Mitsubishi L200 (2018 year). Instruction - part 25





Rear

1,840 kg

Maximum towable weight

With brake

3,000 kg

Without brake

750 kg

Maximum trailer-nose weight

120 kg

Maximum gross combination weight

5,820 kg

Maximum permissible weight of the coupling device

34 kg

Seating capacity

2 persons

NOTE

l

Trailer specifications indicate the manufacturer’s recommendation.

Club cab

Item

Vehicles without wide fender

Vehicles with wide fender

LHD

RHD

Kerb weight

Without optional parts

1,820 kg

1,805 kg

1,840 kg

With full optional parts

1,910 kg

1,895 kg

1,930 kg

Maximum gross vehicle weight

2,850 kg

Maximum axle weight

Front

1,260 kg

Rear

1,840 kg

Maximum towable weight

With brake

3,000 kg

Without brake

750 kg

Maximum trailer-nose weight

120 kg

*

: Vehicles equipped with rear seatless option

Vehicle weight

11-11

OKTE18E1

Specifications

11

Item

Vehicles without wide fender

Vehicles with wide fender

LHD

RHD

Maximum gross combination weight

5,820 kg

Maximum permissible weight of the coupling device

34 kg

Seating capacity

4 persons, 2 persons

*

*

: Vehicles equipped with rear seatless option

NOTE

l

Trailer specifications indicate the manufacturer’s recommendation.

Double cab

Item

2WD Hi-

Rider

4WD

M/T

A/T

LHD

RHD

LHD

RHD

Vehicles

without wide

fender

Vehicles

with wide

fender

Vehicles

without wide

fender

Vehicles

with wide

fender

Kerb weight

Without optional parts

1,765 kg

1,870 kg,

1,840 kg*

*1

1,875 kg,

1,855 kg

*1

1,860 kg,

1,855 kg

*2

1,870 kg

1,875 kg,

1,855 kg

*1

1,860 kg

With full optional parts

1,850 kg

1,960 kg,

1,915 kg

*1

1,955 kg,

1,950 kg

*1*2

1,950 kg,

1,960 kg

*2

1,960 kg

1,955 kg

1,950 kg

*1

: Vehicles for Russia and Ukraine

*2

: Vehicles with the Auto Stop & Go (AS&G) system

*3

: Except for vehicles for Russia and Ukraine

Vehicle weight

11-12

OKTE18E1

Specifications

11

Item

2WD Hi-

Rider

4WD

M/T

A/T

LHD

RHD

LHD

RHD

Vehicles

without wide

fender

Vehicles

with wide

fender

Vehicles

without wide

fender

Vehicles

with wide

fender

Maximum gross vehicle weight

2,800 kg

2,900 kg,

2,850 kg

*1

2,905 kg,

2,850 kg

*1

2,905 kg,

2,900 kg

*2

2,900 kg

2,910 kg,

2,850 kg

*1

2,910 kg

Maximum axle weight

Front

1,260 kg

Rear

1,840 kg

Maximum towable weight With brake

2,700 kg

3,100 kg

Without
brake

750 kg

Maximum trailer-nose weight

110 kg

125 kg

Maximum gross combination weight

5,450 kg

5,950 kg, 5,900 kg

*1

5,950 kg

5,950 kg,

5,900 kg

*1

5,950 kg

Maximum  permissible  weight  of  the
coupling device

34 kg

Maximum roof load

80 kg

*3

Seating capacity

5 persons

*1

: Vehicles for Russia and Ukraine

*2

: Vehicles with the Auto Stop & Go (AS&G) system

*3

: Except for vehicles for Russia and Ukraine

Vehicle weight

11-13

OKTE18E1

Specifications

11

NOTE

l

Trailer specifications indicate the manufacturer’s recommendation.



Engine specifications

E01100604221

Item

Specification

Engine models
No. of cylinders

Total displacement
Bore
Stroke

Camshaft
Mixture preparation

4N15

4 in line

2,442 cc

86.0 mm

105.1 mm



Double overhead

Electronic direct injection

Maximum output (EEC net)

113 kW/3,500 r/min, 133 kW/3,500 r/min

*

Maximum torque (EEC net)

380 N•m/1,500~2,500 r/min, 430 N•m/2,500 r/min

*

*

: Vehicles with high power engine



Engine specifications

11-14

OKTE18E1

Specifications

11

Electrical system

E01100804425

Item

Except for vehicles with the Auto Stop & Go (AS&G) system

Vehicles with the Auto Stop

& Go (AS&G) system

Except for vehicles for Russia and Uk-

raine

Vehicles for Russia and

Ukraine

Voltage

12 V

Battery

Type (JIS)

95D31L, 115D31L

*

115D31L

T-105

Capacity (5HR)

64 Ah, 72 Ah

*

72 Ah

73 Ah

Alternator capacity

95 A, 130 A

*

130 A

95 A, 130 A

*

*

: Optional equipment

NOTE

l

Vehicles equipped with the Auto Stop & Go (AS&G) system have a dedicated AS&G battery type.
The use of a different battery could cause the battery to run down quickly or the AS&G system not to operate normally.
Please contact a MITSUBISHI MOTORS Authorized Service Point when replacing the battery.



Tyres and wheels

E01100904703

Tyre

205R16C 8PR 110/108R

245/70R16 111S RF

245/65R17 111S

Wheel

Size

16x6J, 16x6JJ

16x7J, 16x7JJ

17x7 1/2J

Offset

38 mm

Electrical system

11-15

OKTE18E1

Specifications

11

NOTE

l

Contact a MITSUBISHI MOTORS Authorized Service Point for details on the combination used on your vehicle.



Fuel consumption

E01101102030

Item

Combined

Urban condi-

tions

Extra-urban

conditions

CO

2

 (g/km)

Fuel consump-

tion (L/100 km)

Fuel consump-

tion

(L/100 km)

Fuel consump-

tion (L/100 km)

2WD Hi-Rider

With AS&G

6M/T

177

6.7

8.0

6.0

Without AS&G

5A/T

192

7.3

8.9

6.4

4WD

With AS&G

6M/T

180

6.9

8.2

6.1

Without AS&G

6M/T

186, 188

*1

, 191

*2

7.1, 7.1

*1

, 7.2

*2

8.8, 8.7

*1

, 8.8

*2

6.1, 6.2

*1

, 6.3

*2

5A/T

196, 197

*1

, 201

*2

7.5, 7.5

*1

, 7.6

*2

9.1, 8.9

*1

, 9.0

*2

6.6, 6.7

*1

, 6.8

*2

*1

: Vehicles for RUSSIA

*2

: Vehicles for UKRAINE

AS&G: Auto Stop & Go (AS&G) system

Fuel consumption

11-16

OKTE18E1

Specifications

11

NOTE

l

The results given do not express or imply any guarantee of the fuel consumption of the particular vehicle.
The vehicle itself has not been tested and there are inevitably differences between individual vehicles of the same model. In addition, this vehicle may incor-
porate particular modifications. Furthermore, the driver’s style and road and traffic conditions, as well as the extent to which the vehicle has been driven and
the standard of maintenance, will all affect its fuel consumption.



Capacity

E01101307200

Capacity

11-17

OKTE18E1

Specifications

11

No.

Item

Quantity

Lubricants

1

Engine coolant
[Includes 0.65 litre in the reserve tank]

7.7 litres

MITSUBISHI MOTORS GENUINE SUPER LONG LIFE

COOLANT PREMIUM or equivalent

*1

2

Brake fluid

As required

Brake fluid DOT3 or DOT4

3

Clutch fluid

As required

Brake fluid DOT3 or DOT4

4

Engine oil

Oil pan

8.0 litres

Refer to page 10-05.

Oil filter

0.3 litre

Oil cooler

0.1 litre

5

Power steering fluid

As required

MITSUBISHI MOTORS GENUINE PSF (Power Steering

Fluid)

6

Washer fluid

4.2 litres

—

7

Automatic transmission fluid

10.9 litres

MITSUBISHI MOTORS GENUINE ATF-PA

*1

: Similar high quality ethylene glycol based non-silicate, non-amine, non-nitrate and non-borate coolant with long life hybrid organic acid

technology

CAUTION

l

For the Automatic transmission fluid, use only the MITSUBISHI MOTORS GENUINE ATF. Use of a different fluid could damage the transmission.

No.

Item

Quantity

Lubricants

8

Manual transmission oil

2.2 litres

MITSUBISHI MOTORS GENUINE NEW MULTI GEAR

OIL ECO API GL-4, SAE 75W-80

9

Transfer oil

Super select 4WD II

1.34 litres

MITSUBISHI MOTORS GENUINE NEW MULTI GEAR

OIL ECO API GL-4, SAE 75W-80

Easy select 4WD

1.15 litres

*1

: Contains fluorinated greenhouse gases

Capacity

11-18

OKTE18E1

Specifications

11

No.

Item

Quantity

Lubricants

10

Differential oil

2WD

2.3 litres

MITSUBISHI MOTORS GENUINE Super Hypoid Gear

Oil ECOLOGY API GL-5 SAE 80

4WD

Front

1.2 litres

MITSUBISHI MOTORS GENUINE Super Hypoid Gear

Oil ECOLOGY API GL-5 SAE 80

Rear

2.3 litres

MITSUBISHI MOTORS GENUINE Super Hypoid Gear

Oil ECOLOGY API GL-5 SAE 80

11

Refrigerant (Air condi-
tioning)

Amount

0.52 kg

HFC-134a

*1

CO

2

 equivalent

0.743 t

GWP

1,430

*1

: Contains fluorinated greenhouse gases



Capacity

11-19

OKTE18E1

Specifications

11
