Nissan Pathfinder (2008 year). Manual - part 15





DRIVER SEAT CONTROL UNIT

ADP-107

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

ALJIA0176GB

ADP-108

< ECU DIAGNOSIS >

DRIVER SEAT CONTROL UNIT

ALJIA0177GB

DRIVER SEAT CONTROL UNIT

ADP-109

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

ALJIA0178GB

ADP-110

< ECU DIAGNOSIS >

DRIVER SEAT CONTROL UNIT

ALJIA0179GB

DRIVER SEAT CONTROL UNIT

ADP-111

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

ALJIA0180GB

ADP-112

< ECU DIAGNOSIS >

DRIVER SEAT CONTROL UNIT

Fail Safe

INFOID:0000000001711099

The fail-safe mode may be activated if the following symptoms are observed.

FAIL-SAFE MODE

When any manual and automatic operations are not performed, if any motor operations of front seat LH or
pedals are detected for T2 or more, status is judged “Output error”.

ALJIA0181GB

DRIVER SEAT CONTROL UNIT

ADP-113

< ECU DIAGNOSIS >

C

D

E

F

G

H

I

K

L

M

A

B

ADP

N

O

P

NOTE:
The front seat LH position and pedal adjustment functions (see the following table) operate simultaneously in
the order of priority.

*: In conjunction with sliding the seat, the door mirrors are positioned.

CANCEL OF FAIL-SAFE MODE

The mode is cancelled when the A/T selector lever is shifted to P position from any other position.

DTC Index

INFOID:0000000001711100

*1

:

• 0: Current malfunction is present

• 1-39: Displayed if any previous malfunction is present when current condition is normal. The numeral value increases by one at each

IGN ON to OFF cycle from 1 to 39. The counter remains at 39 even if the number of cycles exceeds it. However, the counter is reset
to 1 if any malfunction is detected again, the normal operation is resumed and the ignition switch is turned from OFF to ON.

OPERATED PORTION

T2

Seat sliding

Approx. 0.1 sec.

Seat reclining

Same as above

Seat lifting (Front)

Same as above

Seat lifting (Rear)

Same as above

Pedal adjust

Same as above

Priority

Function

Priority

Function

1

Seat sliding, (door mirror LH/RH)*

4

Seat lifter-FR

2

Pedal

5

Seat lifter-RR

3

Seat  reclining

CONSULT-III

display

Timing

*1

Item

Reference page

Current mal-

function

Previous mal-

function

CAN COMM CIRCUIT
[U1000]

0

1-39

CAN communication

ADP-27

SEAT SLIDE
[B2112]

0

1-39

Seat slide motor output

ADP-28

SEAT RECLINING
[B2113]

0

1-39

Seat reclining motor output

ADP-29

SEAT LIFTER FRONT
[B2114]

0

1-39

Seat lifting motor front output

ADP-32

SEAT LIFTER REAR
[B2115]

0

1-39

Seat lifting motor rear output

ADP-32

ADJ PEDAL MOTOR
[B2117]

0

1-39

Pedal adjusting motor output

ADP-32

ADJ PEDAL SENSOR
[B2120]

0

1-39

 Pedal adjusting sensor input

ADP-32

DETENT SW
[B2126]

0

1-39

Park position switch condition

ADP-36

UART COMM
[B2128]

0

1-39

UART communication

ADP-38

ADP-114

< ECU DIAGNOSIS >

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

AUTOMATIC DRIVE POSITIONER CONTROL UNIT

Reference Value

INFOID:0000000001711101

TERMINAL LAYOUT

PHYSICAL VALUES

JMJIA0199ZZ

Terminal No.

Wire

color

Description

Condition

Voltage (V)

(Approx.)

+

-

Signal name

Input/

Out-

put

2

Ground

L

Changeover switch RH
signal

Input

Changeover
switch position

RH

0

Neutral or
LH

5

3

Ground

SB

Mirror switch up signal

Input

Mirror switch

Operated
(up)

0

Other than
above

5

4

Ground

V

Mirror switch left signal

Input

Mirror switch

Operated
(left)

0

Other than
above

5

5

Ground

R

Door mirror sensor (RH)
up/down signal

Input

Door mirror RH
position

Peak

3.4

Valley

0.6

6

Ground

L

Door mirror sensor (LH)
up/down signal

Input

Door mirror LH
position

Peak

3.4

Valley

0.6

8

Ground

O

Pedal sensor input sig-
nal

Input

Pedal sensor

Forward

0.5

Backward

4.5

9

Ground

LG

Memory switch 1 signal

Input

Memory switch 1

Push

0

Other than
above

5

10

Ground

SB

UART LINE (TX)

Out-

put

Ignition switch ON

12

Ground

W

Memory indictor 1 signal

Out-

put

Memory indictor
1

Illuminate

0

Other than
above

Battery voltage

PIIA4813E
