RELAY

TSB Revision

COMPONENT LOCATIONS

70-3

AC707342

A

AE

CVT control relay

Condenser fan relay

Starter relay

Fog light relay

Relay box

Horn relay

<2.4L Engine>

AC702518AC

A

A/C compressor relay

Fog light relay

Horn relay

MFI relay

Injector relay

Daytime running
light relay <Vehicles
with discharge type
headlight>

Throttle actuator
control motor relay

<3.0L Engine>

AC702519

AC702519AD

A

Fan control relay

Condenser fan relay

Radiator fan relay

Headlight relay (High)

Headlight relay (Low)

Starter relay

A/T control relay

Theft-alarm horn relay
<Vehicles without
theft-alarm sensor>

<3.0L Engine>

AC702540

B

Heated seat relay

Rear window defogger
relay

ETACS-ECU

Blower relay

AB

AC900254

AD

Brake pedal

Stoplight relay

C

CONTROL UNIT

TSB Revision

COMPONENT LOCATIONS

70-4

CONTROL UNIT

M1701000701051

Name

Symbol

Name

Symbol

A/C-ECU

N

Headlight control unit <Vehicles with
discharge type headlight>

C

ABS-ECU

A

KOS-ECU

K

ASC-ECU

A

Multivision display

G

AWC-ECU <S-AWC>

I

Occupant classification-ECU

P

AWD-ECU <Electronic controlled
AWD>

I

Power window main switch
(incorporating CPU)

Q

CAN box unit

G

Receiver antenna module <Vehicles
with KOS>

J

Column switch (incorporating
column-ECU)

D

SRS-ECU

L

Combination meter (incorporating CPU) E

Sunroof motor assembly (incorporating
CPU)

O

Engine control module

B

Transaxle control module

I

ETACS-ECU

H

USB box

M

Hands free module

M

Wireless control module <Vehicles
without KOS>

J

AC900431

A

B

C

D

E

G

H

I

J

K

L

N

M

AC

*

CONTROL UNIT

TSB Revision

COMPONENT LOCATIONS

70-5

NOTE: The * symbols indicate equipment at both sides.

AC900356

AC900356AH

P

O

Q

AC702536AC

A

ABS-ECU or
ASC-ECU

AC702514AB

Engine
control
module

B

AC900255

AD

Headlight
control unit

Headlight
assembly

C

<Vehicles with discharge type
headlight>

AC702557AB

Column switch
(incorporating
column-ECU)

D

AC702523AB

Combination meter
(incorporating CPU)

E

AC702555

AC702555AC

Multivision
display

CAN box unit

G

CONTROL UNIT

TSB Revision

COMPONENT LOCATIONS

70-6

AC702539

AC702539 AC

ETACS-ECU

H

AC702533

AD

Transaxle
control module

I

ETACS-ECU

AWD-ECU

<Electronic controlled AWD>

AC900509

I

AE

AWC-ECU

ETACS-
ECU

Transaxle
control module

<S-AWC>

AC702551

AC702551AC

Ignition switch

Wireless control module
<Vehicles without KOS>
receiver antenna module
<Vehicles with KOS>

J

AC702550

AC702550AC

KOS-ECU

Steering
shaft

K

AC702585

AC702585AC

SRS-ECU

L
