DIAGNOSIS SYSTEM (BCM)
DIAGNOSIS SYSTEM (BCM)
COMMON ITEM
COMMON ITEM : CONSULT Function (BCM - COMMON ITEM)
INFOID:0000000009567628
APPLICATION ITEM
CONSULT performs the following functions via CAN communication with BCM.
SYSTEM APPLICATION
BCM can perform the following functions.
REAR DEFOGGER
Direct Diagnostic Mode
Description
ECU identification
The BCM part number is displayed.
Self Diagnostic Result
The BCM self diagnostic results are displayed.
Data Monitor
The BCM input/output data is displayed in real time.
Active Test
The BCM activates outputs to test components.
Work support
The settings for BCM functions can be changed.
Configuration
• The vehicle specification can be read and saved.
• The vehicle specification can be written when replacing BCM.
CAN DIAG SUPPORT MNTR
The result of transmit/receive diagnosis of CAN communication is displayed.
System
Sub System
Direct Diagnostic Mode
ECU id
