DLN-114

< SYMPTOM DIAGNOSIS >

[REAR FINAL DRIVE: R145K1]

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

SYMPTOM DIAGNOSIS

NOISE, VIBRATION AND HARSHNESS (NVH) TROUBLESHOOTING

NVH Troubleshooting Chart

INFOID:0000000009177816

Use the chart below to find the cause of the symptom. If necessary, repair or replace these parts.

×: Applicable

Reference

—

—

—

—

DLN

-13

4,

 "Ad

jus

tm

en

t"

DLN

-1

1

5,

 "I

ns

pe

ct

io

n"

NVH of REA

R

 PROPELLER SHAF

T in this section

NVH in F

AX,

RAX, FSU and

R

S

U sections

NVH in W

T

 section

NVH in W

T

 section

NVH i

n F

AX and RAX

secti

on

NVH in B

R

 section

NVH in S

T

 section

Possible cause and SUSPECTED PARTS

G

ea

r to

ot

h ro

ug

h

Ge

ar co

nt

act

 im

pro

p

er

To

o

th su

rfac

es

 wo

rn

Ba

ck

la

sh

 in

co

rrec

t

Com

pani

on

 fl

an

ge

 ex

ce

ss

iv

e

run

ou

t

Ge

ar oi

l im

pro

p

er

PROPELLER S

H

AFT

AXLE AND S

U

S

PENSION

TI

RE

ROAD WHEE

L

DRIVE SHAFT

BRAKE

STE

E

RING

Symptom

Noise

×

×

×

×

×

×

×

×

×

×

×

×

×

REAR DIFFERENTIAL GEAR OIL

DLN-115

< PERIODIC MAINTENANCE >

[REAR FINAL DRIVE: R145K1]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

PERIODIC MAINTENANCE

REAR DIFFERENTIAL GEAR OIL

Inspection

INFOID:0000000009177817

OIL LEAKS

Check that oil is not leaking from final drive assembly or around it.

OIL LEVEL

CAUTION:

Do not start engine while checking oil level.
1. Remove and discard filler plug (1).

CAUTION:

Do not reuse filler plug.

2. Oil level should be level with the bottom of filler plug hole. Add

oil if necessary. Refer to

MA-15, "FOR USA AND CANADA :

Fluids and Lubricants"

 (United States and Canada) or

MA-16,

"FOR MEXICO : Fluids and Lubricants"

 (Mexico).

3. Install filler plug (1) and tighten to specified torque. Refer to

DLN-131, "Exploded View"

.

Draining

INFOID:0000000009177818

CAUTION:

Do not start engine while checking oil level.
1. Remove and discard drain plug (1), and drain gear oil.

CAUTION:

Do not reuse drain plug.

2. Install drain plug (1) and tighten to specified torque. Refer to

DLN-131, "Exploded View"

.

Refilling

INFOID:0000000009177819

CAUTION:

Do not start engine while checking oil level.
1. Remove and discard filler plug (1).

CAUTION:

Do not reuse filler plug.

2. Fill with new oil to the specified level near the filler plug hole.

: Front

ALDIA0275ZZ

: Front

ALDIA0277ZZ

: Front

ALDIA0275ZZ

DLN-116

< PERIODIC MAINTENANCE >

[REAR FINAL DRIVE: R145K1]

REAR DIFFERENTIAL GEAR OIL

3. Install filler plug (1) and tighten to specified torque. Refer to

DLN-131, "Exploded View"

.

Oil grade and viscosity : Refer to

MA-15, "FOR USA

AND CANADA : Fluids and Lu-
bricants"

 (United States and

Canada) or

MA-16, "FOR MEXI-

CO : Fluids and Lubricants"



(Mexico).

Oil capacity

: Refer to

DLN-136, "General

Specification"

.

TORSIONAL DAMPER

DLN-117

< REMOVAL AND INSTALLATION >

[REAR FINAL DRIVE: R145K1]

C

E

F

G

H

I

J

K

L

M

A

B

DLN

N

O

P

REMOVAL AND INSTALLATION

TORSIONAL DAMPER

Exploded View

INFOID:0000000009177820

Removal and Installation

INFOID:0000000009177821

REMOVAL

1. Remove rear propeller shaft from the torsional damper, and support the end of the propeller shaft. Refer to

DLN-103, "Exploded View"

.

2. Remove torsional damper lock nuts (

), using suitable tool.

3. Remove torsional damper.

INSTALLATION

1. Install torsional damper. (When torsional damper has been reused.)

CAUTION:

Clean the mounting surface.

2. Install torsional damper. (When torsional damper has been replaced.)

Degrease the mounting surface of electric controlled coupling, according to the following instruction.

1.

Final drive assembly

2.

Torsional damper

: Vehicle front

: Always replace after every disassembly.

: N·m (kg-m, ft-lb)

JSDIA3029GB

: Front

ALDIA0283ZZ
