HANDS FREE MODULE

TSB Revision

CHASSIS ELECTRICAL

54A-633

REMOVAL AND INSTALLATION

M1549101300162

<USB CABLE>

AC809507AB

1

Removal steps

•

Rear floor console assembly (Refer
to GROUP 52A

− Rear Floor

Console Assembly

P.52A-8

.)

•

Center lower panel (Refer to
GROUP 52A

− Instrument Panel

Assembly

P.52A-2

.)

1.

USB cable

Removal steps (Continued)

HANDS FREE MODULE

TSB Revision

CHASSIS ELECTRICAL

54A-634

REMOVAL AND INSTALLATION

M1549100800164

<USB ADAPTER>

INSPECTION

STEERING WHEEL VOICE-CONTROL SWITCH
CONTINUITY CHECK

M1544401100391

.

Use an ohmmeter to measure the resistance value between the
terminal.

AC900459AB

1

1

A

A

Rear floor console

Section A – A

Claw

Claw

NOTE

       :Claw positions

Removal Steps

•

Rear floor console assembly (Refer
to GROUP 52A

− Rear Floor

Console assembly

P.52A-8

.)

1.

USB adapter

Switch position

Tester
connection

Measurement
value

No push

2

− 3

Approximately
74 k

Ω

"Speech" switch

Approximately
1.5 k

Ω

"Pick-up" switch

Approximately
3.3 k

Ω

"Hang-up" switch

Approximately
6.0 k

Ω

AC606271

“Speech" switch

“Pick-up" switch

“Hang-up" switch

AB

AC606272

ZC6016190000

HANDS FREE MODULE

TSB Revision

CHASSIS ELECTRICAL

54A-635

.

ILLUMINATION CHECK

Apply the battery voltage of steering wheel voice control switch
connector terminal No. 4 and 1, and check if the steering wheel
audio remote control switch illuminates.
NOTE: Make sure that the polarity is correct.

USB ADAPTER INSPECTION

M1549101100072

1. Remove the USB adapter. (Refer to

P.54A-634

)

2. Check that the continuity exists between the front side ter-

minals of USB adapter and rear side terminals of USB
adapter.

AC606272

ZC6016190000

AB

Front side
terminal

Rear side
terminal

Measurement
value

1

1

Continuity
exists (2

Ω or

less)

2

2

3

3

4

4

AC900440

AB

Front side

Rear side

1

2

3

4

4

3

2

1

USB BOX

TSB Revision

CHASSIS ELECTRICAL

54A-636

USB BOX

GENERAL INFORMATION

M1549100200087

The USB

*

 adapter transfers the music data from the iPod

® and USB memory to the radio and CD player or

the multivision display via the USB box, and the data can be played by the "USB mode".
NOTE:

*

:Universal serial bus

SPECIAL TOOLS

M1549100300017

AC900397

AC809503

USB adapter

AC

USB box

Tool

Tool number and
name

Supersession

Application

MB991223

a. MB991219
b. MB991220
c. MB991221
d. MB991222

Harness set

a. Check harness
b. LED harness
c. LED harness

adapter

d. Probe

General service tool
(jumper)

Continuity check and voltage
measurement at harness wire or
connector

a. For checking connector pin

contact pressure

b. For checking power supply

circuit

c. For checking power supply

circuit

d. For connecting a locally

sourced tester

MB992006
Extra fine probe

−

Continuity check and voltage
measurement at harness wire or
connector

MB991223

a

d

c

b

DO NOT USE

BA

MB992006
