SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-17

SEAT ASSEMBLY

FRONT SEAT ASSEMBLY

REMOVAL AND INSTALLATION

M1522001301864

CAUTION

To remove the front seat assembly of vehicle with side air bag, refer to GROUP 52B - Service Precau-
tions

P.52B-25

 and Curtain Air Bag Module

P.52B-453

.

AC701313

1

1

4

3

3

3

2

2

3

4

43 ± 8 N·m
32 ± 5 ft-lb

AC

43 ± 8 N·m
32 ± 5 ft-lb

43 ± 8 N·m
32 ± 5 ft-lb

43 ± 8 N·m
32 ± 5 ft-lb

43 ± 8 N·m
32 ± 5 ft-lb

43 ± 8 N·m
32 ± 5 ft-lb

Removal steps

1.

Headrest

2.

Front seat anchor cover

3.

Rear seat anchor cover

<<

A

>>

•

Wiring harness connectors

>>

A

<<

4.

Front seat assembly

Removal steps (Continued)

SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-18

REMOVAL SERVICE POINT

.

<<A>> WIRING HARNESS CONNECTOR DISCON-
NECTION

Disconnect the following wiring harness connectors:

INSTALLATION SERVICE POINT

.

>>A<< FRONT SEAT ASSEMBLY INSTALLATION

1. Confirm that both the seat slides are locked, and then

temporarily tighten all the bolts shown in the figure so that
no load is applied to the front seat cushion.

2. Tighten all the bolts to the specified torque.

Connector
number

Connector name

D-25 (2)

Power seat assembly connector
<vehicle with power seat>

D-26 (4

−

black)

Heated seat assembly connector
(LH) <vehicle with heated seat>

D-27 (4

−

gray)

Seat slide sensor connector

D-28 (4

−

black)

Seat belt switch connector (Driver’s
seat)

D-29 (2

−

yellow)

Side-airbag module (squib)
connector (LH) <vehicles with
side-airbag>

D-31 (2

−

yellow)

Side-airbag module (squib)
connector (RH) <vehicles with
side-airbag>

D-32 (2

−

black)

Seat belt switch connector
(Passenger’s seat)

D-33 (4

−

black)

Heated seat assembly connector
(RH) <vehicle with heated seat>

AC701314

AB

D-31

D-32

D-33

D-25

D-26

D-27

D-28

D-29

AC507247AB

SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-19

INSPECTION

M1522001400200

Connect the + terminal of the battery to the power seat connec-
tor terminal No. 2 and the

− terminal to terminal No. 1, and

check that the power seat works normally.

DISASSEMBLY AND ASSEMBLY

M1522001501909

(DRIVER'S SEAT)

AC507447AB

AC803390

9

10

11

13

3

4

5

6

7

8

1

2

AC

14

15

17

16

12

43 ± 8 N·m
32 ± 5 ft-lb

43 ± 8 N·m
32 ± 5 ft-lb

43 ± 8 N·m
32 ± 5 ft-lb

Disassembly steps

1.

Hinge cover outer

2.

Inner seat belt

3.

Heated seat switch cover <vehicle
with heated seat>

4.

Heated seat switch <vehicle with
heated seat>

Disassembly steps (Continued)

SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-20

<PASSENGER'S SEAT>

5.

Under cover

6.

Side shield cover

7.

Reclining adjuster lever knob
<vehicle with power seat>

8.

Reclining adjuster lever knob
<vehicle with power seat>

9.

Seat back assembly

<<

A

>>

10. Headrest guide
11. Seat back cover
12. Seat back pad
13. Hinge cover inner
14. Seat cushion cover
15. Seat cushion pad
16. Wiring harness clamp

<<

B

>>

17. Seat cushion frame assembly

Disassembly steps (Continued)

AC803391AB

9

10

11

12

3

4

5

6

7

14

1

2

13

16

15

8

43 ± 8 N·m
32 ± 5 ft-lb

43 ± 8 N·m
32 ± 5 ft-lb

Disassembly steps

1.

Side shield cover

2.

Reclining lever

3.

Slide adjuster side cover

4.

Hinge cover outer

Disassembly steps (Continued)
