P0327, P0328 KS EC-277 < COMPONENT DIAGNOSIS > [QR25DE FOR CALIFORNIA] C D E F G H I J K L M A EC N P O 3. CHECK KNOCK SENSOR INPUT SIGNAL CIRCUIT FOR OPEN AND SHORT 1. Check the continuity between knock sensor harness connector and ECM harness connector. 2. Also check harness for short to ground and short to power. YES >> GO TO 4. NO >> Repair open circuit or short to ground or short to power in harness or connectors. 4. CHECK KNOCK SENSOR EC-277, "Component Inspection" Is the inspection result normal? YES >> GO TO 5. NO >> Replace knock sensor. 5. CHECK INTERMITTENT INCIDENT GI-42, "Intermittent Incident" . >> INSPECTION END Component Inspection INFOID:0000000004349315 1. CHECK KNOCK SENSOR 1. Turn ignition switch OFF. 2. Disconnect knock sensor harness connector. 3. Check resistance between knock sensor terminals as follows. NOTE: It is necessary to use an ohmmeter which can measure more than 10 M Ω. CAUTION: Do not use any knock sensors that have been dropped or phys- ically damaged. Use only new ones. YES >> INSPECTION END NO >> Replace knock sensor. Knock sensor ECM Continuity Connector Terminal Connector Terminal F45 1 F13 61 Existed Terminals Resistance 1 and 2 Approx. 532 - 588 k Ω [at 20°C (68°F)] JMBIA1630ZZ |
