SE-54

< REMOVAL AND INSTALLATION >

FRONT SEAT

2.

Remove the seat cushion outer finisher outside.

3.

Disconnect the connectors of seat control switch, heater switch, and thigh support (driver seat only)
switch.

4.

Remove the seat cushion inner finisher outside.

5.

Remove the seatback trim retainer.

6.

Remove the seatback panel.
• Unfasten the seatback trim fastener.
• Remove the seatback cover panel mounting screws, and then

remove the seatback cover panel.

7.

Disconnect the harness connector.

Driver side

1.

Disconnect the reclining limit switch harness connector (A),
the heater unit harness connectors (B), and the reclining
motor harness connector (C).

: Metal clip

: Pawl

JMJIA2137ZZ

: Metal clip

: Pawl

JMJIA2138ZZ

JMJIA2141ZZ

JMJIA5892ZZ

FRONT SEAT

SE-55

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

2.

Remove the side air bag harness (D).

Passenger side

1.

Disconnect the reclining motor harness connector (E), the
heater unit harness connectors (F), and the reclining limit
switch harness connector (G).

2.

Remove the side air bag harness (J).

8.

Remove the seatback assembly.
Remove the seatback mounting bolts (A), and then remove the
seatback assembly.

9.

Remove the seat belt buckle. Refer to

SB-8, "SEAT BELT BUCKLE : Removal and Installation"

.

Assembly

Assemble in the reverse order of disassembly.

CAUTION:

Install the hog rings of seat cushion trim in position, and then securely connect the trim or trim cord
with the pad side wire.

NNJIA0137ZZ

JMJIA5592ZZ

NNJIA0146ZZ

JMJIA2153ZZ

SE-56

< REMOVAL AND INSTALLATION >

REAR SEAT

REAR SEAT

Exploded View

INFOID:0000000009162951

Removal and Installation

INFOID:0000000009162952

REMOVAL

CAUTION:

Use shop cloths to protect parts from damage during removal and installation.

1.

Remove the seat cushion.

1.

Seatback (RH)

2.

Seat cushion (RH)

3.

Seatback (LH)

4.

Seat cushion (LH)

Refer to

GI-4, "Components"

 for symbols in the figure.

NNJIA0138GB

REAR SEAT

SE-57

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

• Lift up the seat cushion lower side, disengage the joint by pull-

ing the ring (1) of the cushion hook on the front bottom, and
then lift up the seat cushion (2) to remove the seat cushion.

• Remove the seat cushion from the vehicle.

2.

Remove the seatback.
• Remove the seatback lower mounting nut.
• Remove the seatback from the vehicle.

INSTALLATION

Install in the reverse order of removal.

CAUTION:

Use shop cloths to protect parts from damage during removal and installation.

JMJIA0251ZZ
