Nissan Note E12. Manual - part 106

CL-1

TRANSMISSION & DRIVELINE

C

E

F

G

H

I

J

K

L

M

SECTION

CL

A

B

CL

N

O

P

CONTENTS

CLUTCH

PRECAUTION ...............................................

2

PRECAUTIONS ...................................................

2

Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ...................................................................

2

General Precautions  .................................................

2

PREPARATION ............................................

3

PREPARATION ...................................................

3

Commercial Service Tools  ........................................

3

SYMPTOM DIAGNOSIS  ...............................

4

NOISE, VIBRATION AND HARSHNESS
(NVH) TROUBLESHOOTING  .............................

4

NVH Troubleshooting Chart  ......................................

4

PERIODIC MAINTENANCE ..........................

5

CLUTCH PEDAL  .................................................

5

Inspection and Adjustment ........................................

5

CLUTCH FLUID ...................................................

6

Inspection ..................................................................

6

Draining .....................................................................

6

Refilling .....................................................................

7

Air Bleeding ...............................................................

8

REMOVAL AND INSTALLATION ...............

10

CLUTCH PEDAL  ................................................

10

Exploded View  ........................................................

10

Removal and Installation .........................................

10

Inspection and Adjustment  ......................................

11

CLUTCH MASTER CYLINDER  ........................

12

Exploded View .........................................................

12

Removal and Installation  .........................................

12

Inspection and Adjustment  ......................................

13

CLUTCH PIPING ...............................................

14

Exploded View .........................................................

14

Hydraulic Layout ......................................................

14

Removal and Installation  .........................................

14

Inspection and Adjustment  ......................................

15

UNIT REMOVAL AND INSTALLATION ......

16

CSC (CONCENTRIC SLAVE CYLINDER)  .......

16

Exploded View .........................................................

16

Removal and Installation  .........................................

16

Inspection and Adjustment  ......................................

17

CLUTCH DISC AND CLUTCH COVER  ............

18

Exploded View .........................................................

18

Removal and Installation  .........................................

18

Inspection ................................................................

19

SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................

21

SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................

21

General Specifications .............................................

21

Clutch Pedal  ............................................................

21

Clutch Disc  ..............................................................

21

Clutch Cover ............................................................

21

CL-2

< PRECAUTION >

PRECAUTIONS

PRECAUTION

PRECAUTIONS

Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"

INFOID:0000000009578850

The Supplemental Restraint System such as “AIR BAG” and “SEAT BELT PRE-TENSIONER”, used along

with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain

types of collision. Information necessary to service the system safely is included in the SR and SB section of

this Service Manual.

WARNING:

• To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death in

the event of a collision which would result in air bag inflation, all maintenance must be performed by

an authorized NISSAN/INFINITI dealer.

• Improper maintenance, including incorrect removal and installation of the SRS, can lead to personal

injury caused by unintentional activation of the system. For removal of Spiral Cable and Air Bag

Module, see the SR section.

• Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this

Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or har-

ness connectors.

PRECAUTIONS WHEN USING POWER TOOLS (AIR OR ELECTRIC) AND HAMMERS

WARNING:

• When working near the Airbag Diagnosis Sensor Unit or other Airbag System sensors with the Igni-

tion ON or engine running, DO NOT use air or electric power tools or strike near the sensor(s) with a

hammer. Heavy vibration could activate the sensor(s) and deploy the air bag(s), possibly causing

serious injury.

• When using air or electric power tools or hammers, always switch the Ignition OFF, disconnect the

battery and wait at least three minutes before performing any service.

General Precautions

INFOID:0000000009417548

WARNING:

After cleaning clutch disc, wipe it with a dust collector. Do not use compressed air.

CAUTION:

• Always use recommended clutch fluid. Refer to

MA-12, "Fluids and Lubricants"

.

• Do not reuse drained clutch fluid.

• Keep painted surface on the body and other parts free of clutch fluid. If fluid spills, wipe up immedi-

ately and wash the affected area with water.

• Do not use mineral oils, such as gasoline or kerosene. It will ruin the rubber parts of the hydraulic

system.

• Do not reuse CSC (Concentric Slave Cylinder). CSC slides back to the original position every time

when removing transaxle assembly. At this time, dust on the sliding parts may damage the seal of

CSC and may cause clutch fluid leakage. Refer to

CL-16, "Removal and Installation"

.

• Do not disassemble clutch master cylinder and CSC.

PREPARATION

CL-3

< PREPARATION >

C

E

F

G

H

I

J

K

L

M

A

B

CL

N

O

P

PREPARATION

PREPARATION

Commercial Service Tools

INFOID:0000000009417550

Tool name

Description

Clutch aligner

Installing clutch disc

Power tool

Loosening nuts, screws and bolts

ST20050240
( — )
Diaphragm adjusting wrench

Adjusting unevenness of diaphragm spring le-
ver

MCIB0404E

PIIB1407E

ZZA0508D

CL-4

< SYMPTOM DIAGNOSIS >

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000009417551

Use the chart below to find the cause of the symptom. The numbers indicate the order of the inspection. If nec-

essary, repair or replace these parts.

Reference page

CL-5

CL-8

EM-85

CL-17

CL-19

CL-18

SUSPECTED PARTS (Possible cause)

CL

UTCH

 PEDAL (I

ns

pe

ct

io

n an

d ad

ju

st

m

e

nt

)

CLUTCH

 LINE (Air

in

line)

ENGINE MOUNTING

(Loose)

CSC (Co

nc

en

tric

 Sl

av

e Cy

linde

r) (W

orn

, d

irty

 o

r da

ma

ge

d)

CLUTCH

 DISC (Out of true)

CLUTCH

 DISC

(Ru

nou

t i

s

ex

ce

ss

iv

e)

CLUTCH

 DISC (Lining broken)

CLUTCH

 DISC (Dirty or burned)

CLUTCH

 DISC

(Oily)

CLUTCH

 DISC (W

orn out)

CLUTCH

 DISC

(Hardened)

CLUTCH

 DISC

(Lack

of

 spl

in

e gre

a

se

)

DIAP

H

RA

G

M SPRI

N

G

(D

amaged)

DI

APH

R

AG

M SPRIN

G

(O

ut

 of

 ti

p

al

ig

nm

en

t)

PRESS

UR

E

 PLA

T

E

 (Distort

ion)

FL

Y

W

HEEL (Distortion)

Symptom

Clutch grabs/chatters

1

2

2

2

2

2

Clutch pedal spongy

1

2

Clutch noisy

1

Clutch slips

1

2

2

3

4

5

Clutch  does  not  disengage

1

2

3

3

3

3

3

3

3

4

4

5
