SE-50

< REMOVAL AND INSTALLATION >

FRONT SEAT

For the seat with side air bag, disconnect the battery cable from the negative terminal after check-
ing that the ignition switch is OFF, wait for at least 3 minutes, and then disconnect the connector.

10. Remove the front seat from the vehicle.

CAUTION:

• Use shop cloths to protect parts from damage during removal and installation.
• Two people must perform removal and installation of the seat assembly to prevent damage or to

keep from dropping it.

INSTALLATION

Install in the reverse order of removal.

CAUTION:

• Always fix the harness clamp in the normal position.
• Be careful that only driver seat rear inner mounting bolt is different from others among the front seat

mounting bolts.

Disassembly and Assembly

INFOID:0000000009162950

Seatback

Disassembly

1.

Unfasten the seatback trim fastener.

2.

Remove the seatback trim lower retainer.

3.

Remove the seatback (main).
• Remove the seatback cover panel mounting screws, and then

remove the seatback cover panel.

4.

Remove the retainer and hog ring of the seatback assembly (main), and then remove the seatback
assembly (main).

5.

Remove the seat cushion outer finisher outside.

6.

Disconnect the connectors of seat control switch, heater switch, and thigh support (Driver seat only)
switch.

JMJIA2141ZZ

: Metal clip

: Pawl

JMJIA2137ZZ

FRONT SEAT

SE-51

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

7.

Remove the seat cushion inner finisher outside.

8.

Remove the seatback ornament.

9.

Remove knob.

a.

Press on the seatback surface near the knob mounting portion
inward to expose the fixing portion of the knob.

b.

Disengage knob fixing pawl, and then remove knob.

: Metal clip

: Pawl

JMJIA2138ZZ

: Pawl

JMJIA2139ZZ

JMJIA8391ZZ

: Pawl

JMJIA8392ZZ

SE-52

< REMOVAL AND INSTALLATION >

FRONT SEAT

10. Remove the walk-in lever knob (1) and walk-in lever escutcheon

(2).

11. Disconnect the harness connector.

Driver side

1.

Disconnect the reclining limit switch harness connector (A),
the heater unit harness connectors (B), and the reclining
motor harness connector (C).

2.

Remove the side air bag harness (D).

Passenger side

1.

Disconnect the reclining motor harness connector (E), the
heater unit harness connectors (F), and the reclining limit
switch harness connector (G).

: Pawl

JMJIA2140ZZ

JMJIA5892ZZ

NNJIA0137ZZ

JMJIA5592ZZ

FRONT SEAT

SE-53

< REMOVAL AND INSTALLATION >

C

D

E

F

G

H

I

K

L

M

A

B

SE

N

O

P

2.

Remove the side air bag harness (J).

12. Remove the seatback assembly.

Remove the seatback assembly mounting bolts (A).

13. Remove the seat cushion outer finisher inside (front) and the seat cushion outer finisher inside (rear).
14. Remove the seat cushion inner finisher inside (front) and the seat cushion inner finisher inside (rear).

15. Remove the reclining device outer cover (outside) and the reclining device outer cover (inside).

16. Remove the reclining device inner cover (outside) and the reclining device inner cover (inside).

Assembly

Assemble in the reverse order of disassembly.

CAUTION:

Install the hog rings of seatback trim in position, and then securely connect the trim or trim cord with
the pad side wire.

Seat cushion

Disassembly

1.

Remove the seat cushion.
• Disconnect the harness connector from the seat cushion heater unit.
• Remove the seat cushion lower surface mounting bolts (A).

• Remove the seat cushion trim retainer from the lower rear of the seat cushion.

NNJIA0146ZZ

JMJIA2153ZZ

JMJIA2136ZZ
