DISPLAY UNIT

AV-83

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO WITHOUT BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

19

(B)

Ground RGB synchronizing signal

Input

Ignition

switch

ON

—

20

(R)

Ground

Vertical synchronizing (VP)
signal

Output

Ignition

switch

On

—

21

—

Shield

—

—

—

—

22

(B)

Ground

Communication signal
(DISP

→CONT)

Output

Ignition

switch

ON

When adjusting display
brightness.

23

—

Shield

—

—

—

—

Terminal

(Wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIB3603E

SKIB3598E

PKIB5039J

AV-84

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO WITHOUT BOSE]

SATELLITE RADIO TUNER

SATELLITE RADIO TUNER

Reference Value

INFOID:0000000009174428

PHYSICAL VALUES

AWNIA2563ZZ

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

22

(B)

21

(W)

Satellite radio sound signal
LH

Output

Ignition

switch

ON

When satellite radio
mode is selected

24

(G)

23

(R)

Satellite radio sound signal
RH

Output

Ignition

switch

ON

When satellite radio
mode is selected

25

—

Shield

—

—

—

—

26

—

Shield (DATA GND)

—

—

—

—

28

(W)

Ground

Request signal
(SAT

→CONT)

Output

Ignition

switch

ON

When satellite radio
mode is selected

29

(R)

Ground

Communication signal
(SAT

→CONT)

Output

Ignition

switch

ON

When satellite radio
mode is selected

SKIB3609E

SKIB3609E

SKIA9299J

SKIA9300J

AV

SATELLITE RADIO TUNER

AV-85

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO WITHOUT BOSE]

C

D

E

F

G

H

I

J

K

L

M

B

A

O

P

30

(B)

Ground

Communication signal
(CONT

→SAT)

Input

Ignition

switch

ON

When satellite radio
mode is selected

32

(SB)

Ground

Battery power supply

Input

Ignition

switch

OFF

—

Battery voltage

35

(GR)

Ground

Ground

—

Ignition

switch

ON

—

0V

36

(BG)

Ground

ACC power supply

Input

Ignition

switch

ACC

—

Battery voltage

37

(B)

—

Satellite antenna

—

—

—

—

Terminal

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/

Output

SKIA9301J

AV-86

< ECU DIAGNOSIS INFORMATION >

[MID AUDIO WITHOUT BOSE]

BLUETOOTH® CONTROL UNIT

BLUETOOTH® CONTROL UNIT

Reference Value

INFOID:0000000009174429

TERMINAL LAYOUT

PHYSICAL VALUES

AWNIA2564ZZ

Terminal

(wire color)

Description

Condition

Reference value

(Approx.)

+

–

Signal name

Input/out-

put

1

 (Y)

Ground

Battery power

Input

–

–

Battery voltage

2

(R)

Ground

ACC power

Input

Ignition

switch

ACC/ON

–

Battery voltage

3

(P)

Ground

 IGN power

Input

Ignition

switch

ON/

START

–

Battery voltage

4

(B)

Ground

Ground

–

Ignition

switch ON

–

0V

5 –

Shield

–

–

–

—

7

 (B)

8 MIC

in

signal

Input

–

–

–

9

(W)

10

(B)

Audio out

Output

Ignition

switch

ACC/ON

Bluetooth

®

 control

unit sends audio sig-

nal

20

(B)

Ground

Ground

–

Ignition

switch ON

–

0V

22

(B)

Ground

Ground

–

Ignition

switch ON

–

0V

24

(B)

Ground

Ground

–

Ignition

switch ON

–

0V

27

(B)

Ground

Ground

–

Ignition

switch ON

–

0V

SKIB3609E
