HANDS FREE MODULE

TSB Revision

CHASSIS ELECTRICAL

54A-585

AC904648

Radio and CD player OFF

CH4

CH1

Rewind

Fast-forward

DISP

UNLOCK

3 seconds

HFM DIAG

H/W Ver.

S/W Ver.

CH4

CH4

CH4

CH4

CH4

CH3

CH3

CH3

CH3

CH3

HFM UPDATE

CODE_

CODEXXXX

UPDATE XX%

UPDATE FAIL

CODE WRONG

NO FILE

PAGE

NG

OK

3 seconds

PAGE

PAGE

3 seconds

PAGE

3 seconds
      or

PAGE

Code OK

Code NG

PAGE

AE

Microphone check
result

Part Number

Self-check Result

ECU
Malfunction

Abnormal
End

UPDATE
COMPLETE

3 seconds

Description in the
illustrations

Actual display

Condition

UNLOCK

UNLOCK

Four-digit password, which has been set by the security
function, will be erased.

HFM DIAG

HFM DIAG

Displayed when the diagnosis mode is being entered.

Result of microphone
check

MIC Short

Displayed when the line between the microphone and the
hands free module is short-circuited.

MIC Open

Displayed when the line between the microphone and the
hands free module is open-circuited.

MIC OK

Normal status (the line between the microphone and the
hands free module is not open/short-circuited)

Part number

PN XXXXXXXX

Eight-digit part number is displayed.

H/W Ver.

H/W XX

Two-digit hardware version is displayed.

HANDS FREE MODULE

TSB Revision

CHASSIS ELECTRICAL

54A-586

DIAGNOSIS MODE <VEHICLES WITH MMCS>

M1544404800021

As a diagnosis mode for the hands free module, ver-
sion information of the hands free module and diag-
nostic results of the hands free module and the
microphone unit can be displayed by the service
mode of the multivision display.

.

HOW TO INITIATE THE SERVICE MODE

Refer to MMCS - Service mode.

.

HOW TO TERMINATE THE SERVICE MODE

Refer to MMCS - Service mode.

HANDS FREE MODULE

NOTE:

.

•

While the hands free module is in diagnosis mode, connec-
tion with the Bluetooth

®

 device is shut down.

•

While the hands free module is in diagnosis mode, the
sound input to the microphone unit is output directly through
the speaker.

.

S/W Ver.

S/W XXXXXXX

Seven-digit software version is displayed.

Self-check result

HFM OK

Displayed when the hands free module is not defective.

HFM Error

Displayed when the hands free module is suspected to be
defective.
NOTE: Turn the ignition switch to the "OFF" position once
when "ERROR" is displayed. Enter the diagnosis mode by
turning the ignition switch to the "ON" position again. If the
self-check result shows "ERROR" again, the hands free
module is determined to be defective.

NO FILE

NO file

A USB device stores no data.

HFM UPDATE

HFM Update

Displayed when the hands free module update file is found, at
the transition to the hands free module update mode, in the
USB memory that is connected to the USB adapter.

CODE_

CODE_

Input four-digit code for update. Use the "CH" button when a
code is input.

CODE XXXX

Code XXXX

XXXX after Code shows the numbers from 1 to 6,
corresponding to the buttons "CH1" to "CH6".

CODE WRONG

Code wrong

The code, which has been input, is wrong.

UPDATING XX%

Updating XX%

Displayed when updating is carried out.

UPDATING
COMPLETE

Update complete

The updating mode is complete.

UPDATE FAIL

Update fail

Displayed when the update of the hands free module fails.

Description in the
illustrations

Actual display

Condition

HANDS FREE MODULE

TSB Revision

CHASSIS ELECTRICAL

54A-587

1. Select "hands free module" on "Service" screen.

2. "Hands Free Module" screen is displayed.

SPECIFICATION OF DISPLAY ITEM

Service

Vehicle Signal Check

Monitor Check

Camera Setting

Speaker Check

Network/Connect Line Check

Versions Indication

1/2

Sensor Check

Hands Free Module

Memory Initialization

Back

Next

Previous

CAN Communication Confirmation

AC903640

AB

Hands Free Module

VOL  25

S/W Update

Unlock

Back

Error Code

Parts No.

H/W version

S/W version

HFM Self Check

HFM MIC Check

NG

OK

XX

XX. YY.  ZZZ

XXXXXXXX

AC903643

AB

Displayed name

Detail

VOL

The volume of the sound input to the microphone unit and output
through the speaker while the hands free module is in diagnosis
mode. (The sound volume can be changed by operating the
multivision display.)

Parts No

The part number of the hands free module is displayed in 8 digits.

H/W version

The hardware version information of the hands free module is
displayed in 2 digits.

HANDS FREE MODULE

TSB Revision

CHASSIS ELECTRICAL

54A-588

DISPLAY BUTTON AND FUNCTION

.

SOFTWARE UPDATE (S/W Update)

The software of the hands free module can be updated.
NOTE:

.

•

"S/W Update" is displayed when an USB that contains files
to update the hands free module is connected.

•

When the software update cannot continue because of
improper removal of the USB during the update or of an
incorrect update code, the display returns to the "Hands
Free Module" screen. At this time, warning is not displayed.

S/W version

The software version information of the hands free module is
displayed in 7 digits.

HFM Self Check

The hands free module state is displayed.

• "OK": Normal (There is no abnormality in the hands free

module.)

• "NG": Abnormal (The hands free module may have a problem.)

NOTE: If "NG" is displayed, turn the ignition switch to the "OFF"
position once. Then, turn the ignition switch to the "ON" position,
and enter into the diagnosis mode. When the HFM Self Check
display is NG again, the hands free module is determined to be
defective.

HFM MIC Check

Displays the communication condition of the hands free module
and the microphone unit.

• "OK": Normal (There is no short circuit or open circuit in the line

between the microphone unit and the hands free module.)

• "NG (Short)": This message is displayed when the line between

the microphone unit and the hands free module is shorted.

• "NG (Open)": (This message is displayed when there is an open

circuit in the line between the microphone unit and the hands
free module.)

Display button

Detail

S/W Update

Execution button for software update of the hands free module
(Displayed only when the update is possible.)

Error Code

Error Code screen is displayed. (This button is displayed in gray
when "HFM Self Check" is "OK.")

Unlock

Forcibly unlocks the 4-digit passcode that was set by the security
function. (When the module is not locked by passcode, the "Unlock"
button is displayed in gray.)

Back

Returns to "Service" screen.
