REAR SEAT BELT
SB-13
< ON-VEHICLE REPAIR >
C
D
E
F
G
I
J
K
L
M
A
B
SB
N
O
P
3. Remove the anchor bolt, then remove D-ring anchor bolt.
4. Remove retractor screw and retractor anchor bolt, then remove seat belt retractor outer.
INSTALLATION OF SEAT BELT RETRACTOR (COUPE OUTER)
Installation is in the reverse order of removal.
• Always perform an inspection after repair to be sure the system is functioning within specifications. Refer to
.
REMOVAL OF SEAT BELT RETRACTOR (COUPE CENTER)
1. Remove the rear seat cushion and seat back. Refer to
SE-25, "Removal and Installation"
2. Remove the rear parcel shelf finisher. Refer to
INT-17, "Removal and Installation"
.
3. Remove the anchor bolt.
4. Remove the retractor anchor bolt, then remove seat belt retractor center.
INSTALLATION OF SEAT BELT RETRACTOR (COUPE CENTER)
Installation is in the reverse order of removal.
• Always perform an inspection after repair to be sure the system is functioning within specifications. Refer to
.
REMOVAL OF SEAT BELT BUCKLE
1. Remove the rear seat cushion. Refer to
SE-25, "Removal and Installation"
2. Remove buckle anchor bolt, then remove the seat belt buckle. Refer to
INSTALLATION OF SEAT BELT BUCKLE
Installation is in the reverse order of removal.
• Always perform an inspection after repair to be sure the system is functioning within specifications. Refer to
.
