Fail-safe Mode
NMEC0675
Detected items
Engine operating condition in fail-safe mode
Mass air flow sensor circuit
Engine speed will not rise more than 2,400 rpm due to the fuel
cut.
DTC Confirmation Procedure
NMEC0676
CAUTION:
Always drive vehicle at a safe speed.
NOTE:
If “DTC Confirmation Procedure” has been previously conducted,
always turn ignition switch “OFF” and wait at least 5 seconds
before conducting the next test.
SEC447C
PROCEDURE FOR MALFUNCTION A
NMEC0676S01
With CONSULT-II
1)
Turn ignition switch “ON”.
2)
Select “DATA MONITOR” mode with CONSULT-II.
3)
Wait at least 5 seconds.
4)
If DTC is detected, go to “Diagnostic Procedure”, EC-102.
Without CONSULT-II
1)
Turn ignition switch “ON”, and wait at least 5 seconds.
2)
Turn ignition switch “OFF”, wait at least 5 seconds and then
turn “ON”.
3)
Perform “Diagnostic Test Mode II (Self-diagnostic results)” with
ECM.
4)
If DTC is detected, go to “Diagnostic Procedure”, EC-102.
SEC447C
PROCEDURE FOR MALFUNCTION B
NMEC0676S02
With CONSULT-II
1)
Turn ignition switch “ON”.
2)
Select “DATA MONITOR” mode with CONSULT-II.
3)
Start engine and wait at least 2 seconds.
4)
If DTC is detected, go to “Diagnostic Procedure”, EC-102.
Without CONSULT-II
1)
Start engine and wait at least 2 seconds.
2)
Turn ignition switch “OFF”, wait at least 5 seconds and then
turn “ON”.
GI
MA
EM
LC
FE
CL
MT
AT
PD
AX
SU
BR
ST
RS
BT
HA
SC
EL
IDX
DTC 0102 MASS AIR FLOW SENSOR (MAFS)
Fail-safe Mode
EC-99
