C1160 DECEL G SEN SET BRC-73 < COMPONENT DIAGNOSIS > [TYPE 1] C D E G H I J K L M A B BRC N O P C1160 DECEL G SEN SET Description INFOID:0000000003937805 The yaw rate/side/decel G sensor detects the yaw rate/side/decel G affecting the vehicle, and transmits the DTC Logic INFOID:0000000003937806 DTC DETECTION LOGIC DTC CONFIRMATION PROCEDURE 1. CHECK SELF-DIAGNOSIS RESULTS Check the self-diagnosis results. Is above displayed on the self-diagnosis display? YES >> Proceed to diagnosis procedure. Refer to . NO >> Inspection End Diagnosis Procedure INFOID:0000000003937807 1. PERFORM SELF-DIAGNOSIS Perform ABS actuator and electric unit (control unit) self-diagnosis. Do self-diagnosis results indicate anything other than shown above? YES >> Perform repair or replacement for the item indicated. NO >> Perform calibration of decel G sensor. Refer to BRC-13, "CALIBRATION OF DECEL G SENSOR . GO TO 2 2. PERFORM SELF-DIAGNOSIS AGAIN 1. Turn the ignition switch to OFF and then to ON and erase self-diagnosis results. 2. Perform ABS actuator and electric unit (control unit) self-diagnosis again. Are any self-diagnosis results displayed? YES >> Replace yaw rate/side/decel G sensor. Refer to BRC-135, "Removal and Installation" NO >> Inspection End DTC Display item Malfunction detected condition Possible cause C1160 DECEL G SEN SET ABS decel G sensor adjustment is incomplete. • Decel G sensor calibration (control unit) Self-diagnosis results DECEL G SEN SET Self-diagnosis results DECEL G SEN SET 2009 Pathfinder |
