INVECS-II 4A/T <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-62

INVECS-II 4A/T <2.4L ENGINE> (CONTINUED)

JUNCTION
BLOCK

 (FUSE     )

23

 (FUSE     )

 (FUSE     )

20

22

RHEOSTAT

RHEOSTAT CIRCUIT

COMBINATION METER

JOINT
CONNECTOR (2)

JOINT
CONNECTOR (1)

INVECS-II 4A/T <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-63

JOINT
CONNECTOR (3)

DATA LINK
CONNECTOR

ABS-ECU

POWERTRAIN
CONTROL
MODULE

NOTE

WITHOUT ELECTRONIC BRAKE-FORCE DISTRIBUTION (EBD)
AND ANTI-LOCK BRAKING SYSTEM (ABS)
WITH ELECTRONIC BRAKE-FORCE DISTRIBUTION (EBD)
AND ANTI-LOCK BRAKING SYSTEM (ABS)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE
BR :BROWN     O : ORANGE     GR : GRAY     R : RED     W : WHITE
SB : SKY BLUE     P : PINK      Y : YELLOW     V : VIOLET

MULTI-CENTER DISPLAY UNIT

INVECS-II 4A/T <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-64

INVECS-II 4A/T <2.4L ENGINE> (CONTINUED)

RELAY BOX

 (FUSE     )

9

MFI SYSTEM

MFI
RELAY

MFI SYSTEM

POWER
SUPPLY

SOLENOID
VALVE POWER
SUPPLY

CRANKSHAFT
POSITION
SENSOR

MFI SYSTEM

BATTERY

RELAY
BOX

A/T
CONTROL
RELAY

(FUSE     )

22

JOINT
CONNECTOR (1)

INVECS-II 4A/T <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-65

POWERTRAIN CONTROL MODULE

A/T CONTROL
SOLENOID
VALVE ASSEMBLY

UNDERDRIVE
SOLENOID
VALVE
SECOND
SOLENOID
VALVE
OVERDRIVE
SOLENOID
VALVE
TORQUE
CONVERTER
CLUTCH
CONTROL
SOLENOID
VALVE
LOW AND
REVERSE
SOLENOID
VALVE

NOTE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW
SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET

TRANSMISSION
FLUID
TEMPERATURE
SENSOR
