MULTI AV SYSTEM SYMPTOMS
AV-161
< SYMPTOM DIAGNOSIS >
[BOSE AUDIO WITH NAVIGATION]
C
D
E
F
G
H
I
J
K
L
M
B
A
O
P
Symptoms
Probable malfunction location
None of the steering switch operations work.
Steering switch ground circuit malfunction.
Refer to
AV-156, "Diagnosis Procedure"
.
Only specified switch cannot be operated.
Steering switch malfunction.
Steering switch's “SOURCE”, “SEEK UP”, “SEEK DOWN”,
“
”, “START / STOP” switches do not work.
Steering switch signal A circuit malfunction.
Refer to
AV-152, "Diagnosis Procedure"
.
Steering switch's “MRK”, “VOL UP”, “VOL DOWN”, “
”
switches do not work.
Steering switch signal B circuit malfunction.
Refer to
AV-154, "Diagnosis Procedure"
.
