7-2

EQUIPMENT   -  Features

FEATURES

Improved reliability

Nrn8QoAA

1. Gold plating of electronic control system terminals

2. MWP (Multipole Water Proof type) connector

Improved visibility

and safety

1. Double action ignition switch (ignition key push type)

adopted to prevent locking the steering wheel during driving

by accidentally removing the ignition key

 vehicles>

2. Large-sized combination meter adopted
3. High-mounted stop light used.
4. Multi-reflector type headlights adopted.

Improved usability and

convenience

1.

ETACS adopted for centralized control of the alarm buzzer

and timer functions

2.

Electric type speedometer whose pointer moves smoothly

without vibrations as the speed changes

Improved serviceability

1.

Data link connectors (centralized terminals for inspection)

adopted to allow inspection of the diagnostic functions

by a scan tool

2. Dedicated connectors for adjustment of ignition timing,

engine speed detection and fuel pump operation check
adopted

3.

Plug-in type combination meter easy to mount and demount

adopted

4. Wiper motor and link system removable as a unit.











The on-board diagnostic system comprises the fol-

lowing functions to assure better serviceability.

Diagnostic trouble

code (low speed
signal) output

0

Diagnostic trouble

code (high speed
signal) output

0

Service data
(high speed signal)
output

0

Actuator test
(low speed signal)

Actuator test

(high speed signal)

0

Simplified inspection
code output (Same
indication pattern as
for diagnosis code)

Diagnostic trouble
code retained in
memory

Auto-cruise

control

0

0

0

0

0

Until battery is OFF

ABS

FWD

AWD

0

0

0

0

0

0

0

EEPROM

Diagnostic trouble

code erased by

0

0

0 0

0

scan tool

 Data is retained in memory until it is electrically cleared.

EQUIPMENT   On-board

 System

  L I N K

Data link connectors (centralized terminals for in-

spection) have been adopted to allow inspection
of the diagnosis functions by the scan tool.

Al

Data link connector (12 pin)

Data link connector (12 pin)

21.



24.
25.

 Eng.

26.
27. CCD Bus

 CCD Bus

. -

;::
32.

Data link connector (16 pin)

1

2

3

4

5

6

7

8

9

10 11 12 13 14 15 16

Data link connector

 pin)

1. Diagnosis control

  I

 Chassis around

5. Signal
6.
7. 9141

 TX*’

8. ABS (AWD)
9. ETACS (One shot pulse signal)

10.



 Auto-cruise control

14. Simulated vehicles speed

15.
16. Battery power supply (+B)

NOTE

 Non-turbo
 Vehicles with

 automatic transaxle

 Engine (MFI), ABS (FWD)

EQUIPMENT   Battery

The battery of the following specifications has been
established.

SPECIFICATIONS

Items

Specifications

B.C.I. Group size 86

B.C.I. Group size 86

Capacity (5HR)

Ah

50

50

Reserve capacity

min.

90

90

Cold cranking current

A

430

525
