AIR BAG MODULE AND SEAT BELT PRE-TENSIONER DISPOSAL PROCEDURES TSB Revision SUPPLEMENTAL RESTRAINT SYSTEM (SRS) 52B-390 DEPLOYMENT INSIDE THE VEHICLE (WHEN 1. Move the vehicle to an isolated spot. DANGER Wait at least 60 seconds after disconnecting the bat- ). WARNING Battery posts, terminals and related accessories con- 2. Disconnect the negative ( −) and positive (+) battery cables from the battery terminals, and then remove the battery from 3. Remove the glove box assembly (Refer to GROUP 52A, Instrument Panel 4. Disconnect the C-110 air bag module (front passenger's side) connector (four-pin, yellow) from the harness side NOTE: If the C-110 air bag module connector is discon- 5. Obtain two suitable wires, which are 6 meters (20 feet) or longer, as deployment wires. Then connect the wires at one NOTE: This prevents the air bag from unintentional deploy- CAUTION Never fail to do Step 6 in order to prevent accidental static electricity. 7. Cut the instrument panel wiring harness (four-pin, yellow) shown in the figure, while the C-110 air bag module NOTE: The disconnection location should be sufficiently 8. Individually connect a harness to the four disconnected harnesses, cover the connection areas with insulation tape, 9. Connect the C-110 harness side connector connected with the expansion harness to the C-110 air bag module AC307137AB C-110 AIR BAG MODULE FRONT DECK AC100450AD DEPLOYMENT WIRES CONNECTION 6m (20 ft) OR LONGER AC307138 DEPLOYMENT AB INSULATOR C-110 AIR BAG MODULE C-110 HARNESS SIDE CONNECTION |
