CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-147

KEYLESS
ENTRY
RECEIVER

ETACS-
ECU

CONTROL
CIRCUIT

KEYLESS ENTRY TRANSMITTER

DOOR LOCK
ACTUATOR
(REAR : LH)

DOOR LOCK
ACTUATOR
(FRONT : LH)

DOOR LOCK
ACTUATOR
(REAR : RH)

·HEADLAMP
·REAR FOG LAMP
·TAIL LAMP, POSITION LAMP,
 LICENCE PLATE LAMP
 AND LIGHTING
 MONITOR BUZZER
·TURN-SIGNAL LAMP
 AND HAZARD
 WARNING LAMP
·WINDSHIELD WIPER
 AND WASHER

NOTE

:

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-148

CENTRAL DOOR LOCKING SYSTEM <RH drive vehicles> (CONTINUED)

BATTERY

RELAY
BOX

ETACS-ECU

TURN-SIGNAL
LAMP RELAY : LH

TURN-SIGNAL
LAMP RELAY : RH



SIDE
TURN-SIGNAL
LAMP (LH)

HEADLAMP
ASSEMBLY
(TURN : LH)

REAR
COMBI-
NATION
LAMP
(TURN
 : LH)

J/B SIDE

SIDE
TURN-SIGNAL
LAMP (RH)

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-149

HEADLAMP
ASSEMBLY
(TURN : RH)

REAR
COMBINATION
LAMP
(TURN : RH)

COMBINATION
METER

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue    W : White
Y : Yellow     SB : Sky blue     BR : Brown    O : Orange
GR : Grey     R : Red     P : Pink     V : Violet    PU : Purple

CENTRAL DOOR LOCKING SYSTEM

CIRCUIT DIAGRAMS

90-150

CENTRAL DOOR LOCKING SYSTEM <RH drive vehicles> (CONTINUED)

FRONT
ROOM
LAMP

REAR
ROOM
LAMP

ETACS-
ECU

KEY
REMINDER
SWITCH

WHEN KEY
IS REMOVED

FRONT
DOOR
SWITCH
(RH)

REAR
DOOR
SWITCH
(RH)
