DLK-132
< REMOVAL AND INSTALLATION >
REAR DOOR
2. Disconnect the harness connector (A) from rear door.
3. Remove door check link bolt (body side).
4. Remove door hinge nuts (door side) and rear door assembly.
INSTALLATION
Installation is in the reverse order of removal.
CAUTION:
• Apply anticorrosive agent to the hinge mating surface.
• After installation, perform the rear door adjustment procedure. Refer to
DLK-133, "DOOR ASSEMBLY
: Adjustment"
.
• After adjusting, apply touch-up paint (body color) to the head of door hinge nuts.
• Check door hinge rotating point for poor lubrication. If neces-
sary, apply a suitable multi-purpose grease.
JMKIA8084ZZ
JMKIA8072ZZ
