BACKUP LIGHT <TC-SST>

TSB Revision

CIRCUIT DIAGRAMS

90-137

HEATED
SEAT

FUSIBLE
LINK

34

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

DATA LINK
CONNECTOR

JOINT
CONNECTOR
(4)

BACKUP
LIGHT
(LH)

BACKUP
LIGHT
(RH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

STOPLIGHT

TSB Revision

CIRCUIT DIAGRAMS

90-138

STOPLIGHT

M1901003002939

FUSIBLE
LINK

34

STOPLIGHT
SWITCH

JOINT
CONNECTOR
(4)

REAR
COMBINATION
LIGHT
(STOPLIGHT: LH)

REAR
COMBINATION
LIGHT
(STOPLIGHT: RH)

ETACS-
ECU

HIGH-MOUNTED
STOPLIGHT

·ABS, ASC, ACD, AYC AND S-AWC
·AUDIO SYSTEM
·MFI SYSTEM
·SHIFT LOCK MECHANISM

HEATED
SEAT

HORN

TSB Revision

CIRCUIT DIAGRAMS

90-139

HORN

M1901003302134

FUSIBLE
LINK

36

HORN
RELAY

HORN
(LOW)

HORN
(HIGH)

HORN
SWITCH

CLOCK
SPRING

ETACS-
ECU

RELAY BOX

ENGINE
COMPARTMENT

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

METER AND GAUGE <M/T>

TSB Revision

CIRCUIT DIAGRAMS

90-140

METER AND GAUGE <M/T>

M1901003503722

DATA LINK
CONNECTOR

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ETACS-
ECU

IG1
RELAY

FRONT SIDE

FUSIBLE
LINK

36

IGNITION
SWITCH (IG1)

FUSIBLE
LINK

34

RELAY BOX

ENGINE
COMPARTMENT

JOINT
CONNECTOR
(3)

·AIR CONDITIONING SYSTEM
·CENTRAL DOOR
 LOCKING SYSTEM
·DAYTIME RUNNING
 LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
 TONE ALARM
 <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATION
 SYSTEM (KOS)
·TAILLIGHT,
 POSITION LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
 MONITORING
 SYSTEM (TPMS)
·TRUNK LID OPENER
·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·WINDSHIELD
 WIPER AND WASHER

HEATED
SEAT
