Unlock switch

Lock switch

O N



Signals

transmitted

Unlock signal

Lock signal

Signals

received

by

receiver

Door unlock signal

O N

light (operation confirmation function).

NOTE
The receiver determines that the codes are in agree-

I

O F F

I

the transmitter coincides with the code stored in the

ment when any of the three codes transmitted from

I

receiver.

Door lock signal

O N

O F F

Door lock

switch

O N

(Unlock)

O F F

(Lock)





Dome light





O N





O F F

0.5 sec. 0.5 sec.

3 sec.

BODY

 Entry System

OPERATION IN SYSTEM OPERATION MODE
When the transmission switch is pressed once, three
identical codes are transmitted from the transmitter.’

The secret code is decrypted by the comparator circuit

in the receiver which compares the code with the

code stored in the receiver. When the transmitted
code coincides with the stored code, the receiver
sends a door unlock signal or door lock signal to

the ETACS-ECU.

In response to the signal, the doors are locked or
unlocked. When the door lock switch in the door lock

actuator is caused to be ON (unlock) or OFF (lock),
the receiver causes the dome light to flash or steadily



Signals

received
by receiver

Unlock signal

r - l



Door unlock signal

Door lock signal

O N

I

O F F

I

Door switch

30 sec.

O N

O F F

Door lock switch

O N

I

I

(Lock)

TIMER LOCK FUNCTION

If none of the doors is opened in less than 30 seconds

after the doors have been unlocked by the
entry system, the receiver will automatically output
a door lock signal to the ETACS-ECU to re-lock the
doors.
This function prevents accidental unlocking of the
doors that may be caused by an unintentional opera-

tion of the transmitter.

Operation Inhibit Conditions
In the following cases, operation of the system is
inhibited.

l

When a code different from the one stored in
the receiver is received 30 consecutive times
in a minute, operation of the system is inhibited
for 10 minutes.

l

When the ignition key is in the ignition switch
(detected by the key reminder switch)

l

When any of the doors is not fully closed (door

switch: ON)







Code registration switch

V



Receiver

Timing Chart

Code
registration
switch

OPERATION IN CODE REGISTRATION MODE
(PROGRAMMING)
When the code registration switch is in the

 or

position, the receiver enters the registration mode where it
stores the first received secret code in the EEPROM.

Two different secret codes can be stored with the switch in
the

 and

 positions. Therefore, the user can use

two transmitters.

SET-l

FIX

SET-II

Signal sent from

transmitter A

Signal sent from

transmitter B

Valid

Signal received
by receiver



SET-I Starts accepting

secret code
to be stored.

Invalid

Valid

Invalid

I













Secret code is stored in EEPROM when
the switch is changed over from SET-l
or SET-II to FIX.

   Electric Sunroof

l

If an obstruction interferes with the sliding open
motion, the roof lid glass immediately stops.

l

If an obstruction interferes with the sliding close

or tilt down motion, the roof lid glass will auto-

matically reverse.

l

Even after the ignition switch has been placed
at OFF, the sunroof can be operated for 30

seconds. When a door is opened during the
period, the sunroof can be operated for another
30 seconds from that time.



SUNROOF CONTROL SYSTEM

The motor driven outer slide glass sunroof tilt-up

mechanism is an option for all models. This glass
sunroof provides a well-lighted, open environment
even with the roof lid glass in the fully closed state.

The sun roof provides the following features.

To slide open or close the sunroof or tilt it up
or down, you don’t have to continue to press
the switch like the conventional one. The sunroof
operates at the touch of the switch.

If motion of the roof lid glass is interrupted during

a tilt-up operation, the tilt up operation does

not stop until the roof lid glass reaches the fully

tilted up state.

Components

Roof lid glass

 hose









7 .

Tilt-down



 and

Sunroof control uni

sliding close
control

sliding c
control

BODY   Electric Sunroof

SUNROOF CONTROL UNIT

The microcomputer in the sunroof control unit

The sunroof motor drive circuits, incorporated in

trols several functions with two different signals (tilt

the sunroof control unit, operate under control of

up and sliding open, tilt down and sliding close)

the microcomputer.

from various points: the sunroof switches, the door
switch.

System diagram

Ignition switch

Sunroof control unit

--

--

Motor



Sunroof switch



1

 1

 Tilt-up, Sliding open

Microcomputer
