MWI-26
< ECU DIAGNOSIS INFORMATION >
COMBINATION METER
DTC Index
INFOID:0000000009758256
Warning lamp/indicator lamp
ABS warning lamp
The lamp turns ON by suspending communication.
EPS warning lamp
Malfunction indicator lamp (MIL)
Brake warning lamp
High beam indicator lamp
The lamp turns OFF by suspending communication.
Turn signal indicator lamp
Door warning lamp
Position lamp indicator lamp
Engine start operation indicator lamp
Shift P warning lamp
Front fog lamp indicator lamp
Rear fog lamp indicator lamp
Engine Oil pressure warning lamp
KEY warning lamp
CRUISE indicator lamp
SPORT indicator lamp
Function
Specifications
Display contents of CONSULT
Diagnostic item is detected when...
Refer to
CAN COMM CIRCUIT
[U1000]
When combination meter is not transmitting or receiving CAN communication signal
for 2 seconds or more.
CONTROL UNIT (CAN)
[U1010]
When detecting error during the initial diagnosis of the CAN controller of combina-
tion meter.
VEHICLE SPEED
[B2205]
The abnormal vehicle speed signal is input from the ABS actuator and electric unit
(control unit) for 2 seconds or more.
ENGINE SPEED
[B2267]
If ECM continuously transmits abnormal engine speed signals for 2 seconds or
more.
WATER TEMP
[B2268]
If ECM continuously transmits abnormal engine coolant temperature signals for 60
seconds or more.
