Mitsubishi Lancer Evolution IX. Manual - part 12

POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-27

·ROOM LAMP,
 LUGGAGE
 COMPARTMENT
 LAMP, IGNITION
 KEY CYLINDER
 ILLUMINATION
 LAMP AND DOOR
 AJAR WARNING
 LAMP
·WINDSHIELD
 WIPER AND
 WASHER

REMOTE
CONTROLLED
MIRROR

CIGARETTE
LIGHTER

WINDSHIELD
WIPER AND
WASHER

·ACD AND AYC
·ANTI-SKID
 BRAKING
 SYSTEM (ABS)

·ACD AND AYC
·ANTI-SKID BRAKING
 SYSTEM (ABS)
·AUTOMATIC AIR
 CONDITIONER
·COOLING SYSTEM
·HEADLAMP
·HEADLAMP LEVELLING
 SYSTEM
·REAR FOG LAMP
·TAIL LAMP, POSITION LAMP,
 LICENCE PLATE LAMP
 AND LIGHTING MONITOR
 BUZZER
·TURN-SIGNAL LAMP AND
 HAZARD WARNING LAMP
·WINDSHIELD WIPER AND
 WASHER

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-28

POWER DISTRIBUTION SYSTEM <LH drive vehicles> (CONTINUED)

FUSIBLE LINK

1

NO
CONNECTION

FUSIBLE LINK

5

DEFOGGER
RELAY

J/B

(FUSE     )

5

·ACD AND AYC
·ANTI-SKID BRAKING
 SYSTEM (ABS)
·CENTRAL DOOR
 LOCKING SYSTEM
·ENGINE CONTROL
 SYSTEM
·HEADLAMP
·IMMOBILIZER SYSTEM
·METER AND GAUGE
·POWER WINDOWS
·REAR FOG LAMP
·ROOM LAMP,
 LUGGAGE COMPARTMENT
 LAMP, IGNITION KEY
 CYLINDER ILLUMINATION
 LAMP AND DOOR AJAR
 WARNING LAMP
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAIL LAMP, POSITION LAMP,
 LICENCE PLATE LAMP AND
 LIGHTING MONITOR BUZZER
·TURN-SIGNAL LAMP AND
 HAZARD WARNING LAMP
·WINDSHIELD WIPER AND
 WASHER

REAR
FOG LAMP

AUTOMATIC AIR
CONDITIONER

POWER
WINDOWS

REAR WINDOW
DEFOGGER
AND DOOR
MIRROR HEATER

REAR WINDOW
DEFOGGER
AND DOOR
MIRROR HEATER

REAR WINDOW
DEFOGGER
AND DOOR
MIRROR HEATER

Wire colour code
B : Black     LG : Light green     G : Green     L : Blue     W : White     Y : Yellow     SB : Sky blue
BR : Brown     O : Orange     GR : Grey     R : Red     P : Pink     V : Violet     PU : Purple

POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-29

NOTES

POWER DISTRIBUTION SYSTEM

CIRCUIT DIAGRAMS

90-30

POWER DISTRIBUTION SYSTEM



<RH drive vehicles>

M1901000401764

BATTERY

FUSIBLE LINK

FUSIBLE
LINK

RELAY BOX

STARTING SYSTEM

ACD AND
AYC

CHARGING
SYSTEM

·AUTOMATIC AIR
 CONDITIONER
·COOLING
 SYSTEM

ANTI-SKID
BRAKING
SYSTEM
(ABS)

·ENGINE CONTROL
 SYSTEM
·IGNITION SYSTEM
·IMMOBILIZER
 SYSTEM

AUTOMATIC AIR
CONDITIONER

·ACD AND AYC
·ANTI-SKID BRAKING
 SYSTEM (ABS)
·STOP LAMP

·AUTOMATIC AIR
 CONDITIONER
·COOLING SYSTEM

CHARGING SYSTEM

·CENTRAL DOOR LOCKING
 SYSTEM
·TURN-SIGNAL LAMP AND
 HAZARD WARNING LAMP

ENGINE CONTROL
SYSTEM

HORN
