AIR BAG MODULE AND SEAT BELT PRE-TENSIONER DISPOSAL PROCEDURES TSB Revision SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-394 4. Execute the following steps to disconnect D-22 or D-33 seat belt pre-tensioner connector (two-pin) from the harness side NOTE: If the seat belt pre-tensioner connector is discon- (1) Use a flat-tip screwdriver to unlock the harness side connector (two-pin, black) locking button by withdrawing (2) Disconnect the D-22 or D-33 harness side connector. 5. Connect deployment wires, each 6 meters (20 feet) or longer, to the two leads of special tool pre-tensioner adapter 6. Connect the D-22 or D-33 seat belt pre-tensioner two-pin connector (black) to special tool pre-tensioner adapter WARNING If the glass is scratched, seat belt pre-tensioner oper- 7. To suppress the operation sound as much as possible completely close all door windows, close the doors and put AC200976 D-22 OR D-33 AN D-22 OR D-33 AC103556 D-22 OR D-33 LOCKING BUTTON FLAT-TIP SCREW D-22 OR D-33 AR AC103480 CONNECTION DEPLOYMENT WIRES MR991885 INSULATOR TAPE 6 m (20 ft) AC AC103658 AF D-22 OR D-33 MB991885 DEPLOYMENT ACX01308AC DEPLOYMENT WIRE COVER |
