SYSTEM

HAC-15

< SYSTEM DESCRIPTION >

[MANUAL AIR CONDITIONING]

C

D

E

F

G

H

J

K

L

M

A

B

HAC

N

O

P

AIR DISTRIBUTION

1.

Intake door

2.

Blower motor

3.

Evaporator

4.

Air mix door

5.

Heater core

6.

Foot door

7.

Ventilator and defroster door
Fresh air intake

Recirculation air

Defroster

Center ventilator

Side ventilator

Foot

Switch/Dial

position

Door position

V

en

tilat

or an

d

de

fr

os

te

r do

or

Fo

ot

 do

or

In

ta

ke

 do

or

Ai

r mi

x do

or

MODE dial

B

A

—

—

A – B

A

A – B

A – B

A

Air intake lever

—

—

A

B

Temperature control dial

Full cold

—

A

Full hot

B

ALIIA0807ZZ

HAC-16

< SYSTEM DESCRIPTION >

[MANUAL AIR CONDITIONING]

SYSTEM

Discharge air flow

Mode position indication

Air outlet/distribution

Ventilator

Foot

Defroster

Center

Side

50%

50%

—

—

30%

30%

40%

—

—

14%

66%

20%

—

14%

51%

35%

—

22%

—

78%

OPERATION

HAC-17

< SYSTEM DESCRIPTION >

[MANUAL AIR CONDITIONING]

C

D

E

F

G

H

J

K

L

M

A

B

HAC

N

O

P

OPERATION

Switch Name and Function

INFOID:0000000009477932

CONTROLLER

SWITCH OPERATION

1.

Fan control dial (fan switch)

2.

MODE dial

3.

Intake lever

4.

Temperature control dial

5.

A/C switch

JMIIA0933ZZ

Fan control dial (fan
switch)

Fan speed can be adjusted within a range from 1st to 4th.

MODE dial

Mode position is selected to an optimal position by operating this dial.

Intake lever

The air inlet changes REC

⇔ FRE each time by operation this lever.

Temperature control dial

The setting temperature can be selected to an optimum temperature by operating this dial.

A/C switch

The compressor control (switch indicator) is turned ON

⇔ OFF each time by pressing this switch

while the blower motor is activated.

HAC-18

< SYSTEM DESCRIPTION >

[MANUAL AIR CONDITIONING]

DIAGNOSIS SYSTEM (BCM)

DIAGNOSIS SYSTEM (BCM)

COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON ITEM)

INFOID:0000000009567625

APPLICATION ITEM

CONSULT performs the following functions via CAN communication with BCM.

SYSTEM APPLICATION

BCM can perform the following functions.

AIR CONDITIONER

Direct Diagnostic Mode

Description

ECU identification

The BCM part number is displayed.

Self Diagnostic Result

The BCM self diagnostic results are displayed.

Data Monitor

The BCM input/output data is displayed in real time.

Active Test

The BCM activates outputs to test components.

Work support

The settings for BCM functions can be changed.

Configuration

• The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.

CAN DIAG SUPPORT MNTR

The result of transmit/receive diagnosis of CAN communication is displayed.

System

Sub System

Direct Diagnostic Mode

ECU id

en

tif

ica

tion

Se

lf Di

ag

no

st

ic

 Res

u

lt

Dat

a

 M

on

ito

r

Acti

ve

 T

est

W

o

rk

 su

pp

ort

Co

nf

ig

ur

at

io

n

CAN DIAG SUP

P

OR

T MNTR

Door lock

DOOR LOCK

×

×

×

×

Rear window defogger

REAR DEFOGGER

×

×

Warning chime

BUZZER

×

×

Interior room lamp timer

INT LAMP

×

×

×

Exterior lamp

HEAD LAMP

×

×

×

Wiper and washer

WIPER

×

×

×

Turn signal and hazard warning lamps FLASHER

×

×

Air conditioner

AIR CONDITIONER

×

Intelligent Key system

INTELLIGENT KEY

×

×

×

×

Combination switch

COMB SW

×

BCM

BCM

×

×

×

×

×

Immobilizer

IMMU

×

×

×

Interior room lamp battery saver

BATTERY SAVER

×

×

×

Vehicle security system

THEFT ALM

×

×

×

RAP system

RETAINED PWR

×

×

Signal buffer system

SIGNAL BUFFER

×
