Nissan Pathfinder (2008 year). Manual - part 223





DLN-368

< PREPARATION >

[FRONT FINAL DRIVE: M205]

PREPARATION

KV38102200
(

—

)

Drift

Installing front oil seal.
a: 90 mm (3.54 in) dia.
b: 55.3 mm (2.18 in) dia.

ST33081000
(

—

)

Adapter

Removing and installing side bearing inner
race.
a: 43 mm (1.69 in) dia.
b: 33.5 mm (1.32 in) dia.

KV38108300
(J-44195)
Companion flange wrench

Removing and installing drive pinion nut.

ST3127S000
(J-25765-A)
Preload gauge
1. GG91030000
    (J-25765)
    Torque wrench
2. HT62940000
    (

—

)

    Socket adapter (1/2

″

)

3. HT62900000
    (

—

)

    Socket adapter (3/8

″

)

Inspecting drive pinion bearing preload and
total preload

—

(C-4040)
Installer

Installing drive pinion rear bearing inner race.

KV40105230
(

—

)

Drift

Installing drive pinion rear bearing outer race.
a: 92 mm (3.62 in) dia.
b: 85.5 mm (3.37 in) dia.

Tool number
(Kent-Moore No.)
Tool name

Description

NT660

ZZA1000D

NT771

NT124

SDIA2607E

ZZA0898D

PREPARATION

DLN-369

< PREPARATION >

[FRONT FINAL DRIVE: M205]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

Commercial Service Tool

INFOID:0000000001315884

—

(C-4171)
Handle

• Removing drive pinion front bearing outer

race

• Removing drive pinion rear bearing outer

race

—

(D-103)
Remover

Removing drive pinion front bearing outer
race

—

(C-4307)
Remover

Removing drive pinion rear bearing outer
race

Tool number
(Kent-Moore No.)
Tool name

Description

LDIA0134E

LDIA0135E

LDIA0135E

(Kent-Moore No.)
Tool name

Description

(SP8P)
Slide hammer

• Removing front oil seal
• Removing side oil seal

Power tool

Loosening bolts and nuts

LDIA0133E

PBIC0190E

DLN-370

< FUNCTION DIAGNOSIS >

[FRONT FINAL DRIVE: M205]

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

FUNCTION DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000001315885

Use the chart below to help you find the cause of the symptom. If necessary, repair or replace these parts.

×

: Applicable

Reference page

DLN-378

DLN-378

DLN-378

DLN-378

DLN-378

DLN-371

DLN

-30

6,

 "

NV

H T

rou

ble

s

hoo

ti

ng Cha

rt

"

DLN

-31

4,

 "

NV

H T

rou

ble

s

hoo

ti

ng Cha

rt

"

DLN

-32

3,

 "

NV

H T

rou

ble

s

hoo

ti

ng Cha

rt

"

F

AX-4, "

NVH T

rou

bl

es

ho

ot

in

g

 Cha

rt

"

FSU-4,

 "

NVH T

ro

u

b

les

h

oot

in

g Ch

art

"

WT

-33,

 "

NVH T

ro

u

b

les

ho

ot

ing

 Ch

art

"

WT

-33,

 "

NVH T

ro

u

b

les

ho

ot

ing

 Ch

art

"

F

AX-4, "

NVH T

rou

bl

es

ho

ot

in

g

 Cha

rt

"

BR-5, "

NVH T

ro

u

b

les

ho

ot

ing

 Ch

art

"

ST

-9

, "

NVH T

rou

bl

es

ho

ot

in

g

 Cha

rt

"

Possible cause and SUSPECTED PARTS

Ge

ar t

o

o

th

rou

g

h

Gea

r co

nt

ac

t i

m

p

rop

er

T

o

ot

h s

u

rf

ac

es

 w

o

rn

In

c

o

rre

ct ba

ck

la

sh

Co

mp

an

io

n f

lan

ge

 e

x

c

e

s

s

iv

e

 run

o

u

t

Gea

r oi

l i

m

p

rop

er

PR

OP

EL

LE

R

 S

H

A

F

T

FRO

N

T A

X

L

E

F

R

ONT

 SUSPENSI

ON

TI

RE

S

ROAD W

H

EEL

DRIV

E

 SHAFT

BR

AK

E

S

S

T

EERING

Symptom

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×

×

DIFFERENTIAL GEAR OIL

DLN-371

< ON-VEHICLE MAINTENANCE >

[FRONT FINAL DRIVE: M205]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

ON-VEHICLE MAINTENANCE

DIFFERENTIAL GEAR OIL

Changing Differential Gear Oil

INFOID:0000000001315886

DRAINING

1.

Stop the engine.

2.

Remove the drain plug from the front final drive assembly to drain the differential gear oil.

3.

Install the drain plug with sealant applied on the threads to the front final drive assembly. Tighten to the
specified torque. Refer to

DLN-378, "Disassembly and Assembly"

.

• Use High Performance Thread Sealant or equivalent. Refer to

GI-26, "Recommended Chemical Prod-

ucts and Sealants"

.

FILLING

1.

Remove the filler plug from the front final drive assembly.

2.

Fill the front final drive assembly with new differential gear oil
until the level reaches the specified level near the filler plug hole.

3.

Install the filler plug with sealant applied on the threads to the
front final drive assembly. Tighten to the specified torque. Refer
to

DLN-378, "Disassembly and Assembly"

.

• Use High Performance Thread Sealant or equivalent. Refer to

GI-26, "Recommended Chemical Products and Sealants"

.

Checking Differential Gear Oil

INFOID:0000000001315887

DIFFERENTIAL GEAR OIL LEAKAGE AND LEVEL

1.

Make sure that differential gear oil is not leaking from the front final drive assembly or around it.

2.

Check the differential gear oil level from the filler plug hole as
shown.

CAUTION:

Do not start engine while checking differential gear oil level.

3.

Install the filler plug with sealant applied on the threads to the
front final drive assembly. Tighten to the specified torque. Refer
to

DLN-378, "Disassembly and Assembly"

.

• Use High Performance Thread Sealant or equivalent. Refer to

GI-26, "Recommended Chemical Products and Sealants"

.

Differential gear oil
grade and capacity

: Refer to

MA-10, "Fluids

and Lubricants"

.

LDIA0176E

LDIA0176E

DLN-372

< ON-VEHICLE REPAIR >

[FRONT FINAL DRIVE: M205]

SIDE OIL SEAL

ON-VEHICLE REPAIR

SIDE OIL SEAL

Removal and Installation

INFOID:0000000001315889

REMOVAL

1.

Remove the front final drive assembly. Refer to

DLN-376, "Removal and Installation"

.

2.

Remove the differential side shaft and differential side flange
using suitable tool.

3.

Place a small hole in the side oil seal case using suitable tool.

4.

Remove the side oil seal using Tool as shown.

INSTALLATION

1.

Apply multi-purpose grease to the lips of the new side oil seal. Then drive the new side oil seal in evenly to
the gear carrier using suitable tool.

CAUTION:

• Do not reuse side oil seal.
• Do not incline the new side oil seal when installing.
• Apply multi-purpose grease to the lips of the new side oil seal.

2.

Installation of the remaining components is in the reverse order of removal.

CAUTION:

Check the differential gear oil level after installation. Refer to

DLN-371

.

BDIA0006E

LDIA0129E

Tool number

: SP8P

LDIA0130E

FRONT OIL SEAL

DLN-373

< ON-VEHICLE REPAIR >

[FRONT FINAL DRIVE: M205]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

FRONT OIL SEAL

Removal and Installation

INFOID:0000000001315888

REMOVAL

1.

Remove the drive shafts from the front final drive assembly. Refer to

FAX-6, "Removal and Installation"

.

2.

Remove the front propeller shaft from the front final drive assembly. Refer to

DLN-308, "Removal and

Installation"

.

3.

Measure the total preload torque. Refer to

DLN-378, "Disassembly and Assembly"

.

NOTE:
Record the total preload torque measurement.

4.

Remove the drive pinion lock nut using Tool.

5.

Put matching marks on the companion flange and drive pinion
using paint.

CAUTION:

Use paint to make the matching marks. Do not damage the
companion flange or drive pinion.

6.

Remove companion flange using suitable tool.

7.

Place a small hole in the front oil seal case using suitable tool.

8.

Remove the front oil seal using Tool as shown.

Tool number

: KV38108300 (

—

)

BDIA0001E

LDIA0171E

LDIA0129E

Tool number

: SP8P

LDIA0130E

DLN-374

< ON-VEHICLE REPAIR >

[FRONT FINAL DRIVE: M205]

FRONT OIL SEAL

INSTALLATION

1.

Apply multi-purpose grease to the lips of the new front oil seal.
Then drive the new front oil seal in evenly to the gear carrier
using Tool.

CAUTION:

• Do not reuse front oil seal.
• Do not incline the new front oil seal when installing.
• Apply multi-purpose grease to the lips of the new front oil

seal.

2.

Install the companion flange to the drive pinion while aligning the matching marks.

3.

Apply anti-corrosive oil to the threads of the drive pinion and the
seating surface of the new drive pinion lock nut. Then adjust the
drive pinion lock nut tightening torque using Tool A, and check
the total preload torque using Tool B.

• The total preload torque should be within the total preload

torque specification. When not replacing the collapsible
spacer, it should also be equal to the measurement taken dur-
ing removal plus an additional 0.56 N·m (0.06 Kg-m, 5 in-lb).

• If the total preload torque is low, tighten the drive pinion lock

nut in 6.8 N·m (0.69 Kg-m, 5ft-lb) increments until the total pre-
load torque is met.

CAUTION:

• Do not reuse drive pinion lock nut.
• Apply anti-corrosive oil to the threads of the drive pinion

and the seating surface of the new drive pinion lock nut.

• Adjust the drive pinion lock nut tightening torque to the

lower limit first. Do not exceed the drive pinion lock nut
specified torque. Refer to

DLN-378, "Disassembly and Assembly"

.

• Do not loosen drive pinion lock nut to adjust the total preload torque. If the drive pinion lock nut

torque or the total preload torque exceeds the specifications, replace the collapsible spacer and
tighten it again to adjust. Refer to

DLN-378, "Disassembly and Assembly"

.

• After adjustment, rotate drive pinion back and forth 2 to 3 times to check for unusual noise, rota-

tion malfunction, and other malfunctions.

4.

Installation of the remaining components is in the reverse order of removal.

CAUTION:

Check the differential gear oil level after installation. Refer to

DLN-371

.

Tool number

: KV38100500 (J-25273)

BDIA0003E

Tool number

A: KV38108300 (

—

)

B: ST3127S000 (J-25765-A)

Total preload torque:

Refer to

DLN-378, "Disassem-

bly and Assembly"

.

WDIA0381E

CARRIER COVER

DLN-375

< ON-VEHICLE REPAIR >

[FRONT FINAL DRIVE: M205]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

CARRIER COVER

Removal and Installation

INFOID:0000000001315890

REMOVAL

1.

Remove the front final drive assembly. Refer to

DLN-376, "Removal and Installation"

.

2.

Remove the carrier cover bolts and separate the carrier cover
from the gear carrier using Tool.

CAUTION:

• Do not damage the mating surface.
• Do not insert flat-bladed screwdriver, this will damage the

mating surface.

INSTALLATION

1.

Apply 3 mm (0.12 in) bead of sealant to the mating surface of
the carrier cover as shown.
• Use Genuine Silicone RTV or equivalent. Refer to

GI-26,

"Recommended Chemical Products and Sealants"

.

CAUTION:

Remove any old sealant adhering to the mating surfaces.
Also remove any moisture, oil, or foreign material adhering
to the application and mating surfaces.

2.

Install the carrier cover to the gear carrier. Tighten the bolts to
the specified torque. Refer to

DLN-378, "Disassembly and

Assembly"

.

3.

Install the front final drive assembly. Refer to

DLN-376,

"Removal and Installation"

.

CAUTION:

Fill the front final drive assembly with recommended differential gear oil. Refer to

DLN-371

.

Tool number

: KV10111100 (J-37228)

PDIA0699E

SDIA3204E















Content      ..     221      222      223      224     ..
