
ting the timer, refer to “Alarm” in this sec-
tion.

Chassis Control System Error: See Own-
er’s Manual (if so equipped)

This warning appears if the Integrated
Dynamics-control Module detects an error
in the Intelligent Trace Control, Intelligent
Engine Brake, or the Active Ride Control
systems. Have the system checked. It is
recommended that you visit a NISSAN
dealer for this service. For additional infor-
mation, refer to “Chassis control” in the
“Starting

and

driving”

section

this

manual.

Cruise control indicator (if so equipped)

This indicator shows the cruise control sys-
tem status.

For additional information, refer to “Cruise
control” in the “Starting and driving” section
of this manual.

Instruments and controls

2-37

Intelligent Cruise Control (ICC) indica-
tors (if so equipped)

These

indicators

show

the

Intelligent

Cruise Control (ICC) system status. The sta-
tus is shown by color. For additional infor-
mation, refer to “Intelligent Cruise Control
(ICC)” in the “Starting and driving” section of
this manual.

Transmission Shift Position Indicator

This indicator shows the transmission shift
position.

CVT Error: See Owner’s Manual

This warning illuminates when there is a
problem with the CVT system. If this warn-
ing comes on, have the system checked. It
is recommended that you visit a NISSAN
dealer for this service.

Malfunction: See Owner’s Manual (if so
equipped)

This warning appears when one or more of
the following systems (if so equipped) is
not functioning properly:

∙ Automatic Emergency Braking (AEB)

with Pedestrian Detection

∙ Rear Automatic Braking (RAB)

∙ Lane Departure Warning (LDW)

∙ Blind Spot Warning (BSW)

∙ Intelligent Cruise Control (ICC)

If one or more of these warning appears,
have the system checked. It is recom-
mended that you visit a NISSAN dealer for
this service.

Drive mode indicators

These indicators illuminate in the vehicle
information display when either the ECO or
SPORT modes are selected.

For additional information, refer to “SPORT
mode switch” or “ECO mode switch” in the
“Starting and driving” or the section of this
manual.

Unavailable: High Cabin Temp. (if so
equipped)

This message appears when the camera
detects an interior temperature of more
than approximately 104°F (40°C). For addi-
tional information, refer to “Lane Departure
Warning (LDW)” and “Intelligent Lane Inter-
vention (I-LI)” in the “Starting and driving”
section of this manual.

Unavailable: Road is slippery (if so
equipped)

This message appears when the Intelligent
Lane Intervention (I-LI) system becomes
unavailable because the road is slippery.
For additional information, refer to “ Intelli-
gent Lane Intervention (I-LI)” in the “Starting
and driving” section of this manual.

Unavailable: VDC OFF (if so equipped)

This message appears when the Intelligent
Lane Intervention (I-LI) system becomes
unavailable because the VDC is turned off.
For additional information, refer to “ Intelli-
gent Lane Intervention (I-LI)” in the “Starting
and driving” section of this manual.

Unavailable: Front Radar Obstruction (if
so equipped)

This message appears when the Intelligent
Cruise Control (ICC), Automatic Emergency
Braking (AEB), Automatic Emergency Brak-
ing (AEB) with Pedestrian Detection, and/or
ProPILOT Assist system(s) become unavail-
able because the front radar is obstructed.
For additional information, refer to “Intelli-
gent

Cruise

Control

(ICC)”,

“Automatic

Emergency

Braking

(AEB)”,

“Automatic

Emergency Braking (AEB) with Pedestrian

2-38

Instruments and controls

Detection” and/or “ProPILOT Assist” in the
“Starting

and

driving”

section

this

manual.

Side Radar Obstruction (if so equipped)

This message appears when the Blind
Spot Warning (BSW) or Rear Cross Traffic
Alert (RCTA) systems become unavailable
because a radar blockage is detected. For
additional information, refer to “Blind Spot
Warning (BSW)” or “Rear Cross Traffic Alert
(RCTA)” in the “Starting and driving” section
of this manual.

Lane Departure Warning (LDW) indicator
(if so equipped)

This indicator shows when the LDW and
Intelligent Lane Intervention (I-LI) systems
are engaged.

For additional information, refer to “Lane
Departure Warning (LDW) system” and “In-
telligent Lane Intervention (I-LI)” in the
“Starting

and

driving”

section

this

manual.

Intelligent Lane Intervention (I-LI) indi-
cator (if so equipped)

This indicator shows when the I-LI system
is engaged.

For additional information, refer to “Dy-
namic driver assistance switch” in this sec-
tion and “Intelligent Lane Intervention (I-LI)”
in the “Starting and driving” section of this
manual.

Steering Assist indicator (if so
equipped)

This indicator appears when the Steering
Assist system is engaged.

For additional information, refer to “ProPI-
LOT Assist” in the “Starting and driving” sec-
tion of this manual.

Not Available Poor Road Conditions (if
so equipped)

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system or the ICC system is en-
gaged.

Under the following conditions, the ICC
(with ProPILOT Assist) or the ICC system is
automatically canceled:

∙ When the VDC operates

∙ When a wheel slips

The above system cannot be used in some
situations (VDC operates and wheel slip.)

Currently not available (if so equipped)

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system or the ICC system is en-
gaged.

Under the following conditions, the ICC
(with ProPILOT Assist) or the ICC system is
automatically canceled:

∙ When the VDC operates

∙ When a wheel slips

∙ When the VDC system is turned off

The above system cannot be used in some
situations (VDC operates, wheel slip and
VDC system is off.)

Not Available Front Camera Obstructed
(if so equipped)

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system is engaged.

Under the following conditions, the ICC
(with ProPILOT Assist) system is automati-
cally canceled:

∙ The camera area of the windshield is

fogged up or covered with dirt, water,
drops, ice, snow, etc.

Instruments and controls

2-39

∙ Strong light, such as sunlight or high

beams from oncoming vehicles, enter
the front camera

∙ When the wiper (HI) operates

The system will be available when the
above conditions no longer exist.

If the warning message continues to ap-
pear, stop the vehicle in a safe location, turn
the engine off and clean the windshield.

Steering Assist Currently unavailable (if
so equipped)

This message may appear when the Steer-
ing Assist system is engaged.

Under the following conditions, the Steer-
ing Assist system is automatically can-
celed:

∙ When the wiper (LO) operates

∙ When lane markers in the traveling lane

cannot be correctly detected for a pe-
riod of time due to such items as a
snow rut, reflection of light on a rainy
day or several unclear lane markers are
present

If you want to use the Steering Assist sys-
tem again, cancel the ProPILOT Assist sys-
tem and set it again when lane markers are
clearly visible.

Not Available Front camera visibility is
impaired (if so equipped)

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system is engaged.

Under the following conditions, the ICC
(with ProPILOT Assist) system is automati-
cally canceled:

∙ The camera area of the windshield is

fogged up or covered with dirt, water,
drops, ice, snow, etc.

∙ Strong light, such as sunlight or high

beams from oncoming vehicles, enter
the front camera

∙ When the wiper (HI) operates

The system will be available when the
above conditions no longer exist.

If the warning message continues to ap-
pear, stop the vehicle in a safe location, turn
the engine off and clean the windshield.

Not Available Parking Brake On (if so
equipped)

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system is engaged.

Under the following condition, the ICC (with
ProPILOT Assist) system is automatically
canceled:

∙ The electronic parking brake is applied

The above system cannot be used when
the electric parking brake is activated.

Not Available Seat Belt Not Fastened (if
so equipped)

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system is engaged.

Under the following condition, the ICC (with
ProPILOT Assist) system is automatically
canceled:

∙ When the driver’s seat belt is not fas-

tened

The above system cannot be used when
the driver’s seat belt is not fastened.

2-40

Instruments and controls

Step on Brake Now (if so equipped)

This message may appear when the Intel-
ligent Cruise Control (ICC) (with ProPILOT
Assist) system is engaged.

It will be displayed under the following con-
dition:

∙ While the vehicle is stopped by the ICC

(with ProPILOT Assist), the driver’s door
is opened but the electronic parking
brake was not activated.

Please step on the brake immediately.

Steering Assist Alert (if so equipped)

This message may appear when the Steer-
ing Assist system is engaged.

It will be displayed under the following con-
dition:

∙ When not holding the steering wheel or

when there is no steering wheel opera-
tion

Please hold on the steering wheel immedi-
ately. When the steering operation is de-
tected, the warning turns off and the steer-
ing

assist

function

automatically

restored.

Automatic Emergency Braking (AEB)
emergency warning indicator (if so
equipped)

This indicator illuminates along, with an au-
dible warning, when the system detects
the possibility of a forward collision.

For additional information, refer to “Auto-
matic Emergency Braking (AEB)” in the
“Starting

and

driving”

section

this

manual.

Rear Door Alert is activated

When the system is enabled, this message
appears when the Rear Door Alert system
is active and can remind the driver to check
the back seat.

∙ Using the steering wheel switch, a driver

can select “Dismiss Message” to clear
the display for a period of time. If no
selection is made, this message auto-
matically turns off after a period of time.

∙ Using the steering wheel switch, a driver

can select “Disable Alert” to disable the
horn alert for the remainder of the cur-
rent trip.

WARNING

Selecting “Dismiss Message” during a
stop within a trip temporarily dismisses
the message for that stop without turn-
ing the system off. Alerts can be pro-
vided for other stops during the trip. Se-
lecting “Disable Alert” turns off the Rear
Door Alert system for the remainder of
a trip and no audible alert will be
provided.

NOTE:

This system is disabled until a driver en-
ables it using the vehicle information
display. For additional information, refer
to “How to use the vehicle information
display” in this section.

For additional information, refer to “Rear
Door Alert” in this section.

Check Back Seat For All Articles

When the system is enabled, this message
appears when the vehicle comes to a com-
plete stop, the vehicle is transitioned from
the D (Drive) position to P (Park) position,
and the driver exits the vehicle. This mes-
sage alerts the driver, after a period of time,
to check for items in the rear seat after the
audible alert has been provided.

Instruments and controls

2-41

NOTE:

This system is disabled until a driver en-
ables it using the vehicle information
display. For additional information, refer
to “How to use the vehicle information
display” in this section.

For additional information, refer to “Rear
Door Alert” in this section.

Rear Automatic Braking (RAB) indicator
(if so equipped)

This indicator illuminates to indicate the
status of the Rear Automatic Braking (RAB)
system. For additional information, refer to
“Rear Automatic Braking (RAB) system” in
the “Starting and driving” section of this
manual.

Rear Sonar System (RSS) indicator (if so
equipped)

This indicator illuminates to indicate the
status of the RSS. For additional informa-
tion, refer to “Rear Sonar System (RSS)” in
the “Starting and driving” section of this
manual.

Parking Sensor Error: See Owner’s
Manual (if so equipped)

This warning illuminates when there is an
error with the system. For additional infor-
mation, refer to “Rear Sonar System (RSS)”
in the “Starting and driving” section of this
manual.

Blind Spot Warning (BSW) indicator

This indicator shows when the BSW system
is engaged.

For additional information, refer to “Blind
Spot Warning (BSW)” in the “Starting and
driving” section of this manual.

System Fault (if so equipped)

This warning appears if there is a malfunc-
tion in the Rear Automatic Braking (RAB)
system. For additional information, refer to
“Rear Automatic Braking (RAB)” in the “Start-
ing and driving” section of this manual.

Your vehicle may have two types of security
systems:

∙ Vehicle security system

∙ NISSAN Vehicle Immobilizer System

VEHICLE SECURITY SYSTEM

The vehicle security system provides visual
and audible alarm signals if someone
opens the doors or liftgate when the sys-
tem is armed. It is not, however, a motion
detection type system that activates when
a vehicle is moved or when a vibration oc-
curs.

LIC2385

SECURITY SYSTEMS

2-42

Instruments and controls

The system helps deter vehicle theft but
cannot prevent it, nor can it prevent the
theft of interior or exterior vehicle compo-
nents in all situations. Always secure your
vehicle even if parking for a brief period.
Never leave your keys in the vehicle, and
always lock the vehicle when unattended.
Be aware of your surroundings, and park in
secure, well-lit areas whenever possible.
Many devices offering additional protection,
such as component locks, identification
markers, and tracking systems, are available
at auto supply stores and specialty shops. A
NISSAN dealer may also offer such equip-
ment. Check with your insurance company
to see if you may be eligible for discounts for
various theft protection features.

How to arm the vehicle security
system

1. Close all windows. (The system can be

armed even if the windows are open.)

2. Remove the keys from the vehicle.

3. Close all doors and liftgate. Lock all

doors. The doors can be locked with
the key fob (if so equipped), Intelligent
Key (if so equipped), door handle re-
quest switch, or mechanical key (if so
equipped).

4. Confirm that the

security indica-

tor light stays on for about 30 seconds.
The vehicle security system is now pre-
armed. The vehicle security system will
automatically shift into the armed
phase. The

security light begins

to flash once every three seconds. If
during the pre-armed phase one of the
following occurs, the system will not
arm:

∙ Any door is unlocked with the key fob (if

so equipped), the Intelligent Key (if so
equipped),

mechanical

key

(if

equipped), or door request switch.

∙ Ignition switch is placed in the ON posi-

tion.

∙ Even when the driver and/or passen-

gers are in the vehicle, the system will
activate with all the doors, hood and
liftgate

locked

with

the

ignition

switch placed in the LOCK position.
When placing the ignition switch in
the ON position, the system will be
released.

Vehicle security system activation

The vehicle security system will give the
following alarm:

∙ The headlights blink and the horn

sounds

intermittently

but

synchro-

nously.

∙ The alarm automatically turns off after

a period of time. However, the alarm
reactivates if the vehicle is tampered
with again.

The alarm is activated by:

∙ opening any door or the liftgate without

using the key or Intelligent Key (even if
the door is unlocked by releasing the
door inside lock knob).

How to stop an activated alarm

The alarm stops only by unlocking a door
or the liftgate with the mechanical key (if so
equipped), the key fob (if so equipped),
pressing the

button on the Intelligent

Key (if so equipped), or pushing the request
switch on the driver’s or passenger’s door
with the Intelligent Key (if so equipped) in
range of the door handle.

Instruments and controls

2-43

NISSAN VEHICLE IMMOBILIZER
SYSTEM

The NISSAN Vehicle Immobilizer System
will not allow the engine to start without
the use of a registered key.

Never leave these keys in the vehicle.

FCC Notice:

For USA:

This device complies with Part 15 of the
FCC Rules. Operation is subject to the fol-
lowing two conditions: (1) This device
may not cause harmful interference, and
(2) this device must accept any interfer-
ence received, including interference
that may cause undesired operation.

NOTE:

Changes or modifications not expressly
approved by the party responsible for
compliance could void the user’s author-
ity to operate the equipment.

For Canada:

This

device

complies

with

Industry

Canada licence-exempt RSS standard(s).
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must ac-
cept any interference received, including
interference that may cause undesired
operation of the device.

Security indicator light

The security indicator light blinks whenever
the ignition switch is placed in the OFF or
LOCK position.

This function indicates the NISSAN Vehicle
Immobilizer System is operational.

If the NISSAN Vehicle Immobilizer System is
malfunctioning, the light will remain on
while the ignition switch is placed in the ON
position.

LIC0474

2-44

Instruments and controls

If the light still remains on and/or the
engine will not start, seek service for the
NISSAN Vehicle Immobilizer System ser-
vice as soon as possible. Please bring all
registered keys that you have. It is rec-
ommended that you visit a NISSAN
dealer for this service.

SWITCH OPERATION

WARNING

In freezing temperatures the washer
solution may freeze on the windshield
and obscure your vision which may lead
to an accident. Warm the windshield
with the defroster before you wash the
windshield.

CAUTION

∙ Do not operate the washer continu-

ously for more than 30 seconds.

∙ Do not operate the washer if the

windshield-washer fluid reservoir is
empty.

∙ Do not fill the windshield-washer fluid

reservoir

with

windshield-washer

fluid concentrates at full strength.
Some

methyl

alcohol

based

windshield-washer

fluid

concen-

trates may permanently stain the
grille

spilled

while

filling

the

windshield-washer fluid reservoir.

∙ Pre-mix windshield-washer fluid con-

centrates with water to the manufac-
turer’s recommended levels before
pouring the fluid into the windshield-
washer fluid reservoir. Do not use the
windshield-washer fluid reservoir to
mix the windshield-washer fluid con-
centrate and water.

LIC2661

WIPER AND WASHER SWITCH

Instruments and controls

2-45

NOTE:

If the windshield wiper operation is in-
terrupted by snow or ice, the wiper may
stop moving to protect its motor. If this
occurs, turn the wiper switch to the OFF
position and remove the snow or ice that
is on and around the wiper arms. In ap-
proximately 1 minute, turn the switch on
again to operate the wiper.

The windshield wiper and washer operates
when the ignition switch is in the ON posi-
tion.

Push the lever down to operate the wiper
at the following speed:

䊊

Intermittent — intermittent operation
can be adjusted by turning the knob
toward

䊊

(Slower) or

䊊

(Faster). Also,

the intermittent operation speed var-
ies in accordance with the vehicle
speed. (For example, when the vehicle
speed is high, the intermittent opera-
tion speed will be faster.)

䊊

Low — continuous low speed opera-
tion

䊊

High — continuous high speed opera-
tion

Lift the lever up

䊊

to have one sweep op-

eration (MIST) of the wiper.

Pull the lever toward you

䊊

to operate the

washer. The wiper will also operate several
times.

After a short delay the drip wipe function
will operate the wiper once more to clear
remaining windshield-washer fluid from
the windshield.

NOTE:

The Speed Dependent feature and Drip
Wipe feature may be disabled. For addi-
tional information, refer to “Vehicle in-
formation display” in this section.

REAR SWITCH OPERATION

WARNING

In freezing temperatures the washer
solution may freeze on the window and
obscure your vision. Warm the rear win-
dow with the defroster before you wash
the rear window.

LIC2662

2-46

Instruments and controls

CAUTION

∙ Do not operate the washer continu-

ously for more than 30 seconds.

∙ Do not operate the washer if the

windshield-washer fluid reservoir is
empty.

∙ Do not fill the windshield-washer fluid

reservoir

with

windshield-washer

fluid concentrates at full strength.
Some

methyl

alcohol

based

windshield-washer

fluid

concen-

trates may permanently stain the
grille

spilled

while

filling

the

windshield-washer fluid reservoir.

∙ Pre-mix windshield-washer fluid con-

NOTE:

If the rear window wiper operation is in-
terrupted by snow, etc., the wiper may
stop moving to protect its motor. If this
occurs, turn the wiper switch to OFF and
remove the snow, etc. on and around the
wiper arms. After about 1 minute, turn
the switch ON again to operate the wiper.

The rear window wiper and washer oper-
ate when the ignition switch is in the ON
position. Turn the switch clockwise from
the OFF position to operate the wiper.

䊊

Intermittent (INT) — intermittent op-
eration (not adjustable)

䊊

Low (ON) — continuous low speed op-
eration

Push the switch forward

䊊

to operate the

washer. The wiper will also operate several
times.

NOTE:

The Reverse Link feature may be dis-
abled. For additional information, refer
to “Vehicle information display” in this
section.

To defrost the rear window glass and out-
side mirrors (if so equipped), start the en-
gine and push the rear window defroster
switch on. The rear window defroster indi-
cator light on the switch comes on. Push
the switch again to turn the defroster off.

The rear window defroster automatically
turns off after approximately 15 minutes.

CAUTION

When cleaning the inner side of the rear
window, be careful not to scratch or
damage the rear window defroster.

Type A (if so equipped)

LIC2614

REAR WINDOW AND OUTSIDE
MIRROR (if so equipped)
DEFROSTER SWITCH

Instruments and controls

2-47

HEADLIGHT CONTROL SWITCH

Lighting

䊊

Rotate the switch to the

position,

and the front parking, tail, license plate,
and instrument panel lights will come
on.

䊊

Rotate the switch to the

position,

and the headlights will come on and all
the other lights remain on.

CAUTION

Use the headlights with the engine run-
ning to avoid discharging the vehicle
battery.

Type B (if so equipped)

LIC2324

Type A (if so equipped)

LIC2634

Type B (if so equipped)

LIC2635

HEADLIGHT AND TURN SIGNAL
SWITCH

2-48

Instruments and controls

Autolight system (if so equipped)

The autolight system allows the headlights
to turn on and off automatically. The auto-
light system can:

∙ Turn on the headlights, front parking,

tail, license plate and instrument panel
lights automatically when it is dark.

∙ Turn off all the lights when it is light.

∙ Keep all the lights on for a period of time

after you place the ignition switch in the
OFF position and all doors are closed.

NOTE:

Autolight activation sensitivity and the
time delay for autolight shutoff can be
adjusted. For additional information, re-
fer to “Vehicle information display” in
this section.
To turn on the autolight system:

1. Turn the headlight switch to the AUTO

position

䊊

2. Turn the ignition switch to ON.

3. The autolight system automatically

turns the headlights on and off.

Initially, if the ignition switch is placed in the
OFF position and a door is opened and left
open, the headlights remain on for a period
of time. If another door is opened while the
headlights are on, then the timer is reset.

To turn the autolight system off, turn the

switch to the OFF,

, or

position.

Be sure you do not put anything on top
of the autolight sensor located in the top
side

䊊

of the instrument panel. The au-

tolight sensor controls the autolight; if it
is covered, the autolight sensor reacts as
if it is dark out and the headlights will
illuminate. If this occurs while parked
with the engine off and the ignition
switch placed in the ON position, your
vehicle’s battery could become dis-
charged.

LIC2636

LIC3051

Instruments and controls

2-49

Headlight beam select

䊊

To select the high beam function, push
the lever forward. The high beam lights
come on and the

light illumi-

nates.

䊊

Pull the lever back to select the low
beam.

䊊

Pulling and releasing the lever flashes
the headlight high beams on and off.

High Beam Assist (if so equipped)

The High Beam Assist system will operate
when the vehicle is driven at speeds of ap-
proximately 25 mph (40 km/h) and above. If

an oncoming vehicle or leading vehicle ap-
pears in front of your vehicle when the
headlight high beam is on, the headlight
will be switched to the low beam automati-
cally.

WARNING

∙ The High Beam Assist system is a con-

venience but it is not a substitute for
safe driving operation. The driver
should remain alert at all times, en-
sure safe driving practices and switch
the high beams and low beam manu-
ally when necessary.

∙ The high beam or low beam may not

switch automatically under the fol-
lowing conditions. Switch the high
beam and low beam manually.

– During bad weather (rain, fog,

snow, wind, etc.).

– When a light source similar to a

headlight or tail light is in the vicin-
ity of the vehicle.

– When the headlights of the on-

coming vehicle or the leading ve-
hicle are turned off, when the color
of the light is affected due to for-
eign materials on the lights, or
when the light beam is out of
position.

– When there is a sudden, continu-

ous change in brightness.

– When driving on a road that passes

over rolling hills, or a road that has
level differences.

– When driving on a road with many

curves.

– When a sign or mirror-like surface

is reflecting intense light towards
the front of the vehicle.

– When the container, etc. being

towed by a leading vehicle is re-
flecting intense light.

– When a headlight on your vehicle is

damaged or dirty.

– When the vehicle is leaning at an

angle due to a punctured tire, be-
ing towed, etc.

LIC2637

2-50

Instruments and controls

∙ The timing of switching the low beam

and high beam may change under the
following situations.

– The brightness of the headlights of

the oncoming vehicle or leading
vehicle.

– The movement and direction of

the oncoming vehicle and the lead-
ing vehicle.

– When only one light on the oncom-

ing vehicle or the leading vehicle is
illuminated.

– When the oncoming vehicle or the

leading vehicle is a two-wheeled
vehicle.

– Road conditions (incline, curve, the

road surface, etc.).

– The number of passengers and the

amount of luggage.

High Beam Assist operation

To activate the High Beam Assist system,
turn the headlight switch to the AUTO po-
sition

䊊

and push the lever forward

䊊

(high beam position). The High Beam Assist
indicator light in the meter will illuminate
while the headlights are turned on.

If the High Beam Assist indicator light does
not illuminate in the above condition, it may
indicate that the system is not functioning
properly. Have the system checked, it is
recommended that you visit a NISSAN
dealer for this service.

When the vehicle speed lowers to less than
approximately 16 mph (25 km/h), the head-
light uses the low beam.
To turn off the High Beam Assist system,
turn the headlight switch to the

posi-

tion or select the low beam position by
placing the lever in the neutral position.

LIC3696

Instruments and controls

2-51

Nissan Rogue (2019 year). Instruction - part 8
