Nissan Pathfinder. Manual - part 850
CHASSIS AND BODY MAINTENANCE
MA-39
< PERIODIC MAINTENANCE >
C
D
E
F
G
H
I
J
K
L
M
B
MA
N
O
A
TIRE ROTATION
• Follow the maintenance schedule for tire rotation service intervals.
Refer to
MA-9, "FOR USA AND CANADA : Introduction of Periodic
(United States and Canada) or
(Mexico).
• When installing the wheel, tighten wheel nuts to the specified
torque.
CAUTION:
• Do not include the spare tire when rotating the tires.
• When installing wheels, tighten them diagonally by dividing
the work two to three times in order to prevent the wheels
from developing any distortion.
• Be careful not to tighten wheel nut at torque exceeding the
criteria for preventing strain of disc rotor.
• Use NISSAN genuine wheel nuts for aluminum wheels.
• Perform the ID registration after tire rotation. Refer to
BRAKE FLUID LEVEL AND LEAKS
BRAKE FLUID LEVEL AND LEAKS : Inspection
INFOID:0000000009174200
BRAKE FLUID LEVEL
• Make sure that the brake fluid level in the reservoir sub tank is
between the MAX and MIN lines.
• Visually check around the reservoir sub tank and reservoir tank for
brake fluid leakage.
• If the brake fluid level is excessively low, check the brake system
for leakage.
• If brake warning lamp remains illuminated after parking brake
pedal is released, check the brake system for brake fluid leakage.
BRAKE LINE
1. Check brake line (tubes and hoses) for cracks, deterioration or other damage. Replace any damaged
parts.
2. Check for brake fluid leakage by fully depressing brake pedal
while engine is running.
CAUTION:
If brake fluid leakage occurs around joints, retighten or
replace damaged parts as necessary.
BRAKE LINES AND CABLES
Wheel balance
Dynamic (At flange)
Static (At flange)
Maximum allowable im-
balance
Refer to
.
Wheel nut tightening
torque
: 113 N·m (12 kg-m, 83 ft-lb)
SMA829C
ALFIA0249ZZ
SBR389C
