Nissan Altima L32. Manual - part 1051





PG

HARNESS

PG-111

< COMPONENT DIAGNOSIS >

[SEDAN]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

E3

E204

: Body ground

E4

E220

GR/4

: Cooling fan motor-1

E3

E205

B/3

: To E13

D4 E221

GR/4

: Cooling fan motor-2

E3

E206

: Body ground

A4

E222

B/2

: Front combination lamp RH (high)

A4

E208

W/2

: Washer fluid level switch

A3

E223

B/2

: Front combination lamp RH (low)(halogen)

B3

E209

: Body ground

A3

E223

GR/2

: Front combination lamp RH (low)(xenon)

D4 E210

Y/2

: Crash zone sensor

A3

E224

GR/3

: Front combination lamp RH (turn signal)

D5 E211

B/2

: Ambient sensor

B3

E225

B/2

: Front combination lamp RH (parking)

B2

E212

B/2

: Front combination lamp LH (low)
  (halogen)

B4

E226

B/2

: Front washer motor

G3 E212

GR/2

: Front combination lamp LH (low)
  (Xenon)

A5

E227

B/2

: Front fog lamp RH

G4 E213

B/2

: Front combination lamp LH (high)

C4 E228

B/5

: Daytime light relay

G5 E214

B/2

: Front fog lamp LH

B3

E229

: Body ground

G4 E215

B/1

: Horn (low)

C3 E230

: Generator

PG-112

< COMPONENT DIAGNOSIS >

[SEDAN]

HARNESS

ENGINE CONTROL HARNESS (VQ35DE)

ABMIA0548GB

G2

F1

W/16

: To E3

C3

F35

GR/3

: Ignition coil No. 2 (with power transistor)

F2

F2

W/10

: To E11

C1

F36

GR/3

: Ignition coil No. 3 (with power transistor)

C5

F3

B/2

: A/C Compressor

D4

F37

GR/3

: Ignition coil No. 4 (with power transistor)

F2

F4

: Fusible link box (battery)

C1

F38

GR/3

: Ignition coil No. 5 (with power transistor)

G3

F5

B/3

: Battery current sensor

D3

F39

GR/3

: Ignition coil No. 6 (with power transistor)

PG

HARNESS

PG-113

< COMPONENT DIAGNOSIS >

[SEDAN]

C

D

E

F

G

H

I

J

K

L

B

A

O

P

N

C4

F6

: Generator

A2

F40

B/3

: Power steering pressure sensor

C5

F7

B/3

: Generator

A4

F41

GR/1

: Oil pressure switch

E4

F8

W/3

: Primary speed sensor

E4

F46

B/22

: CVT unit

A3

F9

: Engine ground

D1

F55

B/3

: Camshaft position sensor (PHASE)(bank1)

G1

F10

W/36

: IPDM E/R (intelligent power distri-
  bution module engine room)

D4

F56

B/4

: Heated oxygen sensor 2 (bank 2)

E3

F11

GR/2

: Engine coolant temperature sensor

D1

F57

B/6

: Electric throttle control actuator

C1

F12

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 1)

D3

F60

B/3

: Camshaft position sensor (PHASE)(bank2)

F3

F13

BR/48

: ECM

C3

F61

GR/4

: Air fuel ratio (A/F) sensor 1 (bank 2)

F3

F14

GR/32

: ECM

A2

F62

B/4

: Heated oxygen sensor 2 (bank 1)

A3

F15

: Engine ground

B2

F63

B/2

: VIAS control solenoid valve 1

E4

F16

B/48

: TCM (transmission control module)

B3

F64

B/2

: Electric controlled engine mount control
  solenoid valve

B2

F17

GR/2

: Fuel injector No. 1

C2

F65

B/2

: VIAS control solenoid valve 2

C3

F18

GR/2

: Fuel injector No. 2

A3

F66

G/2

: Intake valve timing control solenoid
  valve (bank 2)

C2

F19

GR/2

: Fuel injector No. 3

A2

F67

G/2

: Intake valve timing control solenoid
  valve (bank 1)

C2

F20

GR/2

: Fuel injector No. 4

A3

F68

GR/2

: Engine oil temperature sensor

C2

F21

GR/2

: Fuel injector No. 5

G2

F70

B/10

: Joint connector-F01

D2

F22

GR/2

: Fuel injector No. 6

B1

F71

GR/6

: Joint connector-F03

E2

F23

B/3

: Secondary speed sensor

F4

F72

B/10

: Joint connector-F04

E3

F24

B/2

: Back-up lamp switch

F4

F73

B/10

: Joint connector-F05

E2

F26

GR/2

: Condenser-2

D3

F74

W/4

: Joint connector-F08

F3

F27

: Starter motor

G2

F75

W/4

: Joint connector-F07

F3

F28

GR/1

: Starter motor

E2

F76

L/4

: To F201

D2

F29

L/2

: EVAP canister purge volume control
  solenoid valve

Knock sensor sub-harness

D4

F30

B/3

: Crankshaft position sensor (POS)

E2

F201

L/4

: To F76

D1

F31

B/6

: Mass air flow sensor

C3

F202

GR/2

: Knock sensor (bank 1)

E3

F32

B/2

: Park/neutral position (PNP) switch

C3

F203

GR/2

: Knock sensor (bank 2)

B1

F34

GR/3

: Ignition coil No. 1 (with power
  transistor)

PG-114

< COMPONENT DIAGNOSIS >

[SEDAN]

HARNESS

ENGINE CONTROL HARNESS (QR25DE)

ABMIA0549GB

F2

F1

W/16

: To E3

E1

F31

B/6

: Mass air flow sensor

G2 F2

W/10

: To E11

E2

F32

B/2

: Park/neutral position (PNP) switch (with M/T)

C4 F3

B/12

: A/C Compressor

B3

F34

GR/3

: Ignition coil No. 1 (with power transistor)

F2

F4

: Fusible link box (battery)

B2

F35

GR/3

: Ignition coil No. 2 (with power transistor)

G3 F5

B/3

: Battery current sensor

C3

F36

GR/3

: Ignition coil No. 3 (with power transistor)
